anwaut U2RS232-A Quick Start Manual

anwaut
Product Diagram (U2RS232-A)
1
Port/LED/
Connector
1 Serial Port DB-9
• Connect Serial Peripheral Devices
• Connect the USB to Serial Adapter Cable to a Host
2 USB Type A Port
Computer
Pinout Diagram
Regulatory Compliance
FCC - Part 15
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modifications not expressly approved by
StarTech.com could void the user's authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Quick-Start Guide
Function
USB-A to RS232 DB9 Serial Adapter Cable - M/M
Package Contents
• USB to Serial Adapter Cable x1
• Quick-Start Guide x1
Requirements
• Computer with an available
USB Type A port
Installation
2
Install the Driver
1. Download the driver with the following link. https://anwaut.s3.us-west-1.
amazonaws.com/USB-RS232/Anwaut-USB-RS232-Driver.zip
2. Choose the driver and install.
Windows
1. Double-click the downloaded
file and run the Setup file.
2. Follow the on-screen instruc
tions to complete the
installation.
3. Connect the USB to Serial
Adapter Cable to an available
USB port.
Verify Driver Installation (Windows)
1. Navigate to the Device Manager.
2. Under Ports (COM & LPT), right-click Prolific USB-to-Serial Comm Port and click
Properties.
3. Confirm that the Driver is installed and working as expected.
macOS
1. Navigate to System Information.
2. Expand the Hardware section and click USB.
3. Confirm that Prolific USB-to-Serial Comm Port appears in the list.
Warranty Information
This product is backed by a three-year warranty.
Limitation of Liability
In no event shall the liability of Anwaut (or their officers, directors, employees or agents) for any damages (whether
direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any
pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some
states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the
limitations or exclusions contained in this statement may not apply to you.
macOS
1. Double-click the downloaded
file and run the Setup file inside
the folder.
2. Follow the on-screen instruc
tions to complete the
installation.
3. Connect the USB to Serial
Adapter Cable to an available
USB port.
.
Manual Revision: March 22, 2024
