Page 3
Part Part Part Side Bracket Foot Block ST5*16 Wooden Screw Foot Glide Power Adapter Fixing Screen Holder Screw Card Power Adapter Beam Center Rail Control Box Frame Right M8*12 Screw Handset Frame Left M6*10 Screw Power Cord Lifting Column Right M6*14 Screw Connecting Cable ST5*20 Wooden Screw...
Page 4
STEP 1: Prepare the four (4) lifting columns as below picture shows. STEP 2: Using the supplied allen wrench, insert four (4) M8*12 screws (part 12) to fix the beams (part 3) and lifting columns as below picture shows. Do the same for the other beams (part 3) and lifting columns with four (4) M8*12 screws (part 12).
Page 5
STEP 4: Slide the center rail (part 11) into the two (2) frame ends with eight (8) M6*10 screws (part 13)ensuring: a) the slots in the center rail (part 11) face inward b) the slots in the center rail (part 11) are closer to the top edge when the assembly is upside down.
Page 6
STEP 7: Attach the desk base to the underside of the desktop with ten (10) ST5*20 wooden screws (part 15). Install the control box (part 19) underside of the desktop with two (2) ST5*20 wooden screws (part 15). Install the power adapter fixing (part 17) with two (2) ST5*16 wooden screws (part 16) . Install the handset (part 20) with two ST5*16 wooden screws (part 16).
