Summary of Contents for DAYLIFF B25

Page 1 TRIMMERS Shamba Tool Installation & Operating Manual...
Page 3 INDEX SPECIFICATIONS 2. SYMBOLS & WARNINGS OPERATION TROUBLE SHOOTING WARRANTY © Davis & Shirtliff Ltd 2023 Contents herein are not warranted...
Page 4: Specifications
Models available are as follows:- • Trimmer B25 Solid shaft edge trimmers fitted with loop handle grip with integral control lever conveniently positioned for ease of use when standing. They are particularly suited for cutting weeds, small trees and other foliage in areas not accessible by a lawn mower •...
Page 5: Parts Location
PARTS LOCATION 1. Nylon Cutter Head 9. Fuel Tank 2. Drive Shaft Assembly 10. Throttle Trigger 3. Handle Assy 11. Air Cleaner Cover 4. Harness Assy 12. Choke Cold Starts 5. Ignition Switch 13. Starter Handle 6. Safety Lever 14. Debris Shield 7.
Page 6 1. Knob Bolt 11. Starter Knob 2. Drive Shaft Housing 12. Cutting Line Head 3. Loop Handle 13. Gear Case 4. Shoulder Strap Hanger 14. Debris Guard 5. Ignition Switch 15. Blade (optional) 6. Throttle Trigger Lockout or Safety 16. Guide Bar Lever 17.
Page 7: Symbols And Warnings
2. SYMBOLS & WARNINGS Use appropriate head, eye and ear protection. WARNING Inspect the entire machine for loose parts (nuts, bolts , screws etc) and any damage. Repair or replace as necessary before using the machine WARNING Do not use any attachment, spares or accessories with this trimmer other than the ones recommended.
Page 8 Never start or run the machine inside a closed room or building. WARNING Never attempt to make engine adjustments while the unit is running and strapped to the operator. WARNING Do not use the unit if it is damaged or poorly adjusted. Never remove the machine's guard.
Page 9: Operation
When refueling, never remove the fuel tank cap while the engine is running. Be sure to stop the engine and conrm that it is cooled down. Never refuel when the engine is running or hot. WARNING When gasoline spills, wipe it up completely and properly dispose of cleaning materials before starting the engine.
Page 10: Installing Handle
Gear Case Bracket Shield M5x16 Screws INSTALLING NYLON LINE CUTTER HEAD Ÿ Align hole in adapter plate with hole in shaft and install locking tool. Ÿ Thread cutter head onto shaft (turning it clockwise) until it is tight. Ÿ Remove locking tool. (Refer to pg 12 for additional information) INSTALLING HANDLE Ÿ...
Page 11: Connecting The Trimmer
M5x25 Handle Screws Lower Cap ASSEMBLING THE ROD OF M32 Ÿ Insert the rod(1) in the sleeve (2) so that the hole (3) coincides with the screw(4) as shown in picture 1. Ÿ Tighten the two screws (4) and (5) completely.The head of the screw(4) must not stick out when tightened.
Page 12: Starting Procedure
6. Insert the latch tongue in the slot of the quick release latch to reattach the grass trimmer to the harness. STARTING PROCEDURE Ÿ Dayliff trimmers use two-stroke fuel, a blend of petrol and 2-stroke engine oil in proportions tabulated below. Description...
Page 13 Ÿ Check and confirm that the fuel tank has sufficient fuel for the work or add fresh fill of 2 stroke fuel as above. Ÿ It is recommended that the 2 stroke is mixed in a separate container before filling into the fuel tank.
Page 14 Starting Warm Engine If the engine has been in operation for a period and is still warm, it can be restarted without pulling the choke lever out. Stopping the Engine Move switch to stop position Using the Trimmer Debris Cut On This Side Cut-off Knife on Left Side...
Page 15 TRIMMING Debris EDGING Knife Side SCALPING Raised Angle to Ground Angle to Wall AVOID WIRE TRIMMING: Ÿ This is feeding the trimmer carefully into the material to be cut. Tilt the head slowly to direct debris away from you. If cutting up to a barrier such as fence, wall or tree, approach from an angle where any debris ricocheting off the barrier will fly away from operator.
Page 16 NYLON ROPE REPLACEMENT 2.5mm 120mm (4.75 in)
Page 17: Direction Of Use
HEDGING HEAD Direction of use Before starting work check the following: Ÿ All the screws on the machine and the blade are tightly fastened Ÿ Blades are sharp and there are no signs of any damage Ÿ Protection devices are well fastened and working efficiently Ÿ...
Page 18 HORIZONTAL TRIMMING Ÿ The best results will be obtained with the blade slightly inclined (5° - 10°) in the direction of the cut, proceed with a curved movement, slowly and without interruptions, especially in the case of very thick hedges. LUBRICATING THE BLADES DURING JOBS Ÿ...
Page 19: Using The Unit
MAINTENANCE AND SHARPENING OF THE BLADE Periodically check to ensure the blades are not bent or damaged and that the xed comb on the blade is intact. WARNING Ÿ Adjustment of the distance between blades is not necessary, as this is predetermined by the manufacturer.
Page 20: Working Techniques
Never stand directly underneath the branch you are cutting, be wary of falling branches. Note that a branch may spring back after it hits the ground with risk of injury. Remove branches in WARNING sections. Working Techniques Hold the control handle with the right hand, and the shaft with the left hand. The left arm should be extended to the most comfortable position.
Page 21 Cutting Above Obstacles: The unit's long reach makes it possible to prune branches that are overhanging obstacles, such as rivers or lakes. The tool angle in this case depends on the position of the branch. Cutting From a Lift Bucket: The unit's long reach enables cutting to be performed next to the trunk without the risk of the lift bucket damaging other branches.
Page 22: Checking Chain Tension
Fitting The Chain Retensioning during cutting work: Ÿ Stopping the engine. Ÿ Loosen the nut. Ÿ Hold the bar nose up. Ÿ Use a screwdriver to turn the tensioning screw (1) clockwise until the chain fits snugly against the underside of the bar. Ÿ...
Page 23: Preparing For Operations
Opening the Filler Cap Ÿ The bayonet-type oil tank filler cap with hinged grip can be opened and closed without tools. Ÿ To open the tank, swing the grip to the vertical position. Ÿ Turn the filler cap counterclockwise as far as stop and remove. Filling up with Chain Oil Ÿ...
Page 24 To quickly detach the pole saw from the shoulder strap ,pull the quick-release latch tab upward. WARNING Controls 1. Throttle trigger lockout 2. Throttle lever 3. Slide switch Starting Press down the trigger lockout lever and squeeze the throttle lever and hold them in that position.
Page 25 Ÿ Hold the starter grip with the right hand. Ÿ Pull the starter grip slowly until it engages and then give it a brisk strong pull. Ÿ Do not let the starter grip snap back. Guide it slowly back into the housing so that the starter rope can rewind properly.
Page 26: After Finishing Work
This avoids unnecessary high loads during the break-in period. As all moving parts have to bed in during the break-in period, the frictional resistance in the engine are greater during this period. The engine develops its maximum power after about 5 to 15 tank fillings.
Page 27: Checking And Replacing The Chain Sprocket
Before every cut, mark sure that the cutting attachment stops turning when the engine idles. WARNING Checking and Replacing the Chain Sprocket Ÿ Remove the chain sprocket cover, chain and guide bar. Replace the Chain Sprocket Ÿ After using two saw chains or sooner. Ÿ...
Page 28: Engine Management
It is absolutely essential to comply with the angles and dimensions specied below. If the saw chain is incorrectly sharpened – and in particular if the depth gauge is set too low – WARNING there is an increased risk of kickback, with resulting risk of injury.
Page 29: Checking The Spark Plug
Checking the Spark Plug Ÿ Clean dirty spark plug. Ÿ Check electrode gap (A) and readjust if necessary see"Specifications". Ÿ Use only resistor type spark plugs of the approved range.Rectify problems which have caused fouling of spark plug:– Too much oil in fuel mix.– Dirty air filter.– Unfavorable running conditions, e.g.
Page 30: Fuel Filter
FUEL FILTER Ÿ Fuel tank is fitted with a filter. Filter is situated at the free end of fuel pipe and can be picked out through fuel port with a piece of hooked wire or the like. Ÿ Check the fuel filter periodically. Do not allow dust to enter into fuel tank. Clogged filter will cause difficulty in starting engine or abnormalities in engine performance.
Page 31 The following intervals apply to normal operating conditions only. If the daily working time is longer or operating conditions are difcult (very dusty work area, etc), shorten the specied intervals accordingly Complete Machine Visual inspection √ √ (condition leaks) √ Clean √...
Page 32: Troubleshooting
4. TROUBLE SHOOTING Problem Possible Cause Solution There is no fuel in tank Add fuel in tank Fuel filter obstructed Clean fuel filter Fuel is too dirty Replace fuel There is water in fuel Take out spark plug and dry it Too much fuel in cylinder Mixture ratio is improper Mix properly...
Page 33 Problem Possible Cause Solution Fuel filter obstructed Clean fuel filter and rod Fall short of fuel Adjust carburetor Muffler fouled with oily Clean the oily deposits deposits Piston, piston ring and Replace piston and piston cylinder faulty ring Lo w p o w e r output Conjoint surface of the cylinder and crank cass leak...
Page 34 Problem Possible Cause Solution Fuel exhausted Add Fuel The engine Spark plug fouled with oily Clean the oily deposits s u d d e n l y deposits and short circuit stops High voltage wire Rewire...
Page 35: Terms Of Warranty
5. TERMS OF WARRANTY i) General Liability In lieu of any warranty, condition or liability implied by law, the liability of Dayliff in Ÿ respect of any defect or failure of equipment supplied is limited to making good by replacement or repair (at the Distributors discretion) defects which under proper use appear therein and arise solely from faulty design, materials or workmanship within a specified period.
Page 36 INS540A-12/23...
