Full Motion LED, LCD TV Wall Mount
200x200/300x200
VLM-4600
300x300/400x200
400x400/600x400
CAUTION:
DO NOT EXCEED
RATED LISTED WEIGHT. SERIOUS
INJURY OR PROPERTY DAMAGE
MAY OCCUR!
70"
MAX
35kg
35kg
Advertisement
Summary of Contents for EZYmount VLM-4600
- Page 1 Full Motion LED, LCD TV Wall Mount CAUTION: DO NOT EXCEED 4/30 Prohasky Street RATED LISTED WEIGHT. SERIOUS Port Melbourne, Victoria, 3207 INJURY OR PROPERTY DAMAGE MAY OCCUR! Australia 200x200/300x200 70" VLM-4600 300x300/400x200 35kg 35kg 400x400/600x400...
-
Page 2: Component Checklist
Component Checklist NOTE: Read the entire instruction manual before you start installation and assembly. IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, telephone your local distributor for a replacement. WARNING •... - Page 3 1a. For Wood Stud Wall Mounting 1b. For Solid Brick and Concrete Mounting 60mm 60mm 55mm 55mm ø 10mm ø 4.5mm Mark the exact location of mounting holes Find and mark the exact location of mounting holes Drill pilot holes √...
- Page 4 2. Installing the Decorative Covers 3. Installing the Adapter Brackets Remove the screws on the adapter brackets and keep the screws for later use. Install the decorative covers along the wall plate 3-1 For Flat Back Screens rail until they fit snuggly onto the wall plate.
- Page 5 4. Hooking the TV onto the Wall Mount 3-2 For Recessed Back Screens or to Access A/V Inputs M-C/M-D/M-E M-D/M-E M-D/M-E Note: Choose the appropriate screws, washers and spacers (if necessary) according to the type of screen. Hook the TV over the top of the wall mount. ·...
-
Page 6: Cable Management
5. Cable Management 6. Adjustment You can slightly adjust the level of the TV by tightening or loosening screws or nuts. 180° 180° 180° +10° -15° Adjust to the desired position or tilt. · Remove the cable covers to run the cables. ·...
