Summary of Contents for Antretter & Huber CAMPERNET FOIL ANTENNA
- Page 1 Installation Instructions...
-
Page 2: Installation Instructions
Installation Instructions Mounting on Plastic or Wood The FOIL ANTENNA from the CAMPERNET set is always stuck ver- Structures made of plastic, GRP or wood are transparent for tically like a picture on the wall on plastic or wooden surfaces. The mobile radio signals like glass for light. -
Page 3: Antenna Cables
Antenna Cables Code A, colour black / 5G diversity Code D, colour bordeaux / LTE + 5G Extension of the antenna cable max. 5 m Recommended cable type for extension: Leoni Dacar 302 Installation Instructions FOIL ANTENNA... - Page 4 FOIL ANTENNA FOIL ANTENNA Stick on Installation location The FOIL ANTENNA is stuck inside the Place the FOIL ANTENNA on the motorhome against the outside wall surface without folds and press it or on a piece of furniture. firmly. Before you stick the FOIL ANTENNA, After this step the installation is completed! you can also test the antenna’s range...
- Page 5 No external WiFi antenna No external WiFi antenna No external WiFi antenna is available in the delivery The FOIL ANTENNA is simply a mobile radio antenna! There is no external WiFi antenna inclu- ded in the scope of delivery. If no additional external WiFi antenna is connected to the router, the WiFi Step 2 antenna setting at the router must be...
- Page 6 FOIL ANTENNA Data Sheet Service 698 MHz to 960 MHz, 1424 MHz to 2170 MHz, 2490 MHz Mobile frequencies to 2690 MHz, 3200 MHz to 3900 MHz More information can be found here: Cellular MIMO www.antretter-huber.com/service Mobile antenna gain max. 5 dBi If you have any questions, please contact us at: WiFi frequencies service@antretter-huber.com...
- Page 7 Antretter & Huber GmbH Irsham 55 94081 Fürstenzell www.antretter-huber.com...
