CONTENTS
Gloves
x1
PREPARATION
Clean out all dirt, debris and leaves underneath the solar panel cavity.
INSTRUCTIONS
Roll out the mesh and align the top edge of the mesh along
the side of the solar panel.
3
Hook the fastening rod to the underside of the solar panel
frame. It will have a "Click" sound once it's engaged.
®
Cable Ties
Fasteners
x100
x100
INSTALLATION GUIDE
Installation
Guide
2
Insert the head of the fastening rod through the first mesh
grid below the panel frame.
4
Slide the locking disc onto the rod and push firmly to secure
the mesh tightly.
304 Stainless Steel
PVC Coated Mesh
205mm(H) x 30m(L)
Advertisement
Summary of Contents for VEXO SOLARGUARD PRO
- Page 1 ® INSTALLATION GUIDE CONTENTS Gloves Cable Ties Fasteners Installation 304 Stainless Steel x100 x100 Guide PVC Coated Mesh 205mm(H) x 30m(L) PREPARATION Clean out all dirt, debris and leaves underneath the solar panel cavity. INSTRUCTIONS Roll out the mesh and align the top edge of the mesh along Insert the head of the fastening rod through the first mesh the side of the solar panel.
- Page 2 Still Unsure? Get A Professional. www.vexo.com.au/find-an-installer/ WARRANTY ® Solarguard Pro has a 6 year manufacturer’s warranty against faulty or defective parts only. Warranty does not cover incorrect installation or mishandling of parts. SCAN TO WATCH TUTORIAL VEXO.COM.AU...
