Lightest | Smallest Footprint | Bluetooth | Automatic Heating | Built in Canada
Page 3 - Safety / Equipment / Chemistry / Installation / Storage / Discharge
This user manual was created by Royer Batteries Corp. and contains important information relating to the proper care and maintenance
of your lithium battery. This manual only applies to Royer Batteries lithium battery products. It does not apply to other lithium batteries
or chemistries. Please read through the guide in detail before installing and using your new lithium battery. Reading this guide in its
entirety will help you achieve high performance and long life from your lithium battery investment. We are here to help you anytime!
Should you have any questions concerning safety precautions, installation or the use of your lithium battery, please contact us:
Smarter | Smaller | Lighter | Better
ROYER BATTERIES
MICRO BATTERY MANUAL
Thank You For Your Support!
Page 1 - Intro / Contact
Page 2 - Quick Feature / Installation / Troubleshooting
Page 4 - Battery Charging
Page 5 - BMS / Lifetime & Recycling / State of Charge
Page 6 - App Feature
Page 7 - RS485 Port / LCD Features
Page 8 - Warranty
Page 9 - Liabilities Disclaimer Exclusions
Email: Info@RoyerBatteries.com
Phone: +1 (604) 724-3248
View our website at www.RoyerBatteries.com
1
Version 2.0
ROYERBATTERIES.COM
Advertisement
Table of Contents
Summary of Contents for RB MC12V320
- Page 1 Version 2.0 ROYER BATTERIES MICRO BATTERY MANUAL Lightest | Smallest Footprint | Bluetooth | Automatic Heating | Built in Canada Thank You For Your Support! Page 1 - Intro / Contact Page 2 - Quick Feature / Installation / Troubleshooting Page 3 - Safety / Equipment / Chemistry / Installation / Storage / Discharge Page 4 - Battery Charging Page 5 - BMS / Lifetime &...
-
Page 2: Installation
Quick Feature & Installation Overview For a quick start, please read this page. For a detailed understanding of your battery features and compatibility with your components, continue reading the entire manual. Get the App Physical Switch Heating Series/Parallel Comm. Ports For Android (Google Play The switch controls The internal automatic... - Page 3 Safety & Equipment / Installation & Connection Storage / Discharge & Charging Safety & Equipment ● LiFePO4 batteries are safe for use indoor as well as outdoors with protection. ● Wear protective gear, use a wrench with a rubber-coated handle, check cables, and tighten connections. ●...
- Page 4 Charging & BMS Parameters Recommended Charging Parameters (For Inverter/Chargers, Charger Controllers (MPPT/PWM), DC2DC, AC Chargers) Battery Voltage 12 V 24 V 48 V Cutout Voltage (Quick Recover) {Slow Recover} 12 V (12.2 V) {12.6 V} 24 V (24.4 V) {25.2 V} 48 V (48.8 V) {50.4 V} Max Allowable Input Voltage 14.6 V...
- Page 5 BMS / Battery Life & Recycling / SOC Battery Management System All Royer Batteries LiFePO4 batteries come with a built-in Bluetooth BMS, which protects against: OVP - Over voltage protection (charging) LVP - Low voltage protection (discharging) OTP - Over temperature protection (charging/discharging) UTP - Under Temperature Protection (charging/discharging) OAP - Over amperage protection (short/overload) If the BMS disconnects the battery due to voltage, temperature, or current limits, check the "protection"...
- Page 6 Phone/Tablet App Bluetooth App (XiaoXiang Electric) Our Bluetooth BMS is made by Jiabaida (JBD). You can download the app by searching in the app store for "XiaoXiang Electric" in the Apple App Store or Google Play Store. The app(s) our BMS uses to connect to and view our batteries is open source.
- Page 7 RJ45 (ethernet) Port for RS485 Communications Our batteries come with a RJ45 port for connection to our accessories. Currently support is only for the RB Smart LCD and no other devices should be plugged into our comms. port. We do recommend getting the optional RB Smart LCD for your battery if you would like to monitor the battery from up to 50' with a wired displayed.
-
Page 8: Warranty
Warranty 10-Year Warranty: In the unlikely event that your battery ceases to function during normal use, we commit to repairing, rebuilding, or replacing it at no expense within the 10-year warranty period. If you encounter any issues, please reach out to us at Info@RoyerBatteries.com for assistance. -
Page 9: Contact Information
Liabilities Disclaimer Exclusions 1. General The information provided by Royer Batteries Corp. on all manuals, websites, & social media is for general informational purposes only. While we strive to keep the information up-to-date and accurate, we make no representations or warranties of any kind, express or implied, about the completeness, accuracy, reliability, suitability, or availability concerning the website or the information, products, services, or related graphics contained on the website for any purpose.
