- Page 1 AT5100 External Modulation Optical Transmitter Quick Reference Guide Revision G...
- Page 2 Quick Reference Guide Revision G Copyright © 2020 Ascent Communication Technology Limited. All rights reserved. Reproduction in any manner whatsoever without the express written permission of Ascent Communication Technology is strictly forbidden. This document is produced to assist professional and properly trained personnel with installation and maintenance issues for the product.
- Page 3 AT5100 External Modulation Optical Transmitter Table of Contents 1 Precautions ..........................5 2 Introduction ........................... 6 2.1 Overview ························································································································ 6 2.2 Features ·························································································································· 6 2.3 Specifications ················································································································· 7 2.4 Models and Options ······································································································· 8 3 Installation ..........................9 3.1 Equipment Inventory ····································································································· 9 3.2 Packaging and Transportation ························································································...
- Page 4 AT5100 External Modulation Optical Transmitter 5.7 Change Password ········································································································· 22 5.8 Reset Settings ··············································································································· 22 6 Setup Menu .......................... 23 7 OMI Adjustment ........................27 7.1 The Request on RF Input Level ····················································································· 27 7.2 AGC Condition ·············································································································· 27 8 SBS Adjustment Steps ......................27 9 Optimal Input Signal Level ....................
- Page 5 Unplug unit and refer servicing only to Ascent Communication Technology qualified service personnel. Servicing Do not attempt to service this unit yourself. Refer all servicing only to Ascent Communication Technology qualified service personnel. Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com...
- Page 6 19” sub-rack of 1 RU with dual main power supplies and SNMP management. Together with ACT 1RU EDFA optical amplifiers, the AT5100 XMOD2 provides an ideal long- distance video and short, medium video overlay solution in high density FTTX networks to bring the CATV services to business and home premises.
- Page 7 AT5100 External Modulation Optical Transmitter AT5100 XMOD2 1550nm Externally-Modulated (XMOD2) Laser Transmitter - 19” 1RU Items Unit Min. Typ. Max. Notes Optical Wavelength 1540 1563 Compatible with ITU wavelength Output Port No. Each Output 1 dBm/step Laser linewidth 0.35 SMSR...
- Page 8 AT5100 External Modulation Optical Transmitter Contact ACT for additional product variations on output power, 1 GHz, specific ITU channels, optical connectors etc. Note Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com Page 8 of 29...
- Page 9 95 %. Free ambient air should be maintained around all sides of the unit. Care should be taken to ensure that the air flow around the unit is unrestricted. The AT5100-XMOD2 should have a minimum ventilation clearance of 1 RU above and below the transmitter.
- Page 10 5. Switch the AC power ON (switch located on the rear panel). The ALARM LED will light red. The LCD will light and display “Model: AT5100-XMOD2” and “KEY OFF” on start up. 6. Switch on the laser using the key switch.
- Page 11 AT5100 External Modulation Optical Transmitter Port Item Description Mounting Points Holes for securing unit to rack LASER ON/OFF Key switch for laser activation LASER Laser indicator GREEN – Output power is normal RED – Abnormal status RF indicator GREEN – Normal operation RED –...
- Page 12 AT5100 External Modulation Optical Transmitter Port Item Description Intelligent fan, begins to run when the chassis temperature reaches 32 °C to 35 °C (set by Power Supply Switch UP – 12 V DC MIDDLE – Off DOWN – 18 V DC...
- Page 13 The power interface, is a standard 3-prong line cord, with hot, neutral, and chassis ground. The metal chassis of the transmitter is tied to ground. The AT5100-XMOD2 will be in AGC mode (Automatic Gain Control) when first powered on. To change it to MGC mode (Manual Gain Control), refer to Section 5.3.
- Page 14 For short lines this level can be a bit higher than for very long lines. A reduced line drive level together with a reduced SBS suppression threshold in the transmitter increases the maximum achievable system range. The AT5100-XMOD2 incorporates field-selectable SBS thresholds. Ensure that the selected level will match the fiber line drive level as close as practical for best performance.
- Page 15 AT5100 External Modulation Optical Transmitter The following table contains the ITU frequency plan with corresponding wavelengths available to the AT5100-XMOD2. Channel ITU Freq. Avail. ITU Channel ITU Freq. Avail. ITU (THz) Wavelengths (nm) (THz) Wavelengths (nm) Order Code Order Code 196.0...
- Page 16 AT5100 External Modulation Optical Transmitter The user can use web browser to check the working condition and basic parameters of the amplifier, it supports IE, Chrome, Firefox, Opera and other main web browser. The following example are based on Opera browser.
- Page 17 AT5100 External Modulation Optical Transmitter Step 3: Set the PC IP address in the same range with device IP address. For example the device IP address is 192.168.1.122, pls set PC IP address to 192.168.1.X (X different to 122). Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com...
- Page 18 AT5100 External Modulation Optical Transmitter 2. Open web browser, input the IP add and login in. The IP factory setting is 192.168.1.122. User Name: admin Password: ascent 3. The web management consist of five submenus. Items guide on the left, click to enter.
- Page 19 AT5100 External Modulation Optical Transmitter Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com Page 19 of 29...
- Page 20 AT5100 External Modulation Optical Transmitter OMI mode: switch AGC/MGC statuses. OMI Value: -3 dB to +3 dB adjustable, factory setting is 0 dB. SBS: 13 dB to 19 dB continuously adjust, 0.1 dBm step 0.1 dB. Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com...
- Page 21 AT5100 External Modulation Optical Transmitter Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com Page 21 of 29...
- Page 22 AT5100 External Modulation Optical Transmitter Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com Page 22 of 29...
- Page 23 AT5100 External Modulation Optical Transmitter The following menu shows all using the down arrow button; the up arrow button can be reversed. Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com Page 23 of 29...
- Page 24 AT5100 External Modulation Optical Transmitter Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com Page 24 of 29...
- Page 25 AT5100 External Modulation Optical Transmitter Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com Page 25 of 29...
- Page 26 AT5100 External Modulation Optical Transmitter Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com Page 26 of 29...
- Page 27 AT5100 External Modulation Optical Transmitter The standard RF input is 80±5dBµv in the condition of standard 59 channels, the advised RF steps between channels should controlled within 0.5dB to get the best parameters The above advised RF input is based on 59 channels, in the actual application, the load number of channels may change, accordingly, the RF input of each channel will change, pls see the following picture.
- Page 28 AT5100 External Modulation Optical Transmitter The total RF analog input level depends on the number of analog channels in your system and is identical for the type of system (NTSC, PAL, CENELEC) used. Use the following equation to determine the optimum RF input level per channel when the rated channel loading is not...
- Page 29 Phone: +84 168 481 8348 WEB: www.ascentcomtec.com EMAIL: sales@ascentcomtec.com Specifications and product availability are subject to change without notice. Copyright © 2020 Ascent Communication Technology Limited. All rights reserved. Ver. ACT_1RU_AT5100_XMOD2_QRG_V1g_Sep_2020 Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com Page 29 of 29...
