Summary of Contents for Evobike Balance
- Page 1 Manual Evobike Balance...
- Page 2 1、 Preface 2、Main technical parameters of electric vehicles 3、Main technical parameters of the battery 4、Main technical parameters of the motor 5、Main technical parameters of the controller 6、packaging 7、shakedown test 8、Safety and maintenance 8.1 Safety advice Maintain Please pay attention 1、Before riding, please read the Product Operation Manual carefully and check whether the parts are in good condition to ensure your riding safety.
- Page 3 appliances, please pay attention! 4、Do not disassemble the decomposed parts by yourself. If you need replacement, please purchase standard parts from the general agent of our electric scooter. 5、For the safety of others, please do not lend your electric scooter to someone who can not operate to ride, and thus also protect your car from unnecessary damage.
- Page 4 Main technical parameters of electric vehicles 2、Main technical parameters of electric sliding vehicle 2-1、Vehicle weight：≤15kg 2-2、dead weight ：≤60kg 2-3、The highest speed：20km/h 2-4 、 Continuation mileage ： 10~15km(60Kg at 20 Km/h on flat open surface,Ride without interruption) 2-5、Climbing capacity：≤30°slope 2-6、power rating ：≤250w 2-7、Tire tire pressure：≤35- 55psi 3、Main technical parameters of the battery 类型...
- Page 5 electric efficiency ≥80% 5、Main technical parameters of the controller 类型 24V controller 项目 20.5V±0.5V er-pressure protection value Overflow protection value 20A ± 1A 6、packaging 6-1、Install the handlebars. 6-2、Install front wheels.(Note: 1. The installation sequence of the wheel axle sleeve and gasket is shown in the figure below.2.
- Page 6 6-3、Down-to-earth installation. Two cylindrical feet, one foot is the open hole, one is M10 thread, from the open hole of the screw through the frame under the position of the other threaded foot rotation tightly fixed. 7、shakedown test 7-1、Mad height debugging. Release the saddle tube hug hoop, press and pull the saddle to the appropriate height (note that no safety line is exposed), clamp the hug hoop, and confirm that the cushion will not move...
- Page 7 7-2、Pat angle adjustment. Functional display 1、Long press（ ）：Open / close。 2、Short press（ ）：Replacement mileage display。 3、There are 3 gears， “1-2-3”Short press（ ）The button reduces or increases gears.ECO i MID is s low gear， Medium speed HIGH is gears， high gear。...
- Page 8 4、Long press（ ）+（ ）Go to the setting parameter interface，press（ ）Replace parameter items，pres （ ）Parameter plus 1，press（ ）Parameter minus 1。 Set the value： P01：8 P02：0 P03：24 P12：2 P13：01 P14：3 P04：10 P05：5 P06：10 P07：15 P15：08 P16:12 P17：20.0 P08：16 P09：90 P10：100 P11：0 P19：0 P20:1 P26：20.0 WARNING：..Instrument parameters are strictly prohibited...
- Page 9 should not be stored for more than 30 days. --Lithium-ion batteries will decline in storage capacity —The battery should be charged every 30 days for about 2 hours each time —The battery shall have fire prevention measures when being stored together. There should be a safe distance or reinforced material isolation battery.
- Page 10 Do not use a high-pressure washer! Maintain Your electric balance bike is very safe for the environment. Used parts must be disposed in the appropriate classification recycling bin. The battery can no longer be used and returned to your dealer so that he can transfer it to the recycling company.
- Page 11 Wheel & Tire Rear 16-2.126 Tyre Inflatable tire DIMENSIONS & WEIGHT Wheelbase (axle to axle) 780mm Seat Height 480mm + 100mm Product Weight N.W | G.W 12.8 / 14.8 Max Load 75 Kg Product Packing Size 101x24x56CM Info@evobike.se info@evobike.no info@evobike .dk info@evobike.fi...
