www.EVEREST
ref com
.
Owner's Manual for models:
Back Mount Sandwich Prep. Tables
EPBNR1, EPBNSR2, EPBNR2, EPBNWR2, EPBNR3
Drawered Sandwich Prep. Tables
EPBNR1-D2, EPBNSR2-D2, EPBNR2-D4, EPBNWR2-D4, EPBNR3-D2
Sandwich Prep. Tables (mega-top)
EPBR1, EPBSR2, EPBR2, EPBWR2, EPBR3
Back Mount Open top Prep. Tables
EOTP1, EOTPS2, EOTP2, EOTPW2, EOTP3
Side Mount Sandwich Prep. Tables
EPR1, EPR2, EPWR2, EPR3
Side Mount Pizza Prep. Tables
EPPR1, EPPSR2, EPPR2, EPPR3
Drawered Pizza Prep. Tables
EPPR1-D2, EPPR2-D2, EPPR2-D4, EPPR3-D2, EPPR3-D4
A Step Above the Standard
Thank you for selecting an EVEREST product
R
US
C
ISO-9001
Advertisement
Table of Contents
Summary of Contents for Everest EPBNR1
- Page 1 Side Mount Sandwich Prep. Tables EPR1, EPR2, EPWR2, EPR3 Side Mount Pizza Prep. Tables EPPR1, EPPSR2, EPPR2, EPPR3 Drawered Pizza Prep. Tables EPPR1-D2, EPPR2-D2, EPPR2-D4, EPPR3-D2, EPPR3-D4 A Step Above the Standard Thank you for selecting an EVEREST product ISO-9001...
-
Page 2: Safety Notices
Safety Notices Safety Notices REFRIGERATION WARNING - When using your appliance, always follow basic precautions, including the following : Before starting the unit for the first time, When installing the unit, be careful that the make sure the unit is free from all packaging. electrical cord is not under the unit or pressed Packaging left on the unit during operation against the wall. - Page 3 A dedicated circuit of to its own circuit. EVEREST is not responsible for any damage caused by improper electrical connections resulting from electrical power failure, use of extension cords &...
- Page 4 Caution! Caution! REFRIGERATION To prevent electrical shock and damage to Do not use the the electrical cord, please hold electrical cord the plug head or plug if they when plugging are damaged and unplugging in any way. the unit. Do not put your hands under the unit when Avoid installing the unit where it could moving it.
- Page 5 Installation Guide Installation Guide REFRIGERATION Install the unit on a hard and level surface The unit should be positioned at least 7” or the unit could produce undesired noises. away from the wall for proper ventiliation. For side mount units, a 7” space should also be a orded to the left side of the unit or wall.
- Page 6 Maintenance Guide Maintenance Guide REFRIGERATION Door Gasket Cleaning Shelf Cleaning To preserve the life span of the door gasket Periodically remove the shelves from the unit clean the gasket and clean them with mild soap with mild soap and water on and warm water.
-
Page 7: Troubleshooting
Trouble Shooting Trouble Shooting REFRIGERATION BEFORE YOU CALL Please check the following before requesting service Symptom Possible Solutions Condensing unit a. Ensure the electrical cord has fails to start not been disconnected. b. Ensure the unit is turned on. a. Check the door gaskets for proper seal. Cabinet does not b. - Page 8 Shelves Shelves REFRIGERATION Shelves The unit’s shelves are adjustable so that the refrigerated compartment can be configured to suite your needs. Shelf Clip The shelf clip pilasters are spaced and labeled in 1” increments for your convenience. 1” Pilaster To install a shelf, hook the shelf clips into the pilasters by inserting the top part of the clips first and then the bottom.
-
Page 9: Specification
Specifications Specification REFRIGERATION Back Mount Sandwich Prep Tables Back Mount Mega-Top Model EPBR1 EPBSR2 EPBNR1 EPBNSR2 EPBNR2 EPBNWR2 EPBNR3 Capacity( Cu. Ft.) 11.8 18.3 Door(s) Shelves 1/6 x 12 Pans 1/6 x 6 1/6 x 8 1/6 x 12 1/6 x18... - Page 10 Specifications Specification REFRIGERATION Side Mount Sandwich Prep Tables Model EPR1 EPR2 EPWR2 EPR3 Capacity( Cu. Ft.) Doors & Drawers Shelves Pans 1/6 x 8 1/6 x 12 1/4 x 10 1/4 x 12 Compressor (HP) Power (V-Hz-Ph) 115-60-1 115 -60-1 115-60-1 115-60-1 Temp.
-
Page 11: Temperature Setting
Temperature Setting Temperature Setting REFRIGERATION [Analog Temperature Knob Setting] Applicable models: EPBNR1, EPBNSR2, EPBNR2, EPBNWR2, EPBNR3, EPBNR1-D2, EPBNSR2-D2, EPBNR2-D4, EPBNWR2-D4, EPBNR3-D2, EPBR1, EPBSR2, EPBR2, EPBWR2, EPBR3, EOTP1, EOTPS2, EOTP2, EOTPW2, EOTP3 ℉ [Temperature Setting Range] Setting Range Comp. REF ( ℉) - Page 12 Temperature Setting - Continued Temperature Setting - Continued REFRIGERATION [Digital Temperature Setting] Applicable models: EPR1, EPR2, EPWR2, EPR3, EPPR1, EPPSR2, EPPR2, EPPR3, EPPR1-D2, EPPR2-D2, EPPR2-D4, EPPR3-D2, EPPR3-D4 * LED Display Operation of compressor Current cabinet temperature * Control Buttons Power button Temperature setting button Defrost button * How to set desired temperature...
- Page 13 Pan Configurations Pan Configurations REFRIGERATION REFRIGERATION Back Mount Sandwich Preparation Tables EPBNR1 / EPBNR1-D2 [Standard: (6) 1/6 size pans w/ 2 pan dividers] EPBNSR2 / EPBNSR2-D2 [Standard: (8) 1/6 size pans w/ 3 pan dividers] EPBNR2 / EPBNR2-D4 [Standard: (12) 1/6 size pans w/ 5 pan dividers]...
- Page 14 Pan Configurations Pan Configurations - Continued - Continued REFRIGERATION Back Mount Mega-Top Sandwich Prep. Table, Open Top Prep. Table EPBR1 / EOTP1 [Standard: (9) 1/6 size pans w/ 2 pan dividers] EPBSR2 / EOTPS2 [Standard: (12) 1/6 size pans w/ 3 pan dividers] EPBR2 / EOTP2 [Standard: (18) 1/6 size pans w/ 5 pan dividers] EPBWR2 / EOTPW2...
- Page 15 Pan Configurations - Continued Pan Configurations - Continued REFRIGERATION Side Mount Sandwich Preparation Tables EPR1 [Standard: (8) 1/6 size pans w/ 3 pan dividers] EPR2 [Standard: (12) 1/6 size pans w/ 5 pan dividers] EPWR2 [Standard: (10) 1/4 size pans w/ 4 pan dividers] EPR3 [Standard: (12) 1/4 size pans w/ 5 pan dividers]...
- Page 16 Pan Configurations - Continued Pan Configurations - Continued REFRIGERATION Pizza Preparation Tables EPPR1 / EPPR1-D2 [Standard: (4) 1/3 size pans w/ 3 pan dividers] EPPSR2 [Standard: (9) 1/3 size pans w/ 7 pan dividers] EPPR2 / EPPR2-D2 / EPPR2-D4 [Standard: (12) 1/3 size pans w/ 9 pan dividers] EPPR3 / EPPR3-D2 / EPPR3-D4...
-
Page 17: Product Drawings
Back Mount Sandwich Prep. Tables 27 1/2" 35 1/2" 1 1/8" 1 1/8" 1 1/8" 1 1/8" 31 1/2" 12 1/4" 26 1/2" 17" 17" EPBNR1 EPBNSR2 47 1/2" 59 1/2" 71" 1" 1" 1 1/8" 1 1/8" 1 1/8" 1 1/8" 22 3/4"... - Page 18 Product Drawings Product Drawings REFRIGERATION 47 1/2" 59 1/2" 71" 1" 1" 1 1/8" 1 1/8" 1 1/8" 1 1/8" 22 3/4" 22 3/4" 28 1/2" 28 1/2" 26 1/2" 41 1/4" EPBNR2-D4 EPBNWR2-D4 EPBNR3-D2 Back Mount Mega-Top Sandwich Prep. Tables 27 1/2"...
- Page 19 Product Drawings Product Drawings REFRIGERATION Back Mount Open Top Prep. Tables 27 1/2" 35 1/2" 3 1/2" 3 1/2" 31 1/2" 21" 1" 3 1/2" 5 1/2" Top Lid 1 1/2" 5 1/2" 5 1/2" 2 1/2" 2 1/2" 26 1/2" 17"...
- Page 20 Product Drawings Product Drawings REFRIGERATION Side Mount Sandwich Prep. Tables 35 1/2" 47 1/2" 1 1/8" 1 1/8" 1" 1" 31 1/2" 12 1/4" 22 3/4" 17" 17" EPR1 EPR2 59 1/2" 71" 1 1/8" 1 1/8" 1 1/8" 1 1/8" 22 3/4"...
- Page 21 Product Drawings Product Drawings REFRIGERATION 71" 93 1/4" 28 1/2" 28 1/2" 24 3/4" 24 3/4" 24 3/4" EPPR2 EPPR3 Drawered Pizza Prep. Tables 35 1/2" 71" 36 1/2" 33 1/4" 17 1/4" 19 1/4" 16" 3 1/4" 24 3/4" 22 3/4"...
-
Page 22: Critical Information
In this case, contact a local refrigeration company to take care of this for you. 6. Close the front left side panel. The warranty card below must be submitted to Everest within thirty (30) days of purchase. WARRANTY REGISTRATION CARD... -
Page 23: Warranty Certificate
Our obligation under this warranty is limited to a period of three (3) years from the date of original installation or thirty six (36) months after shipment date from EVEREST,... - Page 24 REFRIGERATION REFRIGERATION A S tep Above the S tanda rd 201 W. Artesia Blvd., Compton CA 90220 Tel : 310-323-6586, 800-444-6285 Fax : 310-323-7524, 310-761-1127 Visit our website at www.EVERESTref.com...
