Summary of Contents for SIRAIR FM-1209Z
- Page 1 Curtain (Cross Flow) User Guide...
- Page 2 NOTE: Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with these instructions could result in personal injury and/or property damage. Retain these instructions for future reference.
- Page 3 The air curtain shall be equal to or greater than the width of the opening. 3. Install the mounting plate above the opening. (PIC2) 4. Align the tabs on the rear of the unit with the slots provided on the wall mounting plate. The bottom flange on the unit must also drop in the bottom channel of the wall mounting plate.
- Page 4 Installation sizes The external dimensions and install the size: (mm) MODEL FM-1209Z FM-1210Z 1000 FM-1212Z 1200 FM-1215Z 1500 FM-1218Z 1800 FM-1220Z 2000 Technical parameter Item Rated Rated Input Mounted Impeller Noise Unit Size Package size Voltage Frequency Power volume velocity...
- Page 5 MAINTENANCE To reduce the risk of fire, electrical shock or injury to persons, observe the following: A. Maintenance is to be performed only by qualified personnel who are familiar with local codes and regulations and are experienced with this type of product. B.
