HEATIT ZM
DIMMER
Installers manual
TABLE OF CONTENTS
1. Introduction
2. Statement regarding products from multiple
manufacturers
3. Behaviour within the Z-Wave network
QR: UPDATED
DOWNLOADS AND
INFO FOUND HERE
Firmware version
Document version
FW 1.0
2023-A
Article no.
Document date
14 444 42
01.03.2023
1. INTRODUCTION
Heatit ZM Dimmer is an inwall dimmer for installation in
European electrical wall boxes. The dimmer enables the user
to control light sources from the Z-Wave™ network and/or an
external switch.
The Heatit ZM Dimmer works on most low loads of both
LEDs and other light fixtures without causing flickering. When
connecting low loads it is recommended to use a bypass.
The dimmer may be connected to two external switches
that can be used to control the lights, associated devices and
scenes.
Heatit ZM Dimmer has power metering and it gives you the
real time information about your power consumption.
NB! DIMMING
Dimming may be challenging, and we recommend checking
the compatibility of different light sources before installation.
We are happy to answer any questions.
2. STATEMENT REGARDING PRODUCTS FROM MULTIPLE
MANUFACTURERS
Please read this before installation
This device may be used with all devices certified with the
Z-Wave Plus™ certificate and should be compatible with
such devices produced by any manufacturer. Every primary
controller is different depending on the manufacturer, their
target audience and intended use/application. Please review
the functionalities implemented by the primary controller you
intend to use with our Z-Wave Plus certified device to ensure
that it provides the necessary controls to take full advantage of
our product's capabilities.
3. BEHAVIOUR WITHIN THE Z-WAVE NETWORK
This device may be operated within any Z-Wave™ network
with Z-Wave-certified devices from other manufacturers. All
non-battery-operated nodes within the network will act as
repeaters regardless of manufacturer to increase the reliability
of the network. On delivery, the device does not belong to any
Z-Wave network. The device needs to be added to an existing
network to communicate with the other devices within it.
Devices may also be removed from a network. The add/
remove processes are initiated by the primary controller of the
Z-Wave network.
Advertisement
Table of Contents
Summary of Contents for Heatit ZM DIMMER
- Page 1 Installers manual 14 444 42 01.03.2023 The Heatit ZM Dimmer works on most low loads of both LEDs and other light fixtures without causing flickering. When connecting low loads it is recommended to use a bypass. The dimmer may be connected to two external switches that can be used to control the lights, associated devices and scenes.
- Page 2 5. Set the primary controller in add mode Wiring diagram Reset button (security/non-security). 6. Press the reset button on dimmer 3 times in a rapid Switch 2 sequence. The Heatit ZM Dimmer is now included in your Switch 1 Z-Wave network. 2-wire Last/Load 5. ILLUSTRATIONS...
- Page 3 NB! When the device is removed from the gateway, the Released @ x seconds parameters are not reset. To reset the parameters, see ”Factory Figure 2 (fail) reset”. If the button is released before the 3 seconds period, the device will indicate fail by turning RED LED on for 3 seconds.
- Page 4 16. ASSOCIATION GROUPS SHORT DESCRIPTION / DESCRIPTION MULTI LEVEL SWITCH DEVICE DESCRIPTION NAME COMMENT OF VALUE Lifeline. (Normally used by the Z-Wave Controller) Sends: Minimum dim Lowest dim level of the 1% - 98%. - Switch Multilevel Report level dimmer. (Default 15).
- Page 5 20.3 Meter Command Class 21. SUPPORTED COMMAND CLASSES The device supports Meter Command Class Get, and the The following table lists all Command Classes supported by device will only respond on supported electric meter scales: the Z-Wave device. The device supports S0, S2 Authenticated kWh (accumulated) and Watt (instant).
- Page 6 Heatit Controls AB can not be held liable for typographical errors, other errors or omittances in our information. Product specifications may change without further notice. All electrical installations must be carried out by a licensed electrician.
