Pro's Kit SS-596 User Manual

SS-596 Solder Smoke Absorber
SS-596 Solder Smoke Absorber is a portable and desktop smoke eater, easy to place and move, low noise and
long-life service. It is designed to absorb potentially harmful contaminants that are released with the smoke while
soldering for protect the health of operators. with a high-performance fan and an activated carbon filter designed to
absorb flux and lead fumes.
The combination of silicone smoke hood and corrugated pipe facilitates directional adjustment and improves
smoke removal efficiency.
Safety Note
·The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
·Children should be supervised to ensure that they do not play with the appliance.
·Please check this purifier before starting up, confirm if the accessories are complete, and confirm that the voltage
is within the required usable range
Warning
·If the product is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
·Please make sure smoke absorber is disconnected with power supply before taking off the protective apparatus.
Specification
Model
Working voltage
Power
Maximum inhalation volume
Noise
Fan speed
Display method
Plug*
Adapter
Accessory
Size
Weight （Approx）
* Adapters correspond to different plug models: 5SS-596-ADF/5SS-596-ADG/5SS-596-ADA
Features
·Equipped with a multi-layer filtration system designed for rapid purification, making it ideal for soldering and
maintenance applications.
·Compact in size, with a multilayer filter, and powerful airflow.
·Adjustable fan speeds, ranging from 10 to 100, with LED display indicating the current fan speed setting.
·With a flexible hose that can be easily adjusted in terms of length and angle.
·The air purifier operates on low voltage, ensuring both safety and reliability in use.
·Multifunctional in different purposes: filters smoke, dust and odor from soldering work or other conditions.
User's Manual
SS-596F
10-100 (digital setting)
5SS-596-ADF
Input :100V-240V 50/60Hz 0.8A
Primary Filter Cotton x2-----5SS-596-F1
Silicone Smoke Hood x1
Corrugated pipe(Φ64x210mm) x1
SS-596G
DC12V
15W
90 L /min
＜60dB
LED (white light)
5SS-596-ADG
Output :12VDC 2.0A 24W
205x210x90mm
1.28kg
SS-596A
5SS-596-ADA
