Summary of Contents for DABBSSON DBS5300B
- Page 1 Dabbsson DBS5300B Extra Battery User Manual...
- Page 2 Read all safety tips, warning messages, terms of use, and disclaimers carefully. Refer to the terms of use and disclaimer at https://www.dabbsson.com and stickers on the product before use. Users take full responsibility for all usage and operations. Familiarize yourself with the related regulations in your area.
-
Page 3: Table Of Contents
3. Getting Started 3.1 Product Details 3.2 LCD Screen 3.3 General Product Usage 3.4 AC Charging 3.5 Solar Charging 3.6 Using Extra Battery DBS5300B 4. FAQs 5. Troubleshooting 6. What’s in the Box 7. Storage & Maintenance 8. Declaration of Conformity... -
Page 4: Specifications
1. Specifications General Info Net Weight Approximately 42.9kg（94.6lbs） Dimensions 533x305x393mm (21x12x15.5in) Capacity 5320Wh (51.2V 104Ah) Certification ETL CE FCC PSE UKCA WEEE ROHS Battery Info Cell Chemistry LiFePO4 Cycle Life 4000 cycles to 80%+capacity Environmental Operating Temperature Optimal Operating Temperature 20℃~30℃(68℉~86℉) Discharge Temperature -10℃~45℃(14℉~113℉) -
Page 5: Safety Instructions
6. Do not use unofficial components or accessories. If you need to replace any components or accessories, visit official Dabbsson channels to check for relevant information. 7. When using the product, follow the operating environment temperature specified in this user manual. -
Page 6: Getting Started
2.2 Disposal Guide 1. If conditions permit, make sure that the battery is fully discharged before disposing of it in a designated battery recycling bin. The product contains batteries with potentially dangerous chemicals, so it is strictly prohibited to dispose of it in ordinary trash cans. For more details, please follow the local laws and regulations on battery recycling and disposal. -
Page 7: General Product Usage
3.2 LCD Screen Input Power Output Power Extra Battery Indicator Remaining Battery Percentage Error Code Low Temperature Warning High Temperature Warning Overload Warning Fan Indicator Remaining Charge/Discharge Time 3.3 General Product Usage Short Press to Turn On Long Press to Turn Off... - Page 8 Dabbsson fast charge technology is specifically for AC charging, offering 1800W of max input power. You can control the charging power through the Dabbsson App. The default max input power for the AC charging speed is 600W. The AC charging is available when connecting to DBS3500.
-
Page 9: Solar Charging
Solar Charging Users can connect solar panels in series as shown in the figure to recharge the product. The product supports 12-150V DC input, 25A max current, and 2400W max charging power. The solar charging is available when connecting to DBS3500. Connection with Solar Panel MC4 Connection Connect XT60 Port... - Page 10 3. Turn off the Extra Battery DBS5300B before connecting or disconnecting it. 4. Do not touch the metal terminals of the Extra Battery DBS5300B connector. If the metal terminals need to be cleaned, gently wipe them with a dry cloth.
-
Page 11: Faqs
4. FAQS 1. What type of batteries does this product use? This product uses high-quality LiFePO4 battery. 2. How long does it take for the product to charge my devices? The charging time is shown on the product’s LCD Screen, which can be used to estimate the charging time of most appliances with stable power usage. -
Page 12: Troubleshooting
If the Alarm Prompt shows on the product LCD screen during use and does not disappear after a restart, please stop using it immediately (do not try to charge or discharge).If you require any other assistance, please contact Dabbsson Customer Service. -
Page 13: What's In The Box
(please find more information on requirements in the user guide). Improper connection of MC4 connector to your device could damage the device. Dabbsson does not take responsibility for equipment failure due to personal misoperation. Please confirm the positive and negative poles of your solar panel. -
Page 14: Declaration Of Conformity
2011/65/EU (EU)2015/863 REACH Regulation: 2006/1907/EC Read the declaration of conformity and access the download link here at https://dabbsson.com/pages/eu-compliance Have any question? Chat with a specialist today. US: support.us@dabbsson.com EU: support.eu@dabbsson.com +1 888 850 9503 Mon-Fri 9am-5pm (PST) Follow Us @Dabbsson_Global...
