Gyroor G-F1 - Hoverboard Manual

Packing List

When unpacking your G-F1, please verify that the above items are included in the package. If you are missing any components, please contact your dealer/distributor or nearest service center (see Contacts in the user manual). After verifying that all components are present and in good condition, you can assemble your new G-F1. Please retain the box and packaging materials in case you need to ship your G-F1 in the future. Always power off your G-F1 and unplug the charge cable before assembling, mounting.

Diagram

Charging

Do not connect the charger if the charge port or charge cable is wet. Your G-F1 is fully charged when the LED on the charger changes from red (charging) to green (trickle charge). Close the rubber cap when not charging.

First Ride

There are safety risks when learning to ride the G-F1. You must read the Safety Instructions and follow the New Rider Tutorial in the App before your first ride. For your safety, your G-F1 is not activated at this time and will beep occasionally after Power ON. Please download the app on app store or google play by search gyroor.

Learning to Ride

Rider must weigh 44-264lb (20-120kg), and should be over 4ft (121cm) tall. Wear an approved helmet and other protective gear to minimize any possible injury. For a new user, please adjust G-F1 to child mode by app or hands.

2. Lightly place one foot on the foot mat, while keeping your other foot on the ground holding your weight. Do not press the steering bar with your leg.


3. Slowly transfer your weight onto the G-F1. The unit will beep, indicating it is now in Balance Mode. Slowly step on with your other foot.



Maintenance

Cleaning and Storing Your G-F1
Use a soft, wet cloth to wipe the mainframe clean. Hard to remove dirt can be scrubbed with a toothbrush and toothpaste. then cleaned with a soft, wet cloth. Scratches on plastic parts can be polished with extra fine grit abrasive paper.

NOTE
Do not wash your G-F1 with alcohol, gasoline, acetone, or other corrosive/volatile solvents. These substances may damage the appearance and internal structure of your G-F1. Do not wash your G-F1 with a power washer or high pressure hose.

Make sure the G-F1 is powered OFF, the charging cable is unplugged, and the rubber cap on the charge port is tightly sealed before cleaning; otherwise you may expose yourself to electric shock or damage the electronic components.
Store your G-F1 in a cool, dry place. Do not store it outdoors for extended periods of time. Exposure to sunlight and temperature extremes (both hot and cold) will accelerate the aging process of the plastic components and may reduce battery life.

Battery Pack Maintenance
Do not store or charge the battery at temperatures outside the stated limits (see Specifications). Do not discard or destroy the battery. For more battery information, refer to the sticker on the battery itself, located on the bottom of the G-F1.
Refer to your local laws and regulations regarding battery recycling and/or disposal. A well maintained battery can perform well even after many miles of riding. Charge the battery after each ride and avoid draining the battery completely. When used at room temperature (70ºF [22ºC]) the battery range and performance is at its best; whereas using it at temperatures below 32ºF (0ºC) c an decrease range and performance.
Typically, at -4ºF (-20ºC) range can be half that of the same battery at 70ºF(22ºC). Battery range will recover when temperature rises. More details are available in the APP.

NOTE
Typically, a fully charged battery should retain charge for 60-90 days in Standby Mode. Remember to charger the battery after each use. Completely draining the battery may cause permanent damage to the battery. Electronics inside the battery record the charge-discharge condition of the battery; damage caused by over-discharge or under-discharge will not be covered by the Limited Warranty.

Do not attempt to disassemble the battery. Risk of fire. No user serviceable parts.

Do not ride when the ambient temperature is outside the machine operation temperature(see Specifications) because low/high temperature will limit the maximum power/torque. Doing so could cause personal injury or property damage due to slips or falls.

1. Click the Bluetooth icon to open the bluetooth and enter the Bluetooth link
2. Show the speed of the hoverboard.
3. Battery reminder (now it shows the battery empty)
4. Click this button to enter the switch and warning page.
5. Click this button to enter light color change page
6. Click this button to enter model adjustment and speed control page.
7. Search the bluetooth of the hoverboard.
8. Click this button to control the switch machine
9. Open this function when you need to left hoverboard for a while, it will warning
10. Fault Analyse help you to find the problem of the hoverboard.
11. Light color control page.

The hoverboard is shaking, it is a little dangerous, what's the problem?
If shaking, it's possible that the user's weight is not enough for the hoverboard, you can adjust it to child mode by gyroor app or adjust by hands. App adjustment: conversion of adult mode and child mode Manual adjustment: Stand up the G-F1, press the power button to turn it on - release the button - then keep press The button remains for about 6 seconds until the drip sound is heard and the balance hoverboard is restarted. Complete child mode switching.

The speed of two sides of the wheel is different/ I can not turn fluently with the hoverboard/ one side of the pedals is not on the horizontal line when starting up, what should I do?
The hoverboard is losing balance now, please calibrate it. Confirm that the hoverboard is in the off state and keep both side of the pedals parallel to the horizontal plane. Make sure the hoverboard is turned off, press and hold the power switch for 5 seconds and then release it. When you hear a sound, the system starts to calibrate; the red light (that is, the running indicator and the left turn indicator) flashes 3 times. Wait until the red light is on, the system calibration is complete, and you can cycle when you turn it off and on again.

I'm an experienced rider, I do not like the self--balance, can I cancel it?
Yes, you can cancel it, adjust it by gyroor app or hands: App adjustment: conversion of self-balance and unself-balance
Manual adjustment: PIace the car horizontally - make sure the G-F1 is turned on, press the power switch for about 6 seconds, until you hear the drip sound, restart the mode to complete the mode switch.

When I stop riding, the G-F1 is shaking heavily, is it normal?
If you suddenly stop using and down, the G-F1 will shake for seconds, it caused by the strong power. We advise that you can adjust it to child mode, that would reduce the shaking. And we suggest do not stop suddenly.

What should I do if there are problems with my G-F1?
If you find there are some problems on hoverboard, please contact GYROOR customer service by facebook @Gyroor or email support@gyroorboard.com, service@gyroor.com, with a video to show the problem and your order number is also needed. Gyroor would help to solve it soon.

Riding Safety

1. The G-F1 is a recreational product. Before mastering riding skills, you need to practice. Neither GyroorTechnology Ltd nor Shenzhen Chitado Technology Co., Ltd is responsible for any injuries or damage caused by a rider's inexperience or failure to follow the instructions in this document.
2. Please understand that you can reduce the risk by following all the instructions and warnings in this manual, but you cannot eliminate all the risks. Remember that whenever you ride the G-F1 you risk injury or death from loss of control, collisions, and falls. When entering into public spaces always comply with the local laws and regulations. As with other vehicles, faster speeds require longer braking distance. Sudden braking on smooth surfaces could lead to wheel slip, loss of balance, or falls. Be cautious and always keep a safe distance between you and other people or vehicles when riding. Be alert and slow down when entering unfamiliar areas.
3. Always wear a helmet when riding. Use an approved bicycle or skateboard helmet that fits properly with the chin strap in place, and provides protection for the back of your head.
4. Do not attempt your first ride in any area where you might encounter children, pedestrians, pets, vehicles, bicycles, or other obstacles and potential hazards.
5. Respect pedestrians by always yielding the right of way. Pass on the left whenever possible. When approaching a pedestrian from the front, stay to the right and slow down. Avoid startling pedestrians. When approaching from behind, announce yourself and slow down to walking speed when passing. Please obey local traffic laws and regulations if situation is different.
6. In places without laws and regulations governing self-balancing electric vehicles, comply with the safety guidelines outlined in this manual. Neither GyroorTechnology (CHINA) Co., Ltd nor Shenzhen Chitado Technology Co., Ltd is responsible for any property damage, personal injury/death, accidents, or legal disputes caused by violations of the safety instructions.
7. Do not allow anyone to ride your G-F1 on his/her own unless they have carefully read this manual, watched the safety video. The safety of new riders is your responsibility. Assist new riders until they are comfortable with the basic operation of the G-F1, make sure each new rider wears a helmet and other protective gear.
8. Before each ride check for loose fasteners, damaged components, and low tire pressure. If the G-F1 makes abnormal sounds or signals an alarm, immediately stop riding. Diagnose your G-F1 via the Gyroor scooter app and call your dealer/distributor for service.
9. Be alert! Scan both far ahead and in front of your G-F1 - your eyes are your best tool for safely avoiding obstacles and low traction surfaces (including, but not limited to, wet ground, loose sand, loose gravel, and ice).

10. To reduce risk of injury, you must read and follow all "CAUTION" and "WARNING" notices in this document. Do not ride at an unsafe speed. Under no circumstance should you ride on roads with motor vehicles. The manufacturer recommends riders should be 6+ years old. Always follow these safety instructions:
    1. People who should not ride the G-F1 include:
       1. Anyone under the influence of alcohol or drugs.
       2. Anyone who suffers from disease that puts them at risk if they engage in strenuous physical activity. iii. Anyone who has problems with balance or with motor skills that would interfere with their ability to maintain balance.
       3. Anyone whose height or weight is outside the stated limits (see Specifications).
       4. Pregnant women.
    2. Riders under the age of 16 years old should ride under adult supervision.
    3. Comply with local laws and regulations when riding this product. Do not ride where prohibited by local laws.
    4. To ride safely, you must be able to clearly see what is in front of you and you must be clearly visible to others.
    5. Do not ride in the snow, in the rain, or on roads which are wet, muddy, icy, or that are slippery for any reason. Do not ride over obstacles (sand, loose gravel, or sticks). Doing so could result in a loss of balance or traction and could cause a fall.
    6. Do not accelerate or decelerate suddenly. Do not accelerate when the G-F1 tilts back or sounds an alarm. Do not attempt to override the speed limiter.
11. Do not attempt to charge your G-F1 if the charger, or the power outlet is wet.
12. As with any electronic device, use a surge protector when charging to help protect your G-F1 from damage due to power surges and voltage spikes. Only use the Gyroor supplied charger. Do not use a charger from any other product.
13. Use only Gyroor approved parts and accessories. Do not modify your G-F1. Modifications to your G-F1 could interfere with the operation of the G-F1, could result in serious injury and/or damage, and could avoid the Limited Warranty.
14. Do not sit on the steering bar. Doing so could result in serious injury and/or damage to your G-F1.

Warnings

You must read and understand the Warnings and Safe Riding instructions in this manual before attempting to ride the G-F1. Failure to follow these warnings could result in death or serious injury due to: loss of balance, traction, and/or control; collisions; and falls.

Avoid contacting obstacles with the tire/wheel.

DO not ride through puddles or other bodies of water. Do not get wet.

DO not ride on public roads motor ways, highways, or streets.

Do not attempt stunts of any kind. Always keep both feet on the foot mats.

Do not ride on low traction surfaces (including, but not limited to, wet ground, loose sand, loose gravel, and ice).

For your safety, do not lift the G-F1 by the fenders when the hoverboard turn on, you risk pinching or injuring your fingers/hands.

Contact

Contact us if you experience issues relating to riding, maintenance and safety, or errors/faults with your G-F1.
E-mail Sales: hello@gyroorboard.com
E-mail Service: service@gyroor.com support@gyroorboard.com
Facebook: @Gyroor
Instagram: gyroor
Website: www.gyroor.com
Have your order number on hand when contacting Gyroor.
