Summary of Contents for Silent Angel Rhein Z1 Plus
- Page 1 Quick Start Guide High Performance Music Server Rhein Z1 Plus...
-
Page 2: Table Of Contents
Table of Contents Product Features ..................Packaging Content ..................Front Panel ..................... Rear Panel ...................... Preparation Work (1) ..................Preparation Work (2) ................... Advanced Connection Diagram ............... Power On ....................... Install Mobile App ..................Use Mobile Device to Control Z1 Plus ............. Device Search Guide ................... -
Page 3: Product Features
Product Features Dual firmware design prevents the firmware from being damaged during upgrade. The dual network port design can connect the network and player at the same time. USB Audio Optimizer is an optimized USB audio processing. Event triggered system architecture minimizes system load. BNC external clock interface is applicable to external clock equipment Package Contents Z1 PLUS... -
Page 4: Front Panel
When the power is on, long press the button to turn off the power ⑨ DC Input ③ Network Port 5.5mm x 2.5mm DC 12V power input ( can be connected to Silent Angel Supports 1000Mbps Ethernet Network and 100Mbps Ethernet Network F2 or suitable 12VDC linear power supply) ④ Player Port ⑩... -
Page 5: Preparation Work (1)
Preparation Work (1) Make sure audio devices are all powered off. Connect Z1 PLUS Network port to a Bonn series or WiFi router LAN port with an Ethernet cable. Connect USB AUDIO port to a USB DAC with the USB cable. Amplifier Ethernet Cable Wi-Fi Router... -
Page 6: Advanced Connection Diagram
Advanced Connection Diagram Internet Ethernet Cable AC INPUT ON / OFF STORAGE EXPANSION GbE LAN DIGITAL OUTPUT ANALOG OUTPUT COAXIAL 100mA max. USB AUDIO AES / EBU POWER ON / OFF EXTERNAL For continued protection against risk of fire,replace ONLY with fuse FUSE TYPE: T1A250VAC 12V DC INPUT of the specified type and current ratings. -
Page 7: Power On
Power On Power on Z1 PLUS by pushing the power button at the rear panel. The power LED will light on. Power LED Power Button Power on other audio devices Install“VitOS Manager"App on a Pad or Phone Use below QR code to install "VitOS Manager" app on a pad or phone. iPad / iPhone Android Pad / Phone Android Pad / Phone... -
Page 8: Use Mobile Device To Control Z1 Plus
Use Mobile Device to Control Z1 Plus > > VitOS Mana. VitOS Mana. > >... -
Page 9: Device Search Guide
Device Search Guide If the device cannot be found when connecting, click the "Help" button. Enter the "Discover Guide" interface, enter the IP address of the Z1 Plus device in the space marked at the bottom of the interface, and then click "Connect". -
Page 10: Install Applications
The connection to Z1 Plus is successful and the VitOS Manager main page is shown. Install Applications Before using the application, you need to confirm the installation status of the application. If "Running" is displayed, it means it has been installed. If "Not Installed" appears, click the corresponding application, and then click the "Install"... -
Page 11: Application Introduction
After installing the application, "Downloading" is displayed. Wait until the download is completed to "100%". If the status displays "Running", the installation is successful. Application Introduction Orbiter Plugin： Orbiter Plugin is an application plug-in that mainly builds music playback operations for VitOS devices. - Page 12 Trademark Attribution Notice Windows is a trademark or registered trademarks of Microsoft Corporation in the United States and other countries. iOS is a trademark or registered trademark of Cisco in the U.S. and other countries.Android is a trademark of Google LLC, registered in the U.S.
