WARNING

Failure to follow all instructions and safety precautions in this

manual, in the vehicle and body manufacturers' manuals and

on the safety decals attached to the vehicle, body and this

product could result in serious injury or death to operators,

service technicians or bystanders and/or damage to property.

DO NOT operate the vehicle or install this product before you

AWTSL10C Camera

READ and UNDERSTAND the vehicle Operation Manual, this

manual and other applicable manufacturers' manuals, and all

safety decals. This product must be installed by certified

technicians/installers familiar with the vehicles on which they

USER MANUAL

will be making the installation.

ISSUED OCTOBER 2018

3E-AWTSL10C-UM-1018

Table of Contents

Need help?

Do you have a question about the 3rd EYE AWTSL10C and is the answer not in the manual?

Questions and answers

Summary of Contents for Dover 3rd EYE AWTSL10C

Page 1 WARNING Failure to follow all instructions and safety precautions in this manual, in the vehicle and body manufacturers' manuals and on the safety decals attached to the vehicle, body and this product could result in serious injury or death to operators, service technicians or bystanders and/or damage to property.
Page 2: Table Of Contents
TABLE OF CONTENTS Camera AWTSL10C ......................................3 Introduction Introduction Introduction ....................................4 Features Features Features ....................................5 Package Contents Package Contents Package Contents ....................................6 Dimensions Dimensions Dimensions ....................................7 Specifications Specifications Specifications ....................................8 Installation Instructions Installation Instructions Installation Instructions ....................................9 Wiring Diagram & Pin Out Wiring Diagram &...
Page 3 USER MANUAL SAFETY PRECAUTIONS Federal Communications Commission (FCC) Statement This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 4 USER MANUAL PRODUCT DOCUMENTATION UPDATES Thank you for purchasing our product. Please read this User Manual before using the product. All product documentation is subject to change without notice. Please go to to get the most current documentation for your 3rd Eye www.3rdeyecam.com products.
Page 5 USER MANUAL AWTSL10C AWTSL10C CAMERA LICENSE PLATE CAMERA USER MANUAL ISSUED OCTOBER 2018 3E-AWTSL10C-UM-1018 Issued October 2018 Copyright 2018, 3rd Eye Printed in U.S.A.
Page 6: Introduction
USER MANUAL AWTSL10C INTRODUCTION 3rd Eye cameras are designed to improve safety during driving by providing high quality images of surrounding areas and obstacles in the vicinity of the vehicle. They will also improve vehicle maneuvering capability by displaying blind spots not normally visible to the driver. Please ensure you read and understand all aspects of this manual before fitting or using your 3rd Eye Camera.
Page 7: Features
USER MANUAL AWTSL10C FEATURES The camera is designed for small car rear view system. It is easy to mount on your car with the bracket being hidden by your license plate. 1. You can use the camera by a DC 12v/200mA power source 2.
Page 8: Package Contents
USER MANUAL AWTSL10C PACKAGE CONTENTS ITEM Camera License Plate Bracket Lip Mount Bracket Wiring Harness Manual Issued October 2018 Copyright 2018, 3rd Eye Package Contents Printed in U.S.A.
Page 9: Dimensions
USER MANUAL AWTSL10C DIMENSIONS Issued October 2018 Copyright 2018, 3rd Eye Dimensions Printed in U.S.A.
Page 10: Specifications
USER MANUAL AWTSL10C SPECIFICATIONS Sensor Type 1/4" CMOS Led's Illumination 0.5 LUX Viewing Angle 170 degrees Mirror Image Normal View Water/Debris-Proof IP67 Audio Power Supply 9-16V DC Current <50mA Working Temperature -30°C - +70°C Dimensions D 1.4" (35mm) x W 7.7" (196mm) x H 1.4" (35mm) System NTCS TV Lines...
Page 11: Installation Instructions
USER MANUAL AWTSL10C INSTALLATION INSTRUCTIONS STEP 1 Remove the rear license plate. STEP 2 Place the bracket behind the license plate and line up the holes. Fasten the camera mounting bracket and the license plate to the vehicle using the anti-theft screws provided. Determine the mounting location that best suits your needs. Be sure to verify that your installation plan complies with local laws and regulations.
Page 12: Wiring Diagram & Pin Out
USER MANUAL AWTSL10C WIRING DIAGRAM AND PIN OUT Issued October 2018 Copyright 2018, 3rd Eye Wiring Diagram & Pin Out Printed in U.S.A.
Page 13: Checking And Settings
USER MANUAL AWTSL10C CHECKING AND SETTINGS 1. Check the function of the camera after you have connected it to a monitor. 2. Align the camera using the image on the monitor to help you: a. The monitor image should show the rear or the bumper of the vehicle at the bottom edge of the screen. b.
Page 14: Cleaning And Caring
USER MANUAL AWTSL10C CLEANING AND CARING Clean the camera with a soft, damp cloth from time to time. NOTICE Do not use sharp or hard objects to clean the device as these may damage the device. Issued October 2018 Copyright 2018, 3rd Eye Cleaning and Caring Printed in U.S.A.
Page 15: Index
INDEX dimensions features installation instructions 4-PIN DIN plug adapter introduction package contents specifications Issued October 2018 Copyright 2018, 3rd Eye Index Printed in U.S.A.
Page 16 3RD EYE WARRANTY 3RD EYE PRODUCTS LIMITED WARRANTY 3rd Eye warrants that the 3rd Eye Hardware and Software, as delivered by 3rd Eye to Client, will be free from defects in materials and workmanship in accordance to the terms and conditions specified herein. This warranty is a “parts replacement only” policy, and does not cover labor. Other limitations apply as provided below.
Page 17 www.3rdeyecam.com Customer Care: 866-804-2984 3rd Eye 22130 Merchants W ay STE 100 Katy, TX 77449...
