ZM-RS6F USB (USB Surround Sound Headphones) User's Manual
Thank you for purchasing Zalman's ZM-RS6F USB (USB Surround Sound Headphones). Please read the
User's Manual thoroughly before using the product and keep the 'Product Warranty' document.
[1] Features
In-Line 5.1 Channel USB Soundcard
USB Based 6-Speaker Surround Sound Headphones
Ideal for Surround Sound with Notebooks for DVD Movies and Games
Real Surround Field Comparable to a Complete Multi-Channel Speaker System
Programmable Spatial Processing, Graphic EQ and More
[2] Specifications
<Headphones>
● Unit Type : Electro Dynamic Round Type Micro Speaker
● Frequency Response : 50Hz ~ 20kHz
● Sound Pressure Level : 89dB ± 3dB at 1kHz
● Impedance : 16 Ohm at 1kHz / 32 Ohm at 1kHz (center speaker unit)
● Weight : 13.64oz (386.6g) *Headphones only(excluding the cable)
● Cord: 7.9ft (240cm)
<Soundcard>
● Input: 1 USB Connection Port(USB 1.1 / 2.0 Compatible)
● Chipset: C-Media CM6206 5.1 Sound
● Sampling Rate: 16bit 44.1kHz, 48kHz Compatible
● Size(W*H*D): 34*18*91mm
● Power Consumption: Minimum 3.3V, 150mA(Standard 5V, 500mA)
● Output: 0.3W per channel
- 1 -
Advertisement
Related Manuals for ZALMAN ZM-RS6F USB
Summary of Contents for ZALMAN ZM-RS6F USB
- Page 1 ZM-RS6F USB (USB Surround Sound Headphones) User’s Manual Thank you for purchasing Zalman’s ZM-RS6F USB (USB Surround Sound Headphones). Please read the User’s Manual thoroughly before using the product and keep the ‘Product Warranty’ document. [1] Features In-Line 5.1 Channel USB Soundcard...
- Page 2 [3] System Requirements ● Software OS: Microsoft Windows XP, Vista ● Hardware Notebook: Pentium III 700MHz or greater (1GHz or greater recommended) Desktop: Pentium III 800MHz or greater (1GHz or greater recommended), Celeron 1.3GHz or greater Memory: 256MB or greater USB Port: USB 1.1 / 2.0 compatible [4] Contents One (1) Set of USB...
- Page 3 USB Connector [6] How to Wear the Headphones ZM-RS6F USB is designed in an Over Head Band style. Please wear the headphones as illustrated in Figure B, and keep or store it as shown in Figure A. * Make sure to properly distinguish the Left/Right channels of the headphones before wearing it.
- Page 4 [7] Installation Connect the headphones’ USB Connector to the PC’s USB port. The OS will automatically detect the headphones, and the “Found New Hardware” message will pop up. * This product could generate a slight pop-up noise during connection to or removal from of the PC’s USB port.
- Page 5 [8] Software Installation Inserting the provided Driver & Utility CD into the PC’s CD-ROM/DVD-ROM drive will generate an auto run of the installation program. (If auto run is not executed, then run the setup.exe file from the CD) - 5 -...
- Page 6 Proceed with the installation according to the directions. Once installation is complete, restart the system. - 6 -...
- Page 7 [9] System Configuration Click on the ‘USB 3D Sound Configuration’ icon in the Task Manager on the bottom right side of the OS. - 7 -...
- Page 8 ) on the bottom will run the channel test. * The ZM-RS6F USB is a five channel unit that does not have a built-in sub woofer. Therefore, the sub woofer channel will not be heard during the channel test. This is not a defect of the product.
- Page 9 Click on the ‘Mixer’ tab. Vol: Adjusts the volume level and balance regarding the audio input source. Select ‘Microphone’ and ‘Line In’ to disable them (This product does not have MIC and line input terminals. Therefore, the features mentioned above is should be muted). <Volume Control>...
- Page 10 Equalizer: Volume can be controlled by frequency, and a preset mode can also be used. ※ Note C-Media 3D 106 Configuration program is a general-purpose software provided for all soundcards using C- Media chipsets. Therefore, certain features related to MIC Input, Recording, and S/PDIF Output are not applicable to ZM-RS6F USB. - 10 -...
- Page 11 [10] Trouble Shooting 1) When no sound is generated - Check the activation status of the USB Controller in the CMOS Settings of the PC. - Check to see if the ‘C-Media USB Sound Device’ has been set as the basic device for sound playback in the PC’s Control Panel(Sounds and Audio Devices Properties).
- Page 12 Warnings Ignoring or improperly reading the content of this sign could lead to death or serious physical injuries. ● In the following cases stop using the product and contact to ZALMAN. - If smoke or strange smell is emitted - If water or metallic objects have entered the product - If the product has been dropped and the exterior has been broken ●...
- Page 13 [12] Product Warranty (International) Warranty – If this product has any defects, then Zalman guarantees that it can be exchanged within one (1) year from the time of purchase. * Product exchange is made with the reseller where the product was purchased. For further inquiries, contact Zalman Headquaters at www.zalman.co.kr or via e-mail to a representative.
