Summary of Contents for Hyundai Electric HGNS-UT2
- Page 1 Charging Motor Installation manual Low & Medium Voltage Circuit Breaker Sep. 20. 2022...
- Page 2 Draw out body Draw out body of ACB from the cradle. 크래들에서 본체를 꺼내주세요.
- Page 3 Open front cover Loosen both bolts by using (+) driver. 커버 볼트(2개)를 풀어주세요. (+)PH SCREW,M6 (+)자 드라이버 (+) driver...
- Page 4 Open front cover Let down the charging handle and disassemble main front cover. MAIN FRONT COVER 커버를 분리해 주세요. 차징 핸들 CHARGING HANDLE...
- Page 5 Install Rachet #4. Insert the large ratchet in the motor unit into the right side of the handle. Please put the gear on the right side. 모터unit 에 들어 있는 커다란 Rachet 을 핸들 우측에 끼워 주세요. 기어 쪽을 Rachet 우측으로...
- Page 6 Remove Bolts Full Snap Shot Reference Picture When Installing Rachet 라쳇 설치 ‘V’ Slot 참고 사진 Put the spring and small ratchet in the motor unit. Raise it with the gear facing up. Place the ‘V’ Protrusion ratchet in the slot. 모터unit 에...
- Page 7 Cable#1 Connection Full Snap Shot Connect 1 to T1 and 2 to T2 according to the number of cables covered by the blue tube on the body. 본체에 있는 파란색 튜브로 씌워져 있 는 케이블을 숫자에 맞추어 1은 T1에 2 는...
- Page 8 Connect To ACB Body Please check direction of the motor ratchet and insert it into the handle. Reference Picture When Insert Rachet 모터 Rachet 방향을 숙지후 핸들에 끼 라쳇 설치 참고 사진 워 주세요.
- Page 9 Tighting Bolts Top view Side view Bolt Tight the 2 bolts to the motor unit. Please refer to the location. *5mm T-wrench Bottom view 모터unit 에 붙어 있는 볼트 2개를 조 여 주세요 Bolt *5mm T-렌치...
- Page 10 Cable#2 Connection Cable Connect the connector on the main body to the motor connector. You can match the Connector colors. 본체쪽 커넥터와 모터 커넥터를 연결 합니다. 색깔을 맞추어 끼우시면 됩니 다.
- Page 11 Tie Cable #10. Group the cable with the cable tie. Handle 케이블 타이로 케이블 정리를 합니다. Cable Tie...
