Summary of Contents for BMC SPEEDMACHINE 00 LTD
- Page 1 Owners Manual Speedmachine Owners Manual...
-
Page 2: Table Of Contents
Speedmachine Gen1 Owners Manual - V1 - September 2023 - English Copyright © 2023 BMC Switzerland AG. All rights reserved. BMC Switzerland AG | Sportstrasse 49 | CH-2540 Grenchen | Switzerland +41 32 654 14 54 | info@bmc-switzerland.com | www.bmc-switzerland.com... -
Page 3: Introduction
If you do not have the appropriate tools or experience to execute the following instruc- tions, or if you need further information, please contact your official BMC dealer for service of your bicycle. -
Page 4: Intended Use
Bike Registration page (www.bmc-switzerland.com/bmc-bike-reg) Thru-axles: or within the BMC Companion App, you can extend the warranty on the frame to five • Front: BMC model CTS1048 12x100mm years. You can read the warranty provisions in detail on the Warranty policy page •... -
Page 5: Special Parts Details
Time Trial Bottle 400 Rotation stop bolt M4 x 10 Rear Storage 260 Article numbers: Hydration tube cover BMC Rear light StVZO Hydration tube cover - closed Profile Design Risers, Armrests and extensions 30006250 Thru Axle Kit No. 10 Rivet Plug M5 (Top tube & seat tube rear) - Page 6 Generalities Generalities Base bar Extension set Base bar Flat The base bar of the Speedmachine is design for Profile Design Aeria 3 Ultimate. The standard base bar delivered on Speedmachine is the “flat base bar”. 45/25 SLC extensions Width : 400mm Article numbers: 30006136 CKP BASE 24-R6, 0, FLAT-400, RED...
- Page 7 Generalities Generalities Seatpost Hydration Seatpost options FuelTank 1200 The Speedmachine is delivered with a “0mm offset - forward” seatpost The Speedmachine is delivered with a triathlon specific hydration system including: providing an ideal range of adjustment for Triathlon bike fitting. •...
- Page 8 Rear Storage 260 SM00/01 BMC Rear light 20 StVZO Nicely integrated into the Rear Storage 260, our BMC Rear light 20 StVZO provides 20 lumen of brightness to keep you safe while training. You can recharge it by USB with the provided cable and it will diffuse it’s 180° light beam up to 3.5 hours run time.
-
Page 9: General Notes About Assembly
Generalities General notes about assembly Tools Bike specific tools are required to perform the installation of your Speedmachine and its components. We recommend that you have a qualified bicycle mechanic to correct- ly install these components. Before you start assembling, make sure you are equipped with the following tools: Allen keys: •... -
Page 10: Torque Specifications
Generalities Generalities Torque specifications Recommended assembly procedure If you are building a Speedmachine from scratch, the most convenient way is to follow WARNING: Respecting and controlling the correct torque on fasteners is important the order and the procedure described below. This is only the global procedure, all the for your safety. -
Page 11: Sizing And Parts Selection
Many different handlebar types and shapes are available on the market and it is not possible for BMC to guarantee accurate positioning for all of them. The base bar, arm- rest set, extensions and seat post provided with the Speedmachine complete bikes and modules were carefully selected to offer the highest adjustment possibilities in a light, reliable and user-friendly package. -
Page 12: Detailed Assembly Instructions
Detailed assembly instructions Detailed assembly instructions Frame preparation Rear derailleur hanger installation • Select the right model of hanger depending on your groupset, and the rear derailleur design. You can choose between the standard dropout hanger or the direct mount dropout hanger. -
Page 13: Fork Preparation
Detailed assembly instructions Detailed assembly instructions Fork preparation Front derailleur hanger installation • Select the right model of hanger depending on your groupset, The fork provided with the frameset or the bike is already cut to size and to the the chainring configuration, and the front derailleur design. -
Page 14: Seatpost Preparation
Detailed assembly instructions Detailed assembly instructions Seatpost preparation Electronic wires installation Seatpost length SHIMANO DI2 The two seatposts compatible with the Speedmachine have a minimum and a maximum insertion depth in the frame. WARNING: Please always refer to the latest SHIMANO product information for your groupset. -
Page 15: Seatpost Assembly
Detailed assembly instructions Detailed assembly instructions Seatpost assembly SRAM AXS Saddle clamp installation Please always refer to the latest SRAM product information for your groupset. The following information is a guide with basic principles. • Install saddle clamp on your desired seatpost using one of the 3 offsets available. •... -
Page 16: Brake Calipers Assembly
Detailed assembly instructions Detailed assembly instructions Brake calipers assembly Frame seatpost clamp installation • Apply a thin layer of friction paste onto the frontal surface of the seatpost tube. Rear brake • Grease the 2 compression M6x10 and M6x14 socket set bolts and install them into the frame threads without tightening. - Page 17 Detailed assembly instructions Front brake The front brake must be installed directly on the specific BMC front bracket adapter. The Speedmachine is designed for 160mm front rotor only. WARNING: There are multiple front brake adapter plate designs. Make sure you are using the part provided with the Speedmachine.
-
Page 18: Headset And Fork Assembly
Detailed assembly instructions Detailed assembly instructions Headset and fork assembly The Speedmachine is designed to fit high grade stainless steel headset bearings from Enduro Bearings. Specifications of these bearings are: Reference Dimensions Upper bearing ACB 4545 1125T SS-bx 30.15x41x7; 45x45°; 1.125” SS Lower Bearing ACB 4545 125L SS-blk 34.1x46.8x7;45x45°;... -
Page 19: Bottom Bracket And Crankset Assembly
Detailed assembly instructions Detailed assembly instructions Base bar assembly Prior to proceed to the base bar installation, you should define how your brakes should be installed. 4 Nm 4 Nm • Standard Style Brake-Assembly: [Front brake] from [Left lever] & [Rear brake] from [Right lever] •... - Page 20 Detailed assembly instructions Detailed assembly instructions Align and slide over 0.5mm mini • • Install the base bar onto the headset sleeve. 0.5mm mini INFORMATION: It will help to pull the brakes hoses from the base bar grip to help push the base bar onto the headset sleeve.
-
Page 21: Armrest Risers, Armrests And Extensions Assembly
Detailed assembly instructions Detailed assembly instructions Armrest risers, armrests and extensions assembly • Pile up the required spacers Stack height • Apply grease and Friction paste where indicated on the illustration bellow. Depending on your defined position (armrest stack), you can pick and prepare the ap- Thread locker propriate set of spacers and bolts. - Page 22 Detailed assembly instructions Detailed assembly instructions Armrest installation • Install the 4 bolts making sure the longest one is at the front. • Select the armrests position: • Fore and aft adjustment: 45mm in 15mm steps • Width adjustment (c2c): 124, 142, 161, 179, 198, 216, 235, 253mm Short Reach Long Reach 5 Nm...
- Page 23 Detailed assembly instructions Detailed assembly instructions WARNING: The armrests are not designed to be used in the reversed position. Respect the orientation illustrated bellow. Thread locker Grease Grease Thread locker • Grease the 4 armrest bolts upper surface to reinforce their protection against corrosion. WARNING: Bolts orientation is preferred like described in the illustration bellow.
- Page 24 Detailed assembly instructions Detailed assembly instructions Pads installation Extensions installation • Install the pads by placing carefully on hook and loop backing of the armrest and hold The Speedmachine is delivered with the popular extension “45/25 SLC Aerobar firmly for 30 seconds. Repeat for the other pad. Extensions 400mm”...
-
Page 25: Fueltank Installation
Detailed assembly instructions Detailed assembly instructions FuelTank installation • Route the straw into the FuelTank pushing it enough to reach the bottom of the FuelTank. • Install the FuelTank clip using the 2 M4x16 bolts. • Grease the 2 bolts upper surface to reinforce their protection against corrosion. Slide to the bottom of the WARNING: Do not install the down tube or seat tube bolts. -
Page 26: Water Bottle Installation
Detailed assembly instructions Detailed assembly instructions Water bottle installation Top tube storage • Install the TT Bottle slider using 2 M5x12 bolts. The Speedmachine is equipped with top tube threads to allow the mount of a • Grease the 2 bolts upper surface to reinforce their protection against corrosion. top tube storage. -
Page 27: Wheels And Axles
Wheels and axles WARNING: Your bike is delivered pre-assembled with inner tubes for transportation The BMC Speedmachine is a high-tech, performance oriented product. We ask you and display. to specially take care of your bike if you want it to deliver the maximum of it’s perfor- Always setup the wheels following the recommendations and instructions of the mance over the years. - Page 28 Service instructions Notes .......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................... Speedmachine Owners Manual...
- Page 29 BMC Switzerland AG Sporwtstrasse 49 | CH-2540 Grenchen | Switzerland...
