USER MANUAL
SANITATION
iNDUS smart sanitation system

Advertisement

Table of Contents
loading

Summary of Contents for Thetford iNDUS i105-S

  • Page 1 USER MANUAL SANITATION iNDUS smart sanitation system...

  • Page 2: Table Of Contents

    1. Introduction General This is the user manual for the Thetford iNDUS smart sanitation system. Read the safety instructions and information on use and maintenance of the system carefully before continuing. This will enable you to use the system safely and efficiently.

  • Page 3: Safety

    Note. Additional information. Video. Additional instruction video available. 2. Safety General The iNDUS system is an integrated domestic wastewater management system for leisure vehicles. It must not be used for any other purpose than the collection, storage, treatment, reuse and discharging of domestic wastewater produced by human habitation activities in the leisure vehicle.
  • Page 4 ■ Do not empty if specific black water discharge rules or regulations indicate that it is not allowed. In that case, always use the discharge point for black water. Use of the cartridges Risk of health issues, injury, skin burns and eye irritation or damage to the product.
  • Page 5 Troubleshooting Risk of serious injury through cutting and clamping or damage to the product. ■ Always disconnect the product and its components from the power supply before troubleshooting mechanical parts. ■ There is a serious injury risk when touching the sharp macerator knives located below the toilet bowl valve.

  • Page 6: Overview

    4. Before use Read the applicable instructions in the Safety chapter first. Before using the product: ■ Prepare the dosing module. ■ Connect to the Thetford iNDUS app. Prepare the dosing module The dosing module contains three separate cartridges with additives:...
  • Page 7 Click here for more information on how to place the cartridges. Connect to the Thetford iNDUS app In order to get information on the additives- and tank levels the product needs to be connected to the Thetford iNDUS app on your smartphone.

  • Page 8: Use

    ■ Turn on the Bluetooth connection on your smartphone (4). ■ Open the Thetford app and follow the steps up to the Setup connection screen. ■ Press and hold both flush buttons (5) simultaneously on the control panel of your toilet at least 5 seconds until the blue light (6) flashes.
  • Page 9 The control panel has three buttons: 1. Big flush 2. Small flush 3. Bowl valve open/close Use the Thetford app to adjust the settings regarding water consumption, flushing and night modus. For daily use: ■ Flush the toilet using the button for big flush (1) or small flush (2).
  • Page 10 Replace an additive cartridge If an additive cartridges is empty, it must be replaced. Use the Thetford app for information on the additives level per cartridge, or look at the level through the additive cartridge in the cartridge holder. If additive cartridge A & B are empty, the system only uses fresh water instead of grey water to flush.
  • Page 11 You can always discharge wastewater at discharge points for black water. In many cases it is also possible to discharge at a grey water discharge location, provided it is connected to the general sewerage infrastructure. You can check the nearest discharge location via the Thetford app. Preparation ■...
  • Page 12 ■ Wait for all the wastewater to be pumped out. The discharge cycle is complete when the blue light on the discharge control panel turns off. ■ To close the valve of the discharge device (7) depending on the version of the discharge device: Or press and release the knob in the handle.

  • Page 13: Maintenance And Cleaning

    ■ Remove the cap from the holding tank (1). ■ Place the discharge device directly on the opening of the holding tank (2). ■ Perform a normal discharge cycle. (refer to step 6 of Discharge the tanks) but, while holding the discharge device on the opening of the holding tank, press the discharge button using your other hand.
  • Page 14 Clean the toilet and discharge device at least once a week. Clean the toilet ■ Clean the inside of the bowl with "Thetford Toilet Bowl Cleaner" and a soft brush. ■ Clean the outside of the toilet with "Thetford Bathroom Cleaner".
  • Page 15 ■ Place the cap on the additive cartridge (5). ■ Store in a frost free environment. If you do not remove all the additive cartridges, the system cannot be winterized. A red light is displayed on the discharge control panel. Discharge the black and grey water tanks ■...
  • Page 16 ■ Close the access hatch. The system is now fully winterized. Click here for more information on how to drain the tanks. After storage When using the system after storage: ■ Open the access hatch in the floor. ■ Close the drain valves of the black and grey water tank by turning the drain stick clockwise (10).

  • Page 17: Disposal

    7. Disposal When the system has reached the end of its life, it must be disposed of according to local regulations. Environmental Protection Discarded electric appliances are recyc- lable and should not be discarded in the domestic waste. Please actively support us in conserving resources and protecting the environment by returning this appli- ance to the collection centres (if available).

  • Page 18: Service & Questions

    Dosing module Main dimensions (HxWxD) 360 x 280 x 110 mm Weight without additives 1.1 kg Weight with additives 4.7 kg Tank module double floor models Model 210806 210807 210809 Overflow volume black water tank 55 l 55 l 55 l Overflow volume grey water tank 120 l 120 l...
  • Page 19 Error in the system. Check if the discharge valve shows a red light. is open. Start the discharge cycle again. The Thetford app shows the Bluetooth is off. Turn bluetooth on. error message ‘can’t con- Pairing did not succeed. Try to pair, refer to Connect nect to iNDUS’.
  • Page 20 Contact an authorised local the grey watertank. Service Centre. For more troubleshooting check the website www.thetford.com Questions If you have questions about your product, parts, accessories or authorised services visit www.thetford.com or use the service part in the Thetford app.
  • Page 21 If you contact an authorised local Service Centre in your country, provide the details of the model and serial number plus the date of purchase. Warranty For our warranty clause, please refer to the conditions mentioned on www.thetford.com. Declaration of Conformity Thetford hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the applicable Directives and Standards.
  • Page 22 T +61 3 9358 0700 T +86 755 8627 1393 T +46 31 336 35 80 F not available F +86 755 8627 1673 F not available E infoaus@thetford.com.au E info@thetford.cn E infos@thetford.eu www.thetford.com.au www.thetford.cn Copyright 2020-2023 Thetford B.V. All rights reserved. 210407/1223-V04...
