Vayyar Home Dry Contact Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Vayyar Home
™
Dry Contact
Installation
Guide
Vayyar.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Home Dry Contact and is the answer not in the manual?

Questions and answers

Summary of Contents for Vayyar Home Dry Contact

  • Page 1 Vayyar Home ™ Dry Contact Installation Guide Vayyar.com...
  • Page 2 Vayyar or in any case of third party materials, without that third party's consent. This document shall be returned to Vayyar promptly upon request. The materials and information contained herein are provided "AS IS"...

  • Page 3: What's Included

    12/24 VDC Back cover Front cover & screws Power Supply Note: Recommended 3 x self-tapping that the installation be Transmitter Precision screws done by a professional and cables screwdriver installer. Always abide by local regulations. Vayyar Home Dry Contact Installation Guide...

  • Page 4: In-Wall Installation

    In-wall installation Vayyar Home Dry Contact Installation Guide...
  • Page 5 Mark a line on the wall, measured 1.5m/5ft from the floor, where you plan to attach the sensor to the wall. 1.5m/5ft Note: The 1.5m/5ft mark should align with the center of the device. Vayyar Home Dry Contact Installation Guide...
  • Page 6 Using the front cover as a template, draw a circle with the line going through the center. 1.5m/5ft Vayyar Home Dry Contact Installation Guide...
  • Page 7 Cut out the circled area. Vayyar Home Dry Contact Installation Guide...
  • Page 8 Peel the stickers from the chassis and attach the sensor in place. Vayyar Home Dry Contact Installation Guide...
  • Page 9 Wrap the cable over the ribs and into the slot. Vayyar Home Dry Contact Installation Guide...
  • Page 10 Insert the Type-C USB Connector to the bottom of the board on the back of the Chassis. Vayyar Home Dry Contact Installation Guide...
  • Page 11 Drill holes in the wall in line with those on the chassis and insert wall plugs. Vayyar Home Dry Contact Installation Guide...
  • Page 12 *Transmitter not supplied by Vayyar The transmitter cables should be connected to the bottom first (GND) and third (ALARM 1) locations on the board. Do not attach the cables at locations directly next to each other. Vayyar Home Dry Contact Installation Guide...
  • Page 13 The electrical cables should be connected to the bottom eighth (12/24V IN) and sixth (GND) locations on the board. Do not attach the cables at locations directly next to each other. Vayyar Home Dry Contact Installation Guide...
  • Page 14 If your device is NOT pre-provisioned, please reference the provisioning instructions provided by the Vayyar Home Customer Success team Once pairing is complete & power is confirmed, simulate the dry contact is working by pressing the power button for 2-seconds Vayyar Home Dry Contact Installation Guide...
  • Page 15 Attach the chassis to the wall with screws. Vayyar Home Dry Contact Installation Guide...
  • Page 16 Attach the front cover to the chassis and align as shown, until it snaps into place. Vayyar Home Dry Contact Installation Guide...
  • Page 17 Assembly is complete. Vayyar Home Dry Contact Installation Guide...

  • Page 18: On-Wall Installation

    On-wall installation Vayyar Home Dry Contact Installation Guide...
  • Page 19 Peel the stickers from the chassis and attach the sensor in place. Vayyar Home Dry Contact Installation Guide...
  • Page 20 Wrap the cable over the ribs and into the crease. Vayyar Home Dry Contact Installation Guide...
  • Page 21 Insert the USB connector. Vayyar Home Dry Contact Installation Guide...
  • Page 22 With a spirit level, mark a line 1.5m/5ft from the floor on the wall where you want the sensor. 1.5m/5ft Vayyar Home Dry Contact Installation Guide...
  • Page 23 Place the back cover on the wall so that it correctly intersects the line and is the right way up. Vayyar Home Dry Contact Installation Guide...
  • Page 24 Mark drill-hole positions on the wall, including one in the middle for the cable. Vayyar Home Dry Contact Installation Guide...
  • Page 25 Drill and insert wall plugs in line with the holes in the back cover. Vayyar Home Dry Contact Installation Guide...
  • Page 26 Attach the back cover to the wall with screws. Vayyar Home Dry Contact Installation Guide...
  • Page 27 (GND) and third (ALARM 1) locations on the board. Do not attach the cables at locations directly next to each other. Note: Make sure the voltage reaching the system is under 5 volts. Vayyar Home Dry Contact Installation Guide...

  • Page 28: Connect The Sensor

    The electrical cables should be connected to the bottom eighth (12/24V IN) and sixth (GND) locations on the board. Do not attach the cables at locations directly next to each other. Vayyar Home Dry Contact Installation Guide...
  • Page 29 Attach the Attach the chassis to the chassis to the back cover back cover with the with the snap-fit lugs snap-fit lugs (to ease (to ease installation) installation). Vayyar Home Dry Contact Installation Guide...
  • Page 30 Attach the chassis to the back cover with screws. Vayyar Home Dry Contact Installation Guide...
  • Page 31 Attach the front cover to the chassis with the snap-fit lugs. Vayyar Home Dry Contact Installation Guide...
  • Page 32 Assembly is complete. Vayyar Home Dry Contact Installation Guide...

  • Page 33: Installation

    Ceiling installation Vayyar Home Dry Contact Installation Guide...
  • Page 34 Peel the stickers from the chassis and attach the sensor in place. Vayyar Home Dry Contact Installation Guide...
  • Page 35 Wrap the cable over the ribs and into the crease. Vayyar Home Dry Contact Installation Guide...
  • Page 36 Insert the USB connector. Vayyar Home Dry Contact Installation Guide...
  • Page 37 Orient the back cover according to the room wall widths – the top arrows should be parralel to the x-axis. X axis (Narrow side of room) Y axis (Wide side of room) Vayyar Home Dry Contact Installation Guide...
  • Page 38 Drill holes for wall plugs and insert Y axis X axis (Wide side of room) (Narrow side of room) them. Vayyar Home Dry Contact Installation Guide...
  • Page 39 Attach the back cover to the ceiling with screws. Vayyar Home Dry Contact Installation Guide...
  • Page 40 Alternatively, attach the back cover using cable ties/hose clamps. Vayyar Home Dry Contact Installation Guide...
  • Page 41 The electrical cables should be connected to the bottom eighth (12/24V IN) and sixth (GND) locations on the board. Do not attach the cables at locations directly next to each other. Vayyar Home Dry Contact Installation Guide...
  • Page 42 The transmitter cables should be connected to the to the sensor. bottom first (GND) and third (ALARM 1) locations on the board. Do not attach the cables at locations directly next to each other. Vayyar Home Dry Contact Installation Guide...
  • Page 43 Align the holes between the parts according Y axis X axis to the required orientation (0°/45°). Y axis X axis Note: Ceiling mounting with a 45-degree rotation is recommended for better coverage. Vayyar Home Dry Contact Installation Guide...
  • Page 44 Attach the chassis to the back cover with the snap-fit lugs (to ease installation). Vayyar Home Dry Contact Installation Guide...
  • Page 45 Attach the chassis to the back cover with screws. Vayyar Home Dry Contact Installation Guide...
  • Page 46 Attach the front cover to the assembly with the snap-fit lug. Vayyar Home Dry Contact Installation Guide...
  • Page 47 Assembly is complete. Vayyar Home Dry Contact Installation Guide...
  • Page 48 Disassembly instructions Vayyar Home Dry Contact Installation Guide...
  • Page 49 Release the snap-fit joint by inserting a flat-headed screwdriver into the top slot. Vayyar Home Dry Contact Installation Guide...
  • Page 50 Detach the screws from the chassis. Vayyar Home Dry Contact Installation Guide...
  • Page 51 Push the snap- fit lugs towards the center and mannually detach the chassis from the back cover. Vayyar Home Dry Contact Installation Guide...
  • Page 52 Detach the elctrical cable from the sensor. Vayyar Home Dry Contact Installation Guide...
  • Page 53 Unscrew the screws from the wall/ceiling to detach the back cover. Vayyar Home Dry Contact Installation Guide...

  • Page 54: Fcc Statement

    This equipment should be installed and operated with minimum distance 20cm between the radiator & your body Copyright © 2021 Vayyar Imaging Ltd. All rights reserved. Vayyar and Vayyar Home are trademarks and/or registered trademarks of Vayyar Imaging Ltd, 26 Shabazi St, Yehud-Monosson, Israel 5623108.
  • Page 55 Vayyar Home ™ Email: homesupport@vayyar.com Copyright © 2021 Vayyar Imaging Ltd. All rights reserved. Vayyar and Vayyar Home are trademarks and/or registered trademarks of Vayyar Imaging Ltd, 26 Shabazi St, Yehud-Monosson, Israel 5623108. Vayyar Home Dry Contact Installation Guide Vayyar.com...
