3CCD Color Camera

CS5800-04 / CS5800P-04

Operation Manual

Thank you for purchasing our CS5800-04 / 5800P-04 CCD color camera.

This operation manual includes some important information such as how to use this

equipment correctly and safely. Please read through this manual carefully. After

reading, keep this manual by the side of your equipment for your future reference.

TOKYO ELECTRONIC INDUSTRY CO., LTD

Table of Contents

Need help?

Do you have a question about the CS5800-04 and is the answer not in the manual?

Questions and answers

Summary of Contents for Teli CS5800-04

Page 1 CS5800-04 / CS5800P-04 Operation Manual Thank you for purchasing our CS5800-04 / 5800P-04 CCD color camera. This operation manual includes some important information such as how to use this equipment correctly and safely. Please read through this manual carefully. After reading, keep this manual by the side of your equipment for your future reference.
Page 2: Table Of Contents
CONTENS HANDRING PRECAUTIONS RESTRICTION FOR USE DISCLAIMER (LIMITED WARRANTY) OTHER INSTRUCTIONS Product Description............6 Features ................6 Configuration ..............6 Designation and workings of each part......7 How to Connect..............9 Operation ................. 11 Function................11 Mode setting on MENU screen........15 Trouble shooting..............
Page 3 BEFORE USE ‑ ‑ ‑ ‑ GENERAL SAFETY INSTRUCTIONS BEFORE USE GENERAL SAFETY INSTRUCTIONS BEFORE USE BEFORE USE GENERAL SAFETY INSTRUCTIONS GENERAL SAFETY INSTRUCTIONS This instruction manual contains important information for the operator (user) and/or people around him/her to avoid personal injuries, or property damages against him/her or people around him/her by using this product correctly.
Page 4 DANGER If any overheating sign is observed, discontinue the use immediately. In the event that smoke, smell, or any other overheating sign is observed, turn its power switch OFF immediately, and remove your plug from outlet. Do NOT try to continue to use this device.
Page 5 CAUTION If the camera is operated in the electromagnetic field, there may be cases where beat noises (vertical, horizontal, or oblique stripes) appear in the video output. In that case, take preventive measures on the electromagnetic-wave generating source so that your camera does not receive the interference by the electromagnetic wave.
Page 6 This product is digital equipment examined comply with FCC Form, Article 15 Class A. This restriction is set for moderate protection from detrimental jamming in operation of the products under industrial condition. Radiant energy of radio frequency occurred in the use may cause the detrimental jamming to the radio communication depending on the install or usage being deferent from the operation manual.
Page 7: Product Description
1. Product Description Model CS5800-04/CS5800P-04 are digital 3CCD cameras employing a 1/3 type 400,000 pixels 3CCD, featuring high resolution images outstanding color reproduction with 750TV lines in horizontal. 2. Features (1) High-resolution with 750TV lines in horizontal (2) Adoption of new developed DSP...
Page 8: Designation And Workings Of Each Part
4. Designation and workings of each part 4.1 Camera head Name Description CCD pickup part Image capturing part Mount Part Fix C-mount lens Camera connecter Connect the attached camera cable 4.2 Camera Control Unit (4-2-1) CCU front POWER CAMERA WHITE BLANCE WINDOW MENU USER...
Page 9 (4-2-2) CCU rear RGB/SYNC OUT Y/C OUT VIDEO OUT DC12V IN Name Description Connect to the monitor and so on with RGB/SYNC OUT RGB/SYNC OUT connecter connecter Model: SDED-9S (Manufactured by HIROSEDENKI) Connect to the monitor and so on with Y/C OUT connecter Y/C OUT connecter Model: 848-01-101(Manufactured by HOSHIDENKI) Connect to the monitor and so on with composite VIDEO OUT (10) VIDEO OUT connecter...
Page 10: How To Connect
5. How to Connect Connect cables as follows in the use of this camera 5.1 Connection between CCU and Camera Head Connect CCU and CH with attached camera cable. Camera Head C-mount lens Camera cable Connecter： Male Connecter： Female CAMERA USER CS5800 4mm or less...
Page 11 5.2 Connection between CCU and peripheral equipment Connect CCU and peripheral equipment BNC cable S terminal cable RGB cable DC12V IN Video monitor Power cable RGB/SYNC OUT Y/C OUT VIDEO OUT DC12V IN CCU rear Caution in the connection ♦ Make sure that the power of this camera and peripheral equipment is turned off. ♦...
Page 12: Operation
6. Operation (1) Refer to the preceding section 5, “How to connect”, and connect the necessary equipment correctly. (2) Turn on the power of the connected equipment. (3) Turn on the power of this camera. (4) After being displayed the video on the video monitor, adjust the lens aperture so that the brightness becomes to be appropriate.
Page 13 7.2 White Balance White Balance mode: MANU (Manual white balance) AUTO (Auto white balance) FULL/PUSH Refer to the section 8-2 (1), “COLOR”, for setting on MENU screen. White Balance mode AUTO mode Description AUTO-LED SET-LED Shoot a white subject and adjust WB on ＭＡＮＵ...
Page 14 7.3 Window The detection area for AUTO WB and ALC operation is set. MAX (Full screen detection) LARGE H and V positions can be set in each window. SMALL Refer to the section 8-2(3), “WINDOW”, for setting on MENU screen. When WINDOW key on CCU front panel is pushed, OFF(MAX)/ON(LARG/MID/SMALL) of window is switched.
Page 15 7.6 User file This camera has 3 kinds of user file being selectable to suit to the shooting condition. User can call up a preset data and set up it immediately by switching the user file with USER key on CCU front panel. And initial factory setting (preset condition) can be loaded with menu screen after changing the setting.
Page 16: Mode Setting On Menu Screen
8. Mode setting on MENU screen Various settings are available via MENU screen displayed on the video monitor of this camera. The contents, which is set once, is recorded in the selected user file (1, 2 or3) even though the power is turned OFF.
Page 17 8.2 How to change the each setting item Refer to the section 8-1, “ Display of MENU screen”, to display the setting page which you want to change. Adjust the cursor to the setting screen, which you want to change, and then, change the setting value with LEFT/RIGHT key.
Page 18 (8-2-2) COLOR (Page for White Balance mode setting) ＣＯＬＯＲＣＯＬＯＲＣＯＬＯＲＣＯＬＯＲＣＯＬＯＲＣＯＬＯＲＣＯＬＯＲＣＯＬＯＲＭＭＭＭＭＭＭＭＡＡＡＡＡＡＡＡＮＮＮＮＮＮＮＮＵ...
Page 19 (8-2-4) MASKING (Page for masking setting) ＭＡＳＫＩＮＧＭＡＳＫＩＮＧＯＮＯＦＦＲ−Ｇ＋０００Ｒ−Ｂ＋０００Ｇ−Ｂ＋０００Ｇ−Ｒ＋０００Ｂ−Ｒ ...
Page 20 (8-2-6) OPTION (Page for option setting) ＯＰＴＩＯＮＮＥＧ／ＰＯＳＮＥＧＰＯＳＤＴＬＯＵＴＯＮＯＦＦＧＳＹＮＣＯＮＯＦＦＲＳＨＡＤ＋０００ＢＳＨＡＤ＋０００ Setting Page: ＯＰＴＩＯＮ Initial Item Variable range Description Factory...
Page 21: Trouble Shooting
・Is the monitor adjusted correctly? ・Does the connector for camera cable become loose? Noise is occurred. ・Is there some equipment generating strong magnetic field in peripheral environment? 10. Specification Model CS5800-04 CS5800P-04 １ Image sensor Interline CCD ・Image size 1/3 type ・Chip size...
Page 22 １０ Subject illumination ・Standard 2,000 lx、Ｆ8、3,000Ｋ・Minimum 8 lx, F2.2 １１ S/N 58dB １２ Resolution ・H resolution 750 TV lines ・V resolution 350 TV lines 430 TV lines １３ Gamma ON/OFF １４ White balance FULL AUTO / ONE PUSH AUTO / MANUAL ・Color temperature control From 2,250 K through 6,000 K range...
Page 23: External-View Drawing
11. External-view drawing 11.1 Camera head...
Page 24 11.2 CCU...
Page 25 Kansai Branch: Nitto Building, 2-1-1 Sakaemachi-dori, Chuo-ku, Kobe, Hyogo, 650-0023, Japan Phone: +81-078-321-3461 Fax: +81-078-321-3463 Fukuoka Office: Yen building, 2-7-21, Hirao, Chuo-ku, Fukuoka, 810-0014, Japan Phone: +81-092-523-3395 Fax: +81-092-523-3397 URL: http://www.teli.co.jp The design and specification is subject to change without notice. Date of issue: 2002-07 Ver.1.0...
