- Page 1 18V LITHIUM-ION CORDLESS BLOWER ASSEMBLY AND OWNER'S MANUAL WARNING! Read this manual before operating your product.
- Page 2 IMPORTANT NOTES Details Thank you for purchasing your Victa product. Victa prides itself in the quality and performance of all its products. This instruction manual will aid in the assembly, safe operation and maintenance of your product. Please read the following warnings to ensure safety and the long life of your product.
-
Page 3: Table Of Contents
Table of Contents Features & Supplied Items Blower Safety & Handling General safety Assembly Procedures Unpacking Assembly Removing the tube Install & remove the battery Operating Instructions Starting & stopping Operating Maintenance & Care Cleaning Storage Product disposal Maintenance chart Emergency contact Service Troubleshooting... -
Page 4: Features & Supplied Items
FEATURES DEFINITIONS Features & Supplied Items 18V Lithium-Ion Blower Blower Housing Variable Speed Dial Blower Tube Handle Battery Slot Battery Charger (not included with all product) Battery (not included with all product) - Blower Instruction/Safety Manual (not shown) - Battery & Charger Instruction/Safety Manual (not shown) WARNING Do not operate the product if any component is missing or damaged. - Page 5 General Safety • Carefully read all instructions on the machine and in the manual before attempting to assemble and operate the machine. Keep this manual in a safe place for future reference, and consult it regularly. Ensure other users read this manual and are aware of the product safety risks. •...
-
Page 6: Assembly Procedures
ASSEMBLY PROCEDURES Unpacking The Blower is supplied with some components not assembled. To assemble these, proceed as follows: • Carefully remove the product and any accessories from the box. Make sure that all items listed on page 3 are included. •... - Page 7 ASSEMBLY PROCEDURES Installing the Battery NOTE: Refer to figure 3. • Place the battery in the blower. Fig 3 Align raised rib on battery with grooves in the blower’s battery port. Battery Release • Make sure the latch on bottom Latch of the battery snaps in place and that battery pack is...
-
Page 8: Operating
OPERATION INSTRUCTION Stopping The Blower NOTE: Refer to figure 5. Fig 5 • Roll the variable speed dial backward to slow Off Position the speed or Roll it to 0 to stop the blower. Variable • Remove the battery. To ensure the blower is Speed Dial. -
Page 9: Cleaning
Cleaning WARNING To prevent serious personal injury remove the battery from the machine before servicing, cleaning, or removing debris. • Clean the unit using a damp cloth with a mild detergent. • Do not immerse the machine or any part of it in water. •... -
Page 10: Service
Maintenance Chart Refer to the following table for routine maintenance. Features Requirements • • Whole unit Visual inspection • Variable Speed Dial Check operation • • Blower housing Check & clean • Air inlet Check & clean • • Tube Check &... -
Page 11: Troubleshooting
TROUBLESHOOTING Troubleshooting Problem Possible Cause User action Unit will not 1. Tube 1. Clear the blockage following the procedure blow 2. Fan is blocked in the manual. 3. Battery is not seated correctly in 2. Clear the blockage following the procedure the product in the manual. - Page 12 TECHNICAL SPECIFICATIONS Specifications PRODUCT SPECIFICATION Description 18V Cordless Blower Function Blow Motor Type Brushed Motor Motor Specification 18V DC Maximum Motor Speed 18000RPM Maximum Air Velocity 245km/h Maximum Air Volume 98CFM Product Weight (No Battery) 1.4Kg Sound Pressure Level : 80.3dB (A), K: 3dB (A) Sound Power Level (Measured) 94dB (A) Sound Power Level (Guaranteed)
- Page 13 NOTES _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________...
- Page 14 ©2018 Briggs & Stratton Victa is a trademark of Briggs & Stratton Australia Pty. Ltd. ABN 13 006 576 856 All rights reserved. No part of this booklet may be reproduced by any means without prior written permission. All information herein is subject to change without notice.
