USE AND MAINTENANCE MANUAL
REV0 30/7/2023 PBCA0124GB
AUXILIARY BATTERY
ePower Box
INDEX
1. INTRODUCTION
1.1 Field of application
1.2 Consulting the manual
1.3 Warranty
2. CAUTION
2.1 General recommendations
3. USE OF THE PRODUCT
3.1 First Use
3.2 Charging the Battery
3.3 Resetting the Battery
3.4 Battery Monitoring
3.5 Powering External Devices
3.6 Transportation Instructions
3.7 LiFePO4 Battery
4. MAINTENANCE
4.1 Cleaning Instructions
4.2 Routine Maintenance Instructions
4.3 Troubleshooting
4.4 Replacing the Protective Fuses
5. DISPOSAL
5.1 Packaging
5.2 Disposal of the product in the territory of the European Union
6. CERTIFICATIONS
1
Advertisement
Summary of Contents for MELFORM ePower Box
- Page 1 USE AND MAINTENANCE MANUAL REV0 30/7/2023 PBCA0124GB AUXILIARY BATTERY ePower Box INDEX 1. INTRODUCTION 1.1 Field of application 1.2 Consulting the manual 1.3 Warranty 2. CAUTION 2.1 General recommendations 3. USE OF THE PRODUCT 3.1 First Use 3.2 Charging the Battery 3.3 Resetting the Battery...
- Page 2 MELFORM's Koala line. This device is equipped with a LiFePO4 lithium battery and its charger. Once the LiFePO4 battery is charged, the ePower Box can be used as an independent power source for electrical and electronic devices operating at 12Vdc or lower voltages.
- Page 3 Do not operate the ePower Box if it has been subjected to shocks, falls, or has obvious damage. Avoid smoking, creating sparks or flames in the vicinity of the battery and charger, as there is a risk of explosion.
-
Page 4: Use Of The Product
RECHARGE IF POSSIBLE. To charge the ePower Box battery , proceed as follows: • check that the plug of the power cable supplied with the ePower Box is suitable for the socket of the electrical system; • Make sure that the socket is provided with an efficient earth contact and has an adequate flow rate. - Page 5 8V. This phenomenon can be observed when the Victron display turns off and does not light up the moment you connect the ePower Box to the 230V ac power supply for charging. For a proper reset procedure, keep the device connected to the 230V ac power supply and press the RESET button.
- Page 6 40% is reached. Charging is required up to at least 90% to keep the battery in good condition for as long as possible If the ePower Box is rarely used, it is recommended to recharge the battery every 15/20 days. 3.5 Powering External Devices ePower Box is equipped with an Anderson SB50 socket for powering 12Vdc devices with absorption up to 30A and a 2-port QC3.0 USB socket with output from 3.6Vdc/3A to 12Vdc/1.5A, maximum power 18Wx2.
-
Page 7: Temperature Control
When handling the ePower Box, take the utmost care to avoid collisions with things or people. 3.7 LiFePO4 Battery The ePower Box is equipped with a LiFePO4 battery. The table below shows the characteristics of the different battery options. Code... -
Page 8: Maintenance
To ensure proper cleaning of the product, follow the following directions carefully: - Before proceeding with the cleaning of the container, turn off the ePower Box. Be sure to disconnect the plug from the mains and unplug the socket connecting to the appliance. Store the power cord in a safe place and protected from moisture. - Page 9 4.3 Troubleshooting Below is a list of the main anomalies that can be found on the ePower Box, with an indication of the possible causes and the interventions for recovery. Do not work on the product if it is under warranty: the warranty is void if the product has been repaired or tampered with by an unauthorized third party.
- Page 10 These certifications confirm that the product is designed and manufactured in such a way as to guarantee the highest quality and safety in the transport and storage of perishable food products. Thank you for choosing a MELFORM product! Via Savigliano 34, 12030 Monasterolo di Savigliano (CN) - ITALY Tel.
