Backyard Buddy B-SXS-10000
Installation and Operations Manual
IMPORTANT SAFETY INSTRUCTIONS
Please read the entire contents of this
.
manual prior to installation, operation, servicing or maintaining the lift. Reference
ANSI/ALI ALIS "Safety Requirements for Installation and Service of Automotive
Lifts" & ALI "Lifting it Right". By proceeding you agree that you fully understand
and comprehend the full contents of this manual and other included materials
that came with your lift. Make this manual available to all operators. Failure to
operate this equipment as directed may cause injury or death. SAVE THESE
INSTRUCTIONS
Designed and Engineered in Warren, Ohio USA
