Adirondack Chair - Assembly Instructions

Introduction

Please read these instructions fully before
starting.
Understanding of the whole process will help
to ensure an easy build.
If there are any parts that are unclear then
please call us on 01483489002 for
clarification.
Work on a large level surface where you can
move around all sides of the chair. It is easier
to walk around the chair rather than to have to
rotate the chair to your position.

Tools Required

Cross screwdriver.
Flat screwdriver
10mm Spanner.
For protection and ease of assembly the rear legs are
supplied already attached but rotated beneath the seat
unit as shown.
Start by rotating the legs out towards the rear of the
chair. Lay them flat on the ground behind the seat
assembly.
Hold the back assembly in the cutout area in the side of
the seat and rotate the rear legs into an upright
position, placing their ends under the curved rail at the
top of the back assembly.
Insert four screws through the predrilled holes in the
lower back rail.
You can align these easily by placing the cocktail stick
through one hole. Remove the stick before inserting the
screw.
Insert one screw on each side of the top back rail. Use
the cocktail stick in the other hole to align with the
holes in the top of the back legs.
Remove the cocktail stick and drive a screw into each
of the other predrilled holes.
Screws and fixings
All the screws and fittings are stainless steel. If a screw is
proving stubborn, check that it is fully aligned with the pilot hole.
Do not use excessive force.
Adirondack Outdoors - www.adirondack.co.uk - 01483 489002
What's Included

Chair Seat Assembly - front legs attached

Chair Back Assembly

2 Arms
Fixings pack containing
12 - 4 X 40mm Screws
2 X 50mm stainless steel machine screws and nuts.
2 X 70mm stainless steel machine screws and nuts.
(2 machine screws already attached)
1 cocktail stick to help with alignment.
