- Page 1 ARCTIC HAYES 3-IN-1 THERMOMETER WITH CLAMP, STEM PROBE & INFRARED User Manual A998724 Before using the instrument, please read this manual carefully, and save for future reference.
- Page 2 Introduction This device is a non-contact (infrared) thermometer and contact (probe & clamp) thermometer. Simply aim the thermometer at the target and press the measurement button to display the surface temperature. The distance to target ratio is 1:1 therefore the thermometer should be positioned as close to the target as possible.
- Page 3 Operation Wide Range Application Food preparation, Safety inspectors, Plastic molding, Asphalt, Marine and Screen printing, measure ink and Dryer temperature, HVAC/R, Diesel and Fleet maintenance. ºC or ºF Mode To change this thermometer from ºC toºF or fromºF to ºC, when you using infrared to measuring, firstly turn the instrument on by pressing the “IRT”...
- Page 4 Operation The “MIN” or “MAX” icon will flash, then press the “IRT” button to confirm the “MIN” or “MAX” mode. The thermometer will display the MIN or MAX reading only. LOCK Mode The LOCK mode is particularly useful for continuous monitoring of temperatures . To utilize this thermometer’s LOCK mode.
- Page 5 Operation Clamp or Probe Mode To change this thermometer from Clamp to Probe or from Probe to Clamp,firstly turn the instrument on by pressing the “ON/OFF” botton .If you open the Probe,this thermometer will measuring by Probe,and when you close the Probe ,the thermometer will measuring by Clamp.
- Page 6 Specification General specification IR TemperatureRange -35°C~260°C (-31°F~500°F) Response Time Less than 500ms Infrared Accuracy ±2% of reading or ±2°C / ±4°F Optical Resolution 1:1 distance to spot size Emissivity Adjustable 0.10 ~ 1.00 Probe Temperature Range -40°C to 260°C ( -40°F to 500°F ) Clamp Temperature Range -40°C to 230°C ( -40°F to 446°F ) Temperature Accuracy...
-
Page 8: Limited Warranty
Do not dispose of the unit with the usual domestic refuse. Do not burn the product. Arctic Hayes Ltd Arctic Hayes Ltd 9 Millshaw Park Ave | Leeds Ipco B.V, Spinel 400 LS11 0LR | United Kingdom 3316 LG Dordrecht sales@arctic-hayes.com...
