Summary of Contents for Bendix CVS SmarTire
- Page 1 SMARTIRE BY BENDIX CVS ® TIRE PRESSURE MONITORING SYSTEM (TPMS) BT37 LOW-FREQUENCY (LF) MAINTENANCE HAND TOOL OPERATOR’S MANUAL ®...
- Page 2 The SmarTire by Bendix CVS System consists of a tire pressure sensor inside each tire that transmits Radio Frequency (RF) signals containing a unique Identification Number (ID #), actual tire pressure, temperature, and sensor battery condition to an Electronic Control Unit (ECU) attached to the vehicle’s J1939 communication bus.
- Page 3 Operation Powering the Tool On and Off See Figure 2. Press the Power On/Off button to power on the BT37 Low-Frequency (LF) maintenance hand tool. A Bendix splash screen will appear, followed by the current software version operating on the maintenance hand tool. To power off the unit, hold the Power On/Off button for approximately two (2) seconds.
- Page 4 Changing the Settings See Figure 5. Press the Previous Menu button to return to the main menu. Use the Navigation buttons to select the Settings icon. Then, press the OK button. Use the Navigation buttons to select a menu item. •...
- Page 5 ONE-YEAR (1) LIMITED WARRANTY The manufacturer warrants this product to the original user against defective material or workmanship for a period of 1 year from the date of purchase. The manufacturer reserves the right to determine whether the part or parts failed because of defective material, workmanship or other causes.
- Page 6 24/7/365 ACCESS 1-800-AIR-BRAKE (1-800-247-2725) WEB-BASED TRAINING FULL SERVICE AT YOUR FINGERTIPS TECHTEAM@BENDIX.COM LOG ON AND LEARN FROM THE BEST BW8217 Rev 000 © 2023 Bendix Commercial Vehicle Systems LLC, a member of Knorr-Bremse • 11/23 • All Rights Reserved...
