REFRIGERANT LEAK DETECTOR
INSTALLATION MANUAL
This product complies with following directives/regulations
EU
GB
MD
2006 / 42 / EC
SMR S.I.
LVD
2014 / 35 / EU
EER S.I.
EMC
2014 / 30 / EU
EMC S.I.
RoHS
2011 / 65 / EU
RoHS S.I.
