MCRWAR01
AIR ROWER PRO
Assembly Instructions / Owner's Manual
READ ALL ASSEMBLY INSTRUCTIONS AND SAFETY PRECAUTIONS BEFORE
IMPORTANT:
USING THIS PRODUCT.REFERENCE ALL SAFETY GUIDELINES AND WARNING
LABELS. RETAIN PRODUCT LITERATURE FOR FUTURE REFERENCE.
PROPERLY WARM UP AND STRETCH BEFORE EXERCISING.IF YOU FEEL PAIN
SAFETY:
OR DIZZINESS AT ANY TIME WHILE EXERCISING, STOP IMMEDIATELY AND
CONSULT YOUR PHYSICIAN.
1
Advertisement
Summary of Contents for MasterKraft MCRWAR01
- Page 1 MCRWAR01 AIR ROWER PRO Assembly Instructions / Owner’s Manual READ ALL ASSEMBLY INSTRUCTIONS AND SAFETY PRECAUTIONS BEFORE IMPORTANT: USING THIS PRODUCT.REFERENCE ALL SAFETY GUIDELINES AND WARNING LABELS. RETAIN PRODUCT LITERATURE FOR FUTURE REFERENCE. PROPERLY WARM UP AND STRETCH BEFORE EXERCISING.IF YOU FEEL PAIN...
-
Page 2: Safety Warning
MCRWAR01 Assembly Preparation To ensure ease of product assembly, please take time to verify the size and quantities of all required assembly hard- ware. Use the itemized parts listing and hardware chart for reference. The product assembly process has been documented in easy to follow steps. - Page 3 MCRWAR01...
- Page 4 MCRWAR01 NOTE: Before assembly please lay out all pieces accordingly to ensure you are not missing any items. PLEASE BE CAUTIOUS as some components may be sharp and can cause harm if not handled correctly. Always use safety measurements when assembling...
- Page 5 MCRWAR01...
- Page 6 MCRWAR01 Step 3. finish securing Console (G) onto Forward Base (A) please attach Place Holder (H). Place Holder (H) will break up into 2 components (H1) and (H2). These components will rejoin together once attached onto forward Base (A). Once rejoined please secure with 2 screws (J9) and 1 screw(J4).
- Page 7 MCRWAR01 Step 5. To install foot pedals (E1) and (E2) into (A) Forward Base join the together by Steel Bracket (K). Steel Bracket (K) should slide into place of Foot Pedal (E1). Once placed secure with 2(J5)bolts,2(J10)spring washer and 2(J0)nuts.
- Page 8 MCRWAR01 Step 6.
- Page 9 MCRWAR01 Rower Storage: To fold the Rower, simply pull the PULL PIN (J8) located between Forward Base (A) and Base Railing (B). This will cause Forward Base (A) to drop down and will allow you to raise Base Railing (B) so that Forward Base Leg (C) will be facing outward. When you are ready to unfold the Rower again, simply pull on PULL PIN (J8) while holding onto Base Railing (B).
- Page 10 MCRWAR01...
- Page 11 MCRWAR01...
- Page 12 MCRWAR01 NAME SPECIFICATION NAME SPECIFICATION Main Frame Assembly Sensor Base Cover Flywheel Fan Assembly Ball Head Tapping Screw M4*12mm A2-1 Sensor Cover A2-2 Tube Outer Chain Cover Φ31.8 One-Way Bearing FC 2016 Handle-bar 1/4” Chain Iron Washer S-type Buckle Chain Connecting Spacer...
- Page 13 MCRWAR01 Left Pedal Rest Chain Connecting Axial Right Pedal Rest Φ8X156mm Axial of Moving Wheel Adjust Pedal Pad Left Pedal Rest Cover Aluminum Rail Right Pedal Rest Cover Seat Carriage Roller Cover M4*8mm Seat Carriage Cover Seat Carriage Wheel PR-608ZZ(BMC) Φ8*Φ12*2mm...
