Model: NCB46
Step 1
Attach the back leg, seat and back together by using
(2) 2½" chair bolts.
Step 2
Attach the footrest assembly using (4) 1¾" chair bolts.
__(1) Chair
__(1) Footrest
__(1) Hardware pack
TOOLS NEEDED
4MM T-HANDLE HEX KEY
(INCLUDED)
.
Description
Qty
A - 1/4-20 X 1-3/4 WAFER SHCS
4
B - 1/4-20 X 2-1/2 WAFER SHCS
2
ASSEMBLY INSTRUCTIONS
Footrest Assembly
A
ALL HARDWARE IS COATED STAINLESS STEEL
B
B
A
A
A
12/3/2012
