- Page 1 PÉRGOLA PLUS PÉRGOLA PLUS USER/INSTALLER MANUAL v1.0 REV. 01/2024...
-
Page 2: Table Of Contents
This product complies with Directive 2011/65/EU of the European Parliament and of the Council, of 8 June 2011, on the restriction 02. THE AWNING of the use of certain hazardous substances in electrical and PERGOLA PLUS electronic equipment and with Delegated Directive (EU) 2015/863 TECHNICAL CHARACTERISTICS from Commission. -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. • If the power cable is damaged, it must be replaced by the Read all instructions carefully before beginning the installation/ manufacturer, after-sales service or similarly qualified personnel usage procedures and keep this manual in a safe place that it can... - Page 4 01. SAFETY INSTRUCTIONS the power supply cable. Please note that all the cables must enter conditions have been met. the control board from the bottom. • In the event of tripping of circuits breakers of fuse failure, locate • If the automatism is to be installed at a height of more than 2,5m the malfunction and solve it before resetting the circuit breaker or from the ground or other level of access, the minimum safety and replacing the fuse.
-
Page 5: The Awning
ORIENTATION AND CONSTRUCTION When the width, projection or area is greater than the defined maximum, you can group several modules Module Structure PERGOLA PLUS awning in both width and projection to form a larger awning. (Motor + fabric) (Modules + Structure) -
Page 6: Components
02. THE AWNING COMPONENTS 01• Projection profile 02• Width profile 03• Awning guide 04• Leg 05• Ground fixing plate 06• Union of frame profiles (60x60mm) 07• Union of frame profiles (50x50mm) 08• 1st blade support 09• 1st blade support fixing plate 10•... -
Page 7: Installation
03. INSTALLATION FIXING THE STRUCTURE DRILLING THE PROFILE FOR WALL FIXING Make the markings on the profiles you want to fix to the wall according to diagram 1A. Drill holes along the profiles with Ø10mm and then enlarge the hole inside the profile with Ø20mm, according to diagram 1B so that when tightening, apply force on the outside of the profile. -
Page 8: Assembling The Awning 7B
03. INSTALLATION 03. INSTALLATION LED LIGHTING KIT ASSEMBLY ASSEMBLING THE AWNING PLACEMENT THE FIXING PLATES Place the lateral support fixing plates in the , the fixing plates in the guides. PLACEMENT OF TROLLEYS Place and slide the trolleys onto awning , on the guides. -
Page 9: Motor Assembly 8A
03. INSTALLATION 03. INSTALLATION MOTOR ASSEMBLY COVER ASSEMBLY Place the cover on top of the awning covering the entire width. Use the 8 DIN7504 self-drilling screws provided to attach the cover to the structure. MOTOR FITTING Fit the 12mm diameter pin into the support , fixed to the projection profile on the motor side. -
Page 10: Troubleshooting
03. INSTALLATION 04. TROUBLESHOOTING INSTRUCTIONS FOR DRAINING WATER INSTRUCTIONS FOR CONSUMERS AND SPECIALIZED TECHNICIANS It is important to create drainage points in the PÉRGOLA PLUS to prevent water from accumulating inside the frame. Follow the following instructions and recommendations. Problems Causes Solutions DRILLING... -
Page 11: Maintenance
05. MAINTENANCE MAINTENANCE TASKS AND FREQUENCY Frequency Date Date Date Date Date Date Date (months) 12 24 36 1. MECHANICAL OPERATION Fastening the awning to the structure Lubricate all points with movement and articulation Noises from all mechanics 2. ELECTRICAL FUNCTIONING Power supply protected by circuit breaker and ground wire Check the range of remote controls and battery status Analyze whether the motor stops due to effort or limit switch...
