Comau MATE-XB Quick Reference

MATE-XB
Quick Reference
HAND BOOK WARNINGS
Make adjustments when the device is not worn and disabled.
Do not put your fingers:
• between the box containing the assistive
mechanism and the thigh link
• near the hinge of the thigh link
REGULATIONS & ADJUSTMENTS
Read the handbook carefully before wearing the device for the first time

PELVIC BELT HEIGHT

Open the straps and Set plastic elements to Close straps and place
Remove the hip pads remove plastic elements the preferred height the hip pads on them

PELVIC BELT WIDTH

Unfasten the webbing Close the strap and
Set the belt width by sliding
and open the strap tighten the webbing
belt through the loop

BACK LENGTH

ASSISTANCE ENABLING

Check that the indicator «I» is within the «0-I» range, then
Insert
rotate the handle from «0» to «I»
Pull the spring button back

ASSISTANCE LEVEL SETTING

Insert
Do not jump from 5 to 1 or
from 1 to 5
Set and close, ensuring
Not OK
that the spring button is
Find your key 6mm in the
in the selected hole
box. Make sure to insert the
Regulate from 1-5 level of assistance
key completely
