Page 2
Compliance with all safety and operating instructions in this user manual is a basic prerequisite for safe use of the TILSBERK HUD. The user manual is part of the TILSBERK HUD and must be provided if the TILSBERK HUD is transferred to another user.
4.1 Installing and setting up the TILSBERK HUD app .....................34 4.2 Setting up and using the TILSBERK HUD module .....................36 4.3 Display icons................................38 4.4 Meaning of the LED display on the TILSBERK HUD module ................41 4.5 Starting the navigation ............................42 4.6 Settings ..................................43 5 Storage ....................................45...
P RO D U C T O V E R V I E W Product overview The TILSBERK HUD shows you information directly in front of the eye during the ride. The TILSBERK HUD can be individually configured and display information such as speed, navigation and a compass.
TILSBERK HUD consists of two main components: the helmet adapter, which is installed in your motorbike helmet, and the TILSBERK HUD module, which is affixed to the helmet adapter via a magnetic connection. The narrow outer side of the TILSBERK HUD module features a USB-C charging socket that is used to charge the TILSBERK HUD module.
The TILSBERK HUD app also sends phone data to the TILSBERK HUD module so that the battery level of your smartphone and incoming calls can also be displayed. Once you have set up the TILSBERK HUD app for the first time, you can use the settings to configure the displays, favorite destinations and route setting.
TILSBERK HUD to malfunction. Malfunctions can be irritating while riding and may lead to accidents. • Keep TILSBERK HUD away from liquids and high temperatures. • Do not operate the TILSBERK HUD if it has been exposed to liquids or high temperatures. Risk of injury in case of defective battery! WARNING The installed lithium-ion polymer battery cannot be replaced.
Page 8
Damage to the TILSBERK HUD during the ride distracts you from the traffic. This can lead to accidents and serious injuries. • If your TILSBERK HUD gets hot during the ride or if you notice smoke or deformation of the device, keep calm and pull over on the side of the road as soon as you can.
Page 9
Moisture or high temperatures (over 120 °F) can cause the TILSBERK HUD to malfunction. • Keep TILSBERK HUD away from liquids and high temperatures. • Do not operate the TILSBERK HUD if it has been exposed to liquids or high temperatures.
2.2 Limits of the system Despite its technical precision, it is not possible to guarantee full functionality in all situations. Think about the following system limits before starting your ride to ensure that the TILSBERK HUD is fully functional. Unstable or unavailable Internet connection!
I N - H E L M E T I N STA L L AT I O N In-helmet installation Preparing the installation Before your TILSBERK HUD can guide you to your destination, you have to install it in your helmet. The following sections will help you prepare for installation and choose the right mounting type for your helmet.
Page 12
Does your helmet feature Does the an integrated sun visor? mounting surface of your helmet consist mostly of fabric? Mounting variant A: Clamping in the helmet adapter with tabs Does the mounting Is the fabric material tight surface of your helmet or loose? have a complex geometry? Try to gently twist and...
Page 13
Adhesion is better on fabric surfaces, but these surfaces must also be cleaned. Installation preparation is complete. The installation of TILSBERK HUD can begin now. In the chapter for your determined mounting variant, read how the TILSBERK HUD is correctly mounted in the helmet: •...
I N - H E L M E T I N STA L L AT I O N Finding the mounting variant using the helmet type examples Helmets without sun visor FIGURE 5: Gap in helmets without sun visors Inner shell Gap between inner shell and outer shell Outer shell Position of the helmet adapter with tabs (example)
Page 15
If the tabs of the helmet adapter collide with the sun visor, this helmet is not suitable for installing TILSBERK HUD. In this case, please contact the manufacturer to discuss alternatives. If the helmet adapter with tabs fits into the gap for the sun visor without colliding with the sun visor, continue with mounting variant B (Chapter “3.4 Mounting variant B: Gluing in the helmet adapter with tabs”...
Page 16
I N - H E L M E T I N STA L L AT I O N Complex helmet geometries FIGURE 7: Examples of complex helmet geometries Example of ventilation slots Example of layer between material and plastic frame When it comes to complex helmet geometries, distinguish between helmets with ventilation slots and helmets with a layer between the padding material and the plastic frame.
3.3 Mounting variant A: clamping in the helmet adapter with tabs Video instructions Detailed video instructions for installing TILSBERK HUD in helmets without sun visors are available on the Internet. To access, scan the QR code or call up the video via the browser link.
Page 18
Checking the position of the helmet adapter Put your helmet on as usual. Attach the TILSBERK HUD module to the helmet adapter using the magnets and fold down the display at a 45° angle. The display should be well visible in front of your right eye.
Page 19
Always recheck the conditions listed in step 6 and keep adjusting the position of the helmet adapter until all conditions are met. You have mounted the helmet adapter with tabs in the helmet. Proceed by setting up the TILSBERK HUD app (Chapter “4.1 Installing and setting up the TILSBERK HUD app” on page 34).
3.4 Mounting variant B: Gluing in the helmet adapter with tabs Video instructions Detailed video instructions for installing TILSBERK HUD in helmets using adhesive pads are available on the Internet. To access, scan the QR code or call up the video via the browser link.
Page 21
Check whether the helmet adapter sits correctly on the helmet. To do so, use the magnets to attach the TILSBERK HUD module to the helmet adapter. The TILSBERK HUD module must be completely in contact with the helmet adapter. There must be no visible gap between the TILSBERK HUD module and the helmet adapter.
Page 22
Put your helmet on as usual. Attach the TILSBERK HUD module to the helmet adapter using the magnets and fold down the display at a 45° angle. The display should be well visible in front of your right eye.
Page 23
You have used the adhesive pads to attach the helmet adapter with tabs to the helmet. Proceed by setting up the TILSBERK HUD app (Chapter “4.1 Installing and setting up the TILSBERK HUD app” on page 34).
3.5 Mounting variant C: Using an adhesive pad to glue in the narrow helmet adapter Video instructions Detailed video instructions for installing TILSBERK HUD in helmets using adhesive pads are available on the Internet. To access, scan the QR code or call up the video via the browser link.
Page 25
I N - H E L M E T I N STA L L AT I O N Installing the helmet adapter FIGURE 10: Using an adhesive pad to glue in the narrow helmet adapter Clean the helmet adapter thoroughly. Stick the adhesive pad (FIGURE 10/1) to the side of the helmet adapter on which you can see the magnets.
Page 26
Check whether the helmet adapter sits correctly on the helmet. To do so, use the magnets to attach the TILSBERK HUD module to the helmet adapter. The TILSBERK HUD module must be completely in contact with the helmet adapter. There must be no visible gap between the TILSBERK HUD module and the helmet adapter (FIGURE 11/1).
Page 27
13. Always recheck the conditions listed in step 10 and keep adjusting the position of the helmet adapter until all conditions are met. You have used the adhesive pad to attach the narrow helmet adapter to the helmet. Proceed by setting up the TILSBERK HUD app (Chapter “4.1 Installing and setting up the TILSBERK HUD app” on page 34).
Sugru can leave residues on fabrics and leather. These residues can be hard to remove and traces are likely to remain. • Use TILSBERK HUD with Sugru only if residue on the fabric of your helmet does not bother you.
Page 29
I N - H E L M E T I N STA L L AT I O N Preparing Sugru FIGURE 12: Applying Sugru to the narrow helmet adapter Sugru hardly needs any preparation to develop adhesive properties. The adhesiveness develops through the reaction of the material with the ambient air.
Page 30
I N - H E L M E T I N STA L L AT I O N Place the roll (FIGURE 12/3) on the side of the helmet adapter on which you can see the magnets (FIGURE 12/5). Use your fingers to carefully and evenly distribute the Sugru over the entire surface of the helmet adapter.
Page 31
10. Check whether the helmet adapter sits correctly on the helmet. To do so, use the magnets to attach the TILSBERK HUD module to the helmet adapter. The TILSBERK HUD module must be completely in contact with the helmet adapter. There must be no visible gap between the TILSBERK HUD module and the helmet adapter (FIGURE 14/1).
Page 32
I N - H E L M E T I N STA L L AT I O N 13. Attach the TILSBERK HUD module to the helmet adapter using the magnets and fold down the display at a 45° angle. The display should be well visible in front of your right eye.
Page 33
You have used Sugru to attach the narrow helmet adapter to the helmet. Proceed by setting up the TILSBERK HUD app (Chapter “4.1 Installing and setting up the TILSBERK HUD app” on page 34).
Setting up the TILSBERK HUD app Once you have successfully installed the TILSBERK HUD app, you have to set up the TILSBERK HUD app once. To set up the TILSBERK HUD app and pair it with the TILSBERK HUD module, charge the TILSBERK HUD module before you start setting up the TILSBERK HUD app.
Page 35
For the TILSBERK HUD app to work properly, you must grant all required permissions. Note that the TILSBERK HUD app requires location access “Always.” Once you have completed the setup, you are prompted to connect the TILSBERK HUD module to the TILSBERK HUD app. Pairing the TILSBERK HUD module with the TILSBERK HUD app Once you have granted all required permissions to the TILSBERK HUD app, the TILSBERK HUD app...
Sometimes, pairing fails. In this case, proceed as follows: Switch off the TILSBERK HUD module. Check the Bluetooth® settings of your smartphone. If the TILSBERK HUD module is listed under paired devices, delete the connection. Repeat the pairing process. Make sure you perform the steps in the right order.
Page 37
O P E R AT I O N Fully charge your TILSBERK HUD module before you use it for the first time. Use the USB-C charging cable from the scope of delivery. As the power source, use a power adapter with USB port or a suitable electronic device, such as a computer or a charged power bank.
4.3 Display icons 45° FIGURE 15: Display (example) Depending on the settings in the TILSBERK HUD app, the display will show the following information and notes: Bluetooth® status This icon appears on the display as soon as your TILSBERK HUD is connected to your smartphone via Bluetooth®...
Page 39
O P E R AT I O N Smartphone battery warning The display warns you when the battery level of your smartphone is low. The exact battery level at which the warning appears depends on your smartphone. Current speed The speed indicator shows you your current speed. The bar above the line signals your speed change if you accelerate or brake.
Page 40
O P E R AT I O N Lane information The lane information provides information on the lanes available and turn-offs from the road. The bright arrows show you which lanes you should use. Compass The compass shows you in which cardinal direction you are currently traveling.
Time The display shows the current time. You can use the settings in the TILSBERK HUD app to select from different display layouts and hide some icons (Chapter “Configuring the display layout” on page 43). 4.4 Meaning of the LED display on the TILSBERK HUD module The status LED on the TILSBERK HUD module indicates the current status of the device:...
O P E R AT I O N 4.5 Starting the navigation Use the TILSBERK HUD app to select your destination and route settings, and let the TILSBERK HUD module guide you to your destination. Accident risk in case of inattentiveness! WARNING Inattentiveness in traffic can lead to serious accidents.
4.6 Settings In the “My device” menu, you can adapt your TILSBERK HUD to your specific needs. You can determine which information should be displayed on the display, adjust the brightness as necessary and find all the necessary information about your device.
Page 44
(for example, if you ride into a tunnel). Activating voice prompts If, in addition to the TILSBERK HUD module, you have a headset or headphone connected to your smartphone, you can activate voice prompts for navigation directions. Start route planning.
STO R AG E Storage If you want to store your TILSBERK HUD while you are not using it, pay attention to the ambient conditions at the storage location and the condition of your device: Temperature: between 30 °F and 120 °F Protected from light: Use the protective cover provided and store the device away from direct sunlight.
Use the protective cover provided or a clean microfiber glass cleaning cloth to thoroughly clean the TILSBERK HUD module. In particular, make sure that there is no dirt on the light sensor or the display. To remove stubborn dirt, lightly moisten the protective cover or glass cleaning cloth with clear water.
Page 47
Cleaning a helmet with an installed helmet adapter To clean your helmet, remove the TILSBERK HUD module from the helmet adapter. You can clean the outside of your helmet as you normally would when the helmet adapter is installed. Follow the helmet manufacturer’s instructions when doing so.
Sometimes, the pairing of your smartphone with the TILSBERK HUD module fails. Switch off the TILSBERK HUD module. Check the Bluetooth® settings of your smartphone. If the TILSBERK HUD module is listed under paired devices, delete the connection. Repeat the pairing process (Chapter “Pairing the TILSBERK HUD module with the TILSBERK HUD app” on page 35).
Page 49
The small ring on the display (FIGURE 16/3) must point to the flat side of the TILSBERK HUD module. Insert the clamping wedge (FIGURE 16/4) into the support (FIGURE 16/5) on the display holder. Place one side of the display holder on the TILSBERK HUD module, then push and swing it back into its position.
D I S P O S A L Disposal Environmental hazard in case of incorrect disposal! NOTICE Incorrect disposal can result in environmental hazards. • Dispose of the product in accordance with local rules and regulations. • The device with the built-in battery may only be disposed of properly via collection boxes in shops or at municipal collection points.
5.5 x 1.7 x 0.7 in (extended display) Weight Approx. 1.5 oz (TILSBERK HUD module) Approx. 1.9–2 oz (TILSBERK HUD module with helmet adapter and Sugru or adhesive pads) Control Navigation via the app for Android or iOS with speed recording and...
Page 52
You will find the serial number on the label on the top of the TILSBERK HUD module as well as in the “Settings” menu in the TILSBERK HUD app once the device has been paired.
10 Index Magnets ..............19 , 22 Adhesive pads Large pads for helmet adapters with tabs 19 Material types in the helmet ......15 Narrow pad for narrow helmet adapter ..22 Meaning of symbols ..........2 Small pads for helmet adapters with tabs ............
Page 54
FCC compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 55
1991 us.tilsberk.com TILSBERK North America Inc.
