FHSCP-UNV-10W-L-SD

Emergency LED Driver

Emergency LED Driver
Universal Voltage: 120-277VA
Output Voltage Range: 15-55V
Output Current: 55-666mA
Input Voltage / Frequency
Input Current
Input Power
Standby Power
Input Power Pass-Through Rating (AC Driver Line)
Max Output Rating (LED+ LED- Terminal)
Driver Type
Output Current Rated
Output Voltage Range
Output Power
Number of Output Channels
Input Surge Protection
RFI/ EMI
Output Type
Battery Type
Battery Voltage
Battery Capacity Available
Battery Recharge Time
Battery Discharge Time
Rated Ambient (ta)
Protections
Sound Rating
Humidity
Safety Standards
Service Life
Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060.
Specifications subject to change without notice.
Output Wattage: 3W-10W (Factory default 10W)
C, 50/60Hz
Output Type: LED Class 2
Number of Output Channels: 1 Channel
Dry and Damp
120-277VAC , 50/60Hz
0.12A
6.5W TBD
<0.85W
2A
3A, 55V Max
Constant Power
666mA Max.
15 - 55VDC
10W Max
1 Channel
3KV/6KV Ring wave
FCC Part 15A
LED Class 2
Ternary Lithium Battery
10.8V
3350mAh
24 Hours Max
1.5 Hours Min.
0°C to 55°C (32°F to 131°F)
Over / Under Voltage Protection
Output Open Circuit Protection
A
5% - 95%
UL 924, UL 1310, CSA C22.2 No.141-10
50,000 Hours
5 Years From the date of manufacture when properly installed
TBD
TBD
order@fulham.com www.fulham.com
2023-XXX Rev A
Page 1 of 7
