TERASAKI TemBreak PRO TPDA16S Instruction Manual

The DIN rail adapter is the attachment of breakers for mounting on the DIN rail.
Please read these Instructions carefully to ensure correct use of the Device. The Manufacturer
assumes no responsibility for damages resulting from non-application or incorrect application
of the instructions provided herein.
This manual is to be delivered to the user after completion of the installation work.
*The contents of this manual may be subject to change without notice.
〒547-0002
大阪市平野区加美東6 – 13 – 47
TEL 06 – 6791 – 2756
FAX 06 – 6791 – 2732
http://www.terasaki.co.jp
kiki-info@terasaki.co.jp
2M6021SAB KRB-0923b
Assembly Tools
3
4
DIN rail adapter
Instruction Manual
(Types) TPDA16S
6-13-47 Kamihigashi, Hiranoku, Osaka
547-0002, Japan
TEL +81-6-6791-2763
FAX +81-6-6791-2732
http://www.terasaki.co.jp
int-sales@terasaki.co.jp
Applicable Breaker Type
1
1
type
Connections Poles
TPDA16S FC 3
1:FC= Front connected
Packaged Items
2
DIN rail adapter
Safety Notices
4
Be sure to read these Instructions and other associated documents accompanying the product
thoroughly to be familiarize yourself with the product handling, safety information, and all other
precautions before mounting, using, servicing, or inspecting the product.
In these Instructions, safety notices are divided into "Warning" and "Caution" according to the
hazard level:
Warning : A warning notice with this symbol indicates that neglecting the suggested
procedure or practice could be fatal or result in serious personal injury.
Caution : A caution notice with this symbol indicates that neglecting the suggested
procedure or practice could result in moderate or slight personal injury and/or
property damage.
Note that failing to observe caution notices could result in serious injury/damage in some
situations. Because safety notices contain important information, be sure to read and observe
them.
Operation Precautions
Never touch live terminals. Doing so may result in electric shock.
Installation Precautions
Installation work must be performed by competent persons.
Prior to commencing any work on the product, open an upstream circuit breaker or the
like to isolate all sources of power/voltage. Doing so may result in electric shock.
Operation Precautions
Do not apply excessive force to the DIN rail adapter. Otherwise, damage may occur.
Applicable breaker type
Breaker types
PS50-□, PS125-□, P160□
M4 2pcs.
Nut
Warning
Caution
