Summary of Contents for PRORECK PR-212T
- Page 1 CONCERT SET & VENUE SET USER MANUAL...
- Page 3 WARNING! Do not open cover. No user-serviceable parts inside. Refer servicing to qualified service personnel. Do not place the product in a location near a heat source, such as a radiator, or in an area subject to direct sunlight, excessive dust, mechanical vibration or shock. The product must not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the product.
- Page 4 CONCERT SET...
- Page 5 CONCERT SET This set includes 5 packages. BOX MODEL CONTENTS 1 x subwoofer PR-212T 1 x power cord (6-feet) PR-15S 2 x tripod stand 2 x adapter 2 x speakon to 6.35mm cable (10-feet) PR-ADAPTER 2 x 6.35mm array cable (8-inch) 4 x 6.35mm array cable (14-inch)
- Page 6 CONCERT SET STAGE / HEAD HEIGHT FROM SUB HEIGHT FROM FLOOR: 1 -2 METRES AUDIENCE COVERAGE: 200 - 300 PEOPLE INPUT PARALLEL SERIES 10˚ INPUT 5˚ 0˚ PARALLEL SERIES 10˚ 5˚ 0˚ INPUT PARALLEL 10˚ SERIES 5˚ 0˚ INPUT 10˚ PARALLEL 5˚...
- Page 7 CONNECTION OF CONCERT SET When you use this way of connection, it is nec- essary for you to release the button (as circled in the picture) to stereo.
- Page 8 VENUE SET...
- Page 9 VENUE SET This set includes 7 packages. BOX MODEL CONTENTS 1 x subwoofer PR-212T 1 x power cord (6-feet) 1 x subwoofer PR-212T 1 x power cord (6-feet) PR-204V 4 x array speaker PR-204V 4 x array speaker PR-204V 4 x array speaker...
- Page 10 VENUE SET FLOWN/ABOVE HEAD HEIGHT HEIGHT FROM FLOOR: 3+ METRES AUDIENCE COVERAGE: 500+ PEOPLE Each satellite power output can connect only one four-array set. FROM SUB INPUT 10˚ PARALLEL 5˚ SERIES 0˚ INPUT 10˚ PARALLEL 5˚ SERIES 0˚ INPUT PARALLEL 10˚...
- Page 11 CONNECTION OF VENUE SET When you use this way of connection, it is nec- essary for you to press the button (as circled in the picture) to mono.
- Page 12 FUNCTIONS -SUBWOOFER - 2 1 2 T AC INPUT POWER AC115V ~ 60Hz AC230V ~ 50Hz MADE IN CHINA...
- Page 13 FUNCTIONS -SUBWOOFER 1. SUBWOOFER LEVEL Adjust this knob for independent control over the subwoofer. 2. SATELLITE LEVEL Adjust this knob for independent control over the satellite speakers. 3. INPUTS Use these combi-jack inputs to connect line-level sources such as mixing consoles. 4.
-
Page 14: Dsp Settings
FUNCTIONS -ARRAY SPEAKER PR-204V 1. SERIES OUT Adjust this switch to determine whether the signal is provided from one speaker to the next in either series or parallel. 2. INPUT Provides input to the speaker from the subwoofer or another satellite via ¼” TS Jack. 3. - Page 15 STANDARD DJ 1 DJ 2 LIVE DJ 1 Boosts the bass to help drive dance music and enhance your party's atmosphere. Ideal for larger venues. Examples • DJ and Club events • Larger venues STANDARD DJ 1 DJ 2 LIVE DJ 2 Cut through audiences for a pronounced sound, With low and high end boosts and a slight mid cut.
- Page 16 SPEAKER SET UP 1. Insert the front pillar into the slots at the bottom 2. Achieve the speaker angle you desire by aligning of the speaker. This allows you to connect the the holes to your intended placement and then speaker to the stand adapter.
-
Page 17: Specifications
SPECIFICATIONS 12” Subwoofer Twin Speaker Dual 12’’ bass reflex subwoofer, 2.1 Model Dual: 4’’ 2-way passive system function Frequency response (-10dB) 45Hz-250Hz 150Hz-16KHz Sensitivity (1W@1M) 125 dB 109 dB RMS: 700W RMS: 60W Power output (RMS) Peak: 1000W Peak:85W Max: 2800W Max:160W Nominal impedance 4Ω... - Page 18 CONCERT SET This set includes 5 packages. BOX MODEL CONTENTS 1 x subwoofer PR-212T 1 x power cord (6-feet) PR-15S 2 x tripod stand 2 x adapter 2 x speakon to 6.35mm cable (10-feet) PR-ADAPTER 2 x 6.35mm array cable (8-inch) 4 x 6.35mm array cable (14-inch)
