- Page 1 STEREO ANALOG AMBIENT PROCESSOR USER GUIDE BEFORE PROCEEDING WITH INSTALLATION AND SETUP, PLEASE READ THESE INSTRUCTION PAGES - 1 - MCAudioLab LUNA VariAmb processor - user guide issue 1.0...
- Page 2 The LUNA accepts two input channel in Stereo or Mid-Side mode. An internal encoder converts the input signal to M-S while a decoder converts the output signal back to Stereo. The encoder is of course bypassed when LUNA is in M-S mode.
- Page 3 Depth EQ Balance S.W.A.P. Depth phase flip DEPTH MONO SIDE controls MONO EQ controls Mono phase flip INPUT mode switch OUTPUT meter BYPASS switch INSERT switches CUT switches - 3 - MCAudioLab LUNA VariAmb processor - user guide issue 1.0...
- Page 4 Trim knobs control the SIDE channel level. MONO Rota�ng this poten�ometer clockwise we send the signal to the LUNA Analog Processor. All those signal compo- nents that occupy the central posi�on between the le� and right channels are called MONO. When in the OFF posi�on, no signal is fed to the LUNA Analog Processor.
- Page 5 INSERT switches Allows you to send the LUNA's signal externally. It consists of two separate switches, one for the Mid channel and the other for the Side channel. Whatever the source (Stereo or Mid-Side) the LUNA always operates in M-S mode internally.
- Page 6 The LUNA back panel INPUTs Master OUTPUT GND lift switch Master OUTPUT GND lift switch SIDE output SIDE output return SIDE return send send FUSE DC INPUT - 6 - MCAudioLab LUNA VariAmb processor - user guide issue 1.0...
- Page 7 Output TRS balanced jack connectors. They send the signal to an external device when the LUNA is in insert mode. FUSE The fuse is used to avoid damage to the LUNA electrical circuit in the case of a malfunc�on or problems with the electrical network. Please replace the fuse with the same type and rate only! DC INPUT External Power supply.
- Page 8 CAUTION: Temperature - The chassis may become hot during opera�on. Do not place LUNA close to any heat sources such as radiators or stoves. Avoid exposing it to direct sunlight. Do not block the circula�on vents − heat from the device must be allowed to dissipate. Allow free space around the unit in your rack to let the unit cooling down.
- Page 9 Amplifica�on (Output) -inf to +6 dB Max Output level: +22dBu Input electronically servo-balanced (all audio inputs) Input resistance 10kOhm Output electronically servo-balanced (all audio ouputs) Output resistance <50Ohm - 9 - MCAudioLab LUNA VariAmb processor - user guide issue 1.0...
