10 POSSIBLE MALFUNCTIONS AND SUGGESTED REMEDIES
10.1 Possible malfunctions and suggested remedies are given in Table 10.1.
Table 10.1
Malfunction
1. Water does not flow through
the meter
2. Water is flowing through the
Faulty ultrasonic sensors or
meter, but the meter readings
do not increase
10.2 Troubleshooting is carried out in the manufacturer's service center or in a specialised workshop
and the meter is then submitted for verification.
11 TRANSPORTATION AND STORAGE
11.1 Meters in the original manufacturer's packaging can be transported by rail, road, water (except
for sea) and air (in hermetically sealed baggage compartments of the aircraft) with the obligatory
observance of the rules and requirements applicable to these types of transport. Transportation by sea
requires special packaging.
11.2 Packaged meters can be transported at ambient temperatures from –50 to +50 °C and with
100% relative humidity of air at +25 °C.
11.3 During transportation and handling procedures, observe the manipulation signs on the packaging.
The meters should not be exposed to direct atmospheric precipitation.
11.4 The meters must be stored in the manufacturer's packaging in closed, dry premises at ambient
temperature from +5 to +50 °C and with maximum 80% relative humidity of air at +35 °C.
11.5 The air in the premises where the meters are stored should not contain aggressive, caustic and
corrosive fumes.
11.6 Unpacking of meters that are transported in winter must be carried out in a heated room after
keeping them unpacked under normal conditions for 6 hours.
12 DISPOSAL
12.1 At the end of its service life, the product must be disassembled into parts, sorted by material type,
and handed over to a specialised recycling company.
13 MANUFACTURER'S WARRANTY
13.1 The manufacturer guarantees the compliance of the meters with the specified requirements,
provided that the consumer fulfills all the conditions of product storage, transportation, installation
and operation.
13.2 Warranty service life for water meters is five years from the date of sale.
13.3 Meters with mechanical damage and broken seals will not be accepted for warranty maintenance.
13.4 No claims will be accepted if meters are submitted without a completely filled data sheet.
13.5 Send reclamation reports and claim letters to the manufacturing company.
14 ACCEPTANCE CERTIFICATE
Ultrasonic water meter
is manufactured and accepted in accordance with the mandatory requirements of state standards,
current technical documentation and is recognized as suitable for operation.
Date of sale:
Possible cause Remedy
Dismantle the meter, remove
Clogged strainer
the strainer, clean and rinse it
Replace the meter
electronic circuit
Ultrasonic
water meters JWM
USER MANUAL
1 GENERAL INFORMATION
1.1 Intended use
Ultrasonic water meters JWM are designed for the measurement of cold drinking water or hot water in
hot water systems (according to temperature classes), flowing through a fully filled, closed pipe.
The meters are used for accounting, including commercial accounting, of water consumption in the
industrial and municipal sectors, and for technology processes control.
The meters are not intended for use in any area with a potentially explosive atmosphere.
1.2 Operating conditions:
• Ambient temperature from 5 to 55 °С;
• Relative humidity of air from 0 to 100 %;
• Water temperature depending on the temperature class of the meter:
◦ T30 - from 0.1 to 30 °C;
◦ T50 - from 0.1 to 50 °C;
◦ T70 - from 0.1 to 70 °C;
◦ T90 - from 0.1 to 90 °C;
◦ T30/T70 - from 30 to 70 °C;
◦ T30/T90 - from 30 to 90 °C;
• Water pressure from 0.03 to 1.6 MPa;
• Environmental requirements class – В;
• Environmental and mechanical requirements class – М1;
• Environmental and electromagnetic requirements class – Е2.
1.3 The meters meet the requirements of the Directive 2014/32/EU, Directive 2014/30/EU, Directive
2014/53/EU, Directive 2011/65/EU.
Table 1.1.
Example
JWM2,5-110P-LRIR-Т50
JWM2,5-110P-LRIR-Т50
JWM2,5-110P-LRIR-Т50
JWM2,5-110P-LRIR-Т50
JWM2,5-110P-LRIR-Т50
The manufacturer reserves the right to change the design and meter markings that do not affect the
product specifications.
1.5 Meter name, serial number, date of manufacture – refer to section 14.
1.6 Manufacturing company:
TELECOMMUNICATION TECHNOLOGIES LLC
Manufacturer's address:
1, Mytna Sq., Odessa, 65026, Ukraine
Phone: +380 48 759-09-09
E-mail: sales@jooby.com.ua, www.jooby.eu
2 SPECIFICATIONS
2.1 Meter specifications are given in Table 2.1.
Table 2.1
Parameter names
Nominal diameter DN, mm
Permanent flow rate Q , m 3 /h
3
Overload flow rate Q , m 3 /h
4
Transitional flow rate Q , dm /h
3
2
Minimum flow rate Q , dm /h
3
1
Sensitivity threshold, dm /h
3
Disabling transport mode after minimum flow rate, dm
Measurement range R = Q /Q
3 1
Ratio Q /Q
2 1
Water temperature class according to EN ISO 4064-1
Flow disturbance immunity class according to EN ISO 4064-1
Counter indication range, m
3
Actual scale interval, m
3
Accuracy class according to EN ISO 4064-1
Maximum permissible error for the upper flow rate zone
(Q ≤ Q ≤ Q ), %
2 4
Maximum permissible error for the lower flow rate zone
(Q ≤ Q ≤ Q ), %
1 2
Maximum admissible pressure, bar
Pressure loss class according to EN ISO 4064-1
Installation orientation
Backflow
Ambient temperature, °C
Relative humidity, %
IP rating according to EN 60529
Climate and environmental requirements class according to EN ISO 4064-1
Environmental and mechanical requirements class according to the
requirements of the Directive 2014/32/EU
Description
Nominal flow rate Q3: 2.5 – 2.5 m /h;
3
4 – 4 m /h;
3
6.3 – 6.3 m 3 /h.
Installation length: 110 – 110 mm;
130 – 130 mm;
150 – 150 mm.
Material of the hydraulic component:
Р – Polymer;
В – Brass.
Communication technology: LR – LoRaWAN®;
IR – Infrared output pulse for
the verification procedure.
Temperature class:
T50, T70, T90, T30/T70, T30/T90 – corresponding
temperature class;
without designation - T30.
Parameter values
JWM2,5
JWM4
15 20
2.5 4
3.125 5
16 25.6
10 16
1 1.6
3 4 6
R250
1.6
Т30, Т50, Т70, T90, Т30/Т70, Т30/Т90*
U3, D3
999999
0.001
2
±2 for temperatures from 0.1to 30 °C
±3 for temperatures greater than 30 °C
±5 regardless of temperature
range
16 (МАР16)
Δр 40
H, V, H/V
Backflow counting in a separate
counter
5 ... 55
0 ... 100
IP68
B
M1
JWM6,3
25
6.3
7.875
40.32
25.2
2.52
8
