INSTALLATION AND USER GUIDE

JOVIAN™ Intelligent Toilet

ITL-3014T-EW

Read all instructions carefully before proceeding.

SERIAL NUMBER:

• To ensure that timely and e ective service is available for you, please keep this manual for future reference.

REVISED JUNE 14, 2023

USA: www.craftandmain.com | CANADA: www.craftandmain.ca

Table of Contents

Need help?

Do you have a question about the CRAFT + MAIN JOVIAN ITL-3014T-EW and is the answer not in the manual?

Questions and answers

Summary of Contents for FGI CRAFT + MAIN JOVIAN ITL-3014T-EW

Page 1 • To ensure that timely and e ective service is available for you, please keep this manual for future reference. ©2023 FGI Industries, Ltd. I CRAFT + MAIN™, JOVIAN™, and logo designs are trademarks of FGI Industries, Ltd. REVISED JUNE 14, 2023...
Page 2 INSTALLATION AND USER GUIDE INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet JOVIAN™ Intelligent Toilet ITL-3014T-EW ITL-3014T-EW Safety Instruction Cover Power Plug Dryer Function Nozzle control buttons (Posterior & Feminine Wash) Heated Seat Toilet Water Supply Hose Seat Sensor T-valve Toilet Water Supply Angle Valve (Not included)
Page 3: Keys Of Remote Control
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW KEYS OF REMOTE CONTROL NIGHT LIGHT HOT/ COLD On/O of night light Alternate wash with hot and cold water NOZZLE CLEAN Key for nozzle clean Bidet BIDET Used for feminine area wash DRYER Press to dry the washed areas...
Page 4 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW ATTENTION - PLEASE READ CAREFULLY Thank you for purchasing this product from our company. To ensure proper use of this product, please read this manual carefully prior to use. Please retain this manual for future reference. These notes contain important safety-related contents.
Page 5 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW WARNING If the seat or lid is damaged, to avoid harm, be sure to This product must be properly grounded, or a fault or unplug the unit from power, shut o water supply, and short circuit may result in electric shock.
Page 6 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW Avoid installing this product in a bathroom which has WARNING excessive water. Do not spray water onto this product or rinse it with water. Potential danger of electrical shock or ﬁre. Battery safety: •...
Page 7 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW ATTENTION Avoid direct sunlight or putting a heating device Do not use the high and medium levels of seat temperature, water, or dryer for extended periods. close to this product. May cause discoloration. Long-time use may cause burning.
Page 8: Grounding Instructions
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW GROUNDING INSTRUCTIONS This product must be grounded. In the event of an electrical short circuit, a grounded product reduces the risk of electric shock. This product is equipped with a cord having a grounded wire with a grounded plug. The plug must be plugged into a GCFI outlet that is properly installed and grounded.
Page 9: Important Safeguards
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: DANGER– To reduce the risk of electrocution: Do not use while bathing. Do not place or store product where it can fall or be pulled into a tub or sink.
Page 10 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW HARDWARE AND PARTS LIST Remote Control Intelligent Toilet T-Valve with Wax Ring & Holder Assembly Wire Filter & O-Ring Operating instructions Adaptor Floor Bolts x2 with O-Ring TOOLS Drill (with ¼" drill bit) Teﬂon tape Marking pen 23-26mm Adjustable Wrench...
Page 11 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW CONFIRM PRIOR TO INSTALLATION Water Requirements • Minimiun dynamic working pressure is 25 psi (no less than 4.8 gal/min at ﬂowing), and maximum static water pressure is 80 psi (in motionless state). Minimum water pressure required for basic function performance. Key point for measurement of minimum water pressure This method can be used if you have no water pressure measuring apparatus Key point to consider...
Page 12: Installation Instructions
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW INSTALLATION INSTRUCTIONS Lift the packaging upwards to expose the toilet According to the following diagrams, put the accessories aside for later use, and then lift the packaging upwards to allow for the toilet to be exposed. (F1) Existing water supply Grounded Angle valve...
Page 13 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW INSTALLATION INSTRUCTIONS Install the intelligent toilet bottom ﬂange anchor screw Turn the ceramic body over laterally and place on a prepared foam surface (F4). By visual measurement, draw a line on one lateral side of Marking Pen the ceramic body point of the drain outlet perpendicular to the plane against the center of ceramic bottom, and the...
Page 14 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW INSTALLATION INSTRUCTIONS Preparing the toilet seat for toilet bowl installation Hold both seat and cover vertical, pull upward to detach them from plastic snap connectors on the ceramic bowl. (F6A + F6B). Lift the seat and move it forward so as to leave space to tighten the ﬂoor bolts.
Page 15 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW INSTALLATION INSTRUCTIONS Installing the toilet bowl onto ﬂoor ﬂange With two people lifting the toilet bowl, slowly lower the bowl onto the ﬂoor ﬂange. Use the guide marking as the toilet reference. Make sure the ﬂoor bolts on the ﬂoor ﬂange completely come through bolt opening on the bottom of toilet bowl by viewing from the back of the seat.
Page 16 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW INSTALLATION INSTRUCTIONS Re-attach toilet seat Shift toilet seat back into position over bowl and align bolt holes in seat to appropriate holes in top of bowl. (reversing steps 6) Press down hard to lock the snap connectors into position. (F8C) Push down...
Page 17 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW INSTALLATION INSTRUCTIONS Connecting the T-valve to water supply angle valve and connecting braided water supply hoses. With the 3/8" male connection facing to the right, apply Telﬂon tape and screw on adapter (supplied). (F9A + F9B) Connect T-valve to male thread on adapter (apply Telﬂon tape to male threads).
Page 18 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW INSTALLATION INSTRUCTIONS Turn on water at water supply angle valve. Turn valve into the ON position and check for any water leaks at hose connections. If any leaks appear, tighten connection until leaking stops. (F10) 110V-120V Plug in the GFCI power cord to the electrical outlet To conﬁrm power is being supplied to the toilet, the...
Page 19: Trial Run
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW INSTALLATION INSTRUCTIONS CONGRATULATIONS! CONGRATULATIONS! The installation of the JOVIAN™ Intelligent toilet is complete. Please keep the Sale Receipt and these instructions for future reference and important information. TRIAL RUN (TRY THE KEYS ON THE REMOTE CONTROL AND THE LATERAL BUTTONS ON THE TOILET TO SEE THAT IT IS WORKING NORMALLY.) Are functions of the product normal? (F13) Are posterior wash and feminine wash (wash strength adjustment and nozzle position adjustment), adjustment...
Page 20: Remote Control Pairing
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW REMOTE CONTROL PAIRING Pairing of the remote control has been completed during the production of the product. In case the remote is not Level indicator working, pair as per below: ﬂickers Unplug the power cord, hold on the stop key until the level F14A Hold on indicator ﬂickers and then let go of the stop key (F14A).
Page 21: Remote Control Functions
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW REMOTE CONTROL FUNCTIONS The Intelligent toilet automatically turns on when it senses body electrostatic induction being applied to the seat. The wash functions and dryer function will not work unless the body sensor on the seat detects body electrostatic induction (F15).
Page 22 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW REMOTE CONTROL FUNCTIONS HOT/COLD Press "Hot/Cold" key, and Hot/Cold function will be enabled or disabled. • In wash mode, press Hot/Cold key to begin alternating 15 seconds hot/ 5 seconds cold. • This function can only be used in washing mode.
Page 23 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW REMOTE CONTROL FUNCTIONS WATER TEMPERATURE Press the "Water Temp" key to adjust water temperature. • The current temperature level will be displayed when the key is pressed for the ﬁrst time. Pressing a second time will adjust the water temperature. Continue pressing until the desired temperature is achieved.
Page 24 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW FUNCTIONS FOR USE NOZZLE CLEAN Press "Nozzle Clean" key. (Dual functions) • The nozzle is extended for removal and manual cleaning. This function can only be used when no body part or other objects are in contact with the seat sensor area.
Page 25: Push Button Functions
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW PUSH BUTTON FUNCTIONS POWER/STOP Press "Power/Stop" key to turn on the device. Hold "Power/Stop" key for 3 seconds to turn o the device. • Water spray wash and dryer can be turned o at any time by pressing Power/Stop button.
Page 26: Additional Functions
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW ADDITIONAL FUNCTIONS UV STERILIZATION Sterilization will run automatically. UV Light • When a person leaves the seat after being seated and using the spray wash function, the UV sterilization will automatically run for 3 minutes. During UV sterilization, the indicator light near the nozzle will be purple.
Page 27 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW OPERATION OF THE MANUAL FLUSH SYSTEM Should a power outage occur, the remote control will not operate the toilet. Lift the seat cover so that the underside is facing you. You will locate the battery compartment as shown in ﬁgure F22.
Page 28: Cleaning And Maintenance
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW CLEANING AND MAINTENANCE To ensure normal use of the product, please clean and maintain the product regularly. Note • Disconnect the power source prior to maintenance, close water supply angle valve and turn o water supply. •...
Page 29: Troubleshooting
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW TROUBLE-SHOOTING When any issue is found If issues arise, read the list below ﬁrst for trouble-shooting tips. If the issues do not resolve, please contact our customer service team. Power Switch Symptom Analysis of Issue Solution Check if the power switch/ socket...
Page 30 INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW TROUBLE-SHOOTING Dryer temperature Symptom Analysis of Issue Solution Check if dryer is set to “o ” Adjust dryer temperature as per the manual Air is cold for warm air setting Check if heating element for warm Contact our Customer Service team for further help.
Page 31: Limited Warranty
FGI shall not be responsible or liable for any failure or damage to its toilet tank trim, plumbing ﬁttings, or china products caused by the use of either chloramines or high concentration of chlorine, lime/ iron sediments and/or other minerals not removed from public water during the treatment of public water supplies or caused by toilet tank type cleaners containing chlorine, calcium hypochlorite, and / or other chemicals.
Page 32: Specifications
INSTALLATION AND USER GUIDE JOVIAN™ Intelligent Toilet ITL-3014T-EW SPECIFICATIONS Rated Voltage 110V - 120V Rated frequency 60Hz Rated consumption power Water intake temperature 59°F/15°C, power 1050W Water intake temperature 39°F/4°C - 95°F/35°C Min. necessary water pressure 25 psi, ensuring a ﬂow of water at least 4.8gal/18L per minute Range of water intake pressure for use Max.
