VINGLI 3 PIECES WICKER BISTRO SET
ASSEMBLY INSTRUCTION FOR MODELS
WICKER BISTRO
Please contact us via email if parts are missing or damaged, we will
gladly ship your replacement parts free of charge. Please attach your
EMAIL
support@vingli.com
Thank you for purchasing from VINGLI!
Order ID so that we can assist you better.
www.vingli.com
WEBSITE
IMPORTANT
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ
AND KEEP FOR FUTURE
REFERENCE.
Advertisement
Related Manuals for VINGLI WICKER BISTRO
Summary of Contents for VINGLI WICKER BISTRO
- Page 1 VINGLI 3 PIECES WICKER BISTRO SET ASSEMBLY INSTRUCTION FOR MODELS WICKER BISTRO Thank you for purchasing from VINGLI! Please contact us via email if parts are missing or damaged, we will gladly ship your replacement parts free of charge. Please attach your Order ID so that we can assist you better.
- Page 2 Your satisfaction is our highest pursuit. Return Policy VINGLI believes you will absolutely love your 3 pieces wicker Bistro set, but if for some reason you want to return the product, please contact us directly before you decide to return your product to the retailer. Our Customer Service organization can answer most concerns and can assist you with any questions you may have about your new product.
- Page 3 BEFORE STARTING Before Using Product Read each step carefully before starting. It is very important that each step is performed in the correct order. If these steps are not followed in sequence, assembly difficulties will occur. Make sure all parts are included. Most board parts are labeled or stamped on the raw edge.
- Page 4 MODEL & ASSEMBLY TIPS MODEL: WICKER BISTRO. DIMENSION : Outside Dimensions: 91.3"L x 28.3"W x 31.8"H FEATURES : 60% Wood glue with maroon paint 40% powder coated steel and wicker rope. Gross weight: 48.9 Ib. 30 mins Estimated Time for Assembly: Caution 1.This product is designed for home use and not intended for commercial use.
-
Page 5: Part List
PART LIST... - Page 6 PART LIST...
- Page 7 IDENTIFY PARTS - TABLE...
- Page 8 ASSEMBLY STEPS - TABLE New panels & accessories needed in below step. STEP 1 Attach part 9 to the 4 holes of part 10 and make sure that they are perpendicular to each other.Use a allen key to screw parts A and E into the hole.
- Page 9 ASSEMBLY STEPS - TABLE STEP 2 After installing step 1, attach the finished assembly to the 4 holes of part 8. Use the allen key to screw parts B and E into the 4 holes. When the 2 steps have been completed retighten all bolts.
-
Page 10: Maximum Loads
MAXIMUM LOADS This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging instability, collapse, and serious injury. DIMENSION : Outside Dimensions:20’’D x 18.8’’H FEATURES : 80% Wood glue with maroon paint. 20% powder coated steel and wicker rope. Weight : 7.05 Ib/3.2 kg. - Page 11 IDENTIFY PARTS - CHAIR (x2)
- Page 12 PART LIST New panels & accessories needed in below step.
- Page 13 ASSEMBLY STEPS - CHAIR (x2) STEPS 1 : Attach part 1 to part 4 according to 2 pre-drilled holes. Use part A and E to screw into the mounting hole .
- Page 14 ASSEMBLY STEPS - CHAIR ( x2 ) STEPS 2 : Attach part 2 and 3 to the seat part installed in step 1. Take out part B, D, E and use a allen key to screw them into the holes. Finally, please tighten all screws.
- Page 15 ASSEMBLY STEPS - CHAIR (x2) STEPS 3 : After setting up the chair as shown in the picture below, put the cushion and pillow on the chair.
- Page 16 MAXIMUM LOADS This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging instability, collapse, and serious injury DIMENSION : Outside Dimensions : 29.7’’L x 31.8’’H x 25,9’’W. FEATURES : 60% Wood glue with maroon paint. 40% powder coated steel and wicker rope.
- Page 17 FAQs What should I do when there are accessories or hardware missing? Pls feel free to contact VINGLI customer service via www.vingli.com with your order ID, the quantity, and corresponding listing number of missing part. We will send out for you as soon as possible.
