- Page 1 Inspire Ultra SMV Series Branch Module #2#3 89FBMJ202 89FBMJ203 89FBMJ212 89FBMJ213 INSTRUCTION MANUAL WARNING! Read and follow all safety precautions in Instruction Manual - improper use can cause serious injury. www.delta-dct.com...
- Page 3 Preface Inspire Ultra MS Series Systems adopt the advanced manufacturing technology and takes the environmental-friendly R410A as refrigerant, which is a green product in the 21st century. Please carefully read the manual before installation and operation. The total capacity of the indoor units which runs at the same time cannot exceed the capacity of the outdoor units;...
-
Page 4: Table Of Contents
Contents Safety Precautions.........................1 Product Introduction ........................3 Names of Main Parts......................3 Combinations for Outdoor and Indoor Units ..............3 Parts and Components of Unit ..................4 Working Temperature Range ....................4 Selection of Installation Location and Precautions...............5 Selection of Installation Location ..................5 Outline Dimension and Servicing Space of 89FBMJ202 ...........6 Outline Dimension and Servicing Space of 89FBMJ203 ...........7 Outline Dimension and Servicing Space of 89FBMJ212 ...........8 Outline Dimension and Servicing Space of 89FBMJ213 ...........9... -
Page 5: Safety Precautions
1 Safety Precautions Warning! :It indicates improper operation might lead to human casualty or sever injury Caution! : It indicates that improper operation might lead to personal injury or property damage. - Page 6 Delta Delta Delta is not responsible of personal injury or equipment damage caused by improper installation and commission, unnecessary service and incapable of following the rules and instructions listed in the manual.
-
Page 7: Product Introduction
2 Product Introduction The BM module of Delta Super Free Match Series is the latest branch device, which adopts the intelligent control technology. Respond to the changes in load of the indoor units, it can coordinate the flow rate of the refrigerant well. Otherwise, it is very compact and has a flexible choice about the installation location, such as the ceiling of parlor, corridor, balcony, storeroom and etc. -
Page 8: Parts And Components Of Unit
2.3 Parts and Components of Unit Inspire Ultra MS Free Match Series, one outdoor unit is able to drive up to three BM modules and nine indoor units which include cassette type, duct type, wall-mounted type, floor ceiling type and console type. -
Page 9: Selection Of Installation Location And Precautions
3 Selection of Installation Location and Precautions ------------------------------------------------------------------------------------------------------------------------- Caution! The installation of the air conditioner must be in accordance with the national and local laws and regulations. The quality of the installation will affect the capability of air conditioner directly. The installation should be left to the appointed service center. -
Page 10: Outline Dimension And Servicing Space Of 89Fbmj202
3.2 Outline Dimension and Servicing Space of 89FBMJ202 Outline dimension Fig. 3 (mm) Table 3 Indoor unit side (mm) Sorts Outdoor unit side (mm) Port A Port B Liquid pipe Φ6.35 Φ6.35 Φ9.52 Gas pipe Φ9.52 Φ9.52 Φ15.9 Installation and service space ①... -
Page 11: Outline Dimension And Servicing Space Of 89Fbmj203
3.3 Outline Dimension and Servicing Space of 89FBMJ203 Outline dimension Fig. 5 (mm) Table 4 Indoor unit side (mm) Outdoor unit side Sorts (mm) Port A Port B Port C Liquid pipe Φ6.35 Φ6.35 Φ6.35 Φ9.52 Gas liquid Φ9.52 Φ9.52 Φ9.52 Φ15.9 Installation and service space... -
Page 12: Outline Dimension And Servicing Space Of 89Fbmj212
3.4 Outline Dimension and Servicing Space of 89FBMJ212 Outline dimension Fig. 7 (mm) Table 5 Indoor unit side (mm) Sorts Outdoor unit side (mm) Port A Port B Liquid pipe Φ6.5 Φ6.5 Φ9.7 Gas pipe Φ16.3 Φ16.3 Φ16.3 Installation and service space ①... -
Page 13: Outline Dimension And Servicing Space Of 89Fbmj213
3.5 Outline Dimension and Servicing Space of 89FBMJ213 Outline dimension Fig. 9 (mm) Table 6 Indoor unit side (mm) Outdoor unit side Sorts (mm) Port A Port B Port C Liquid pipe Φ6.5 Φ6.5 Φ6.5 Φ9.7 Gas liquid Φ16.3 Φ16.3 Φ16.3 Φ16.3 Installation and service space... -
Page 14: Installation Instruction
4 Installation Instruction Check the installation location and ensure it is strong and level. Otherwise, there should be enough space to install drainage pipe, so that the condensed water can be discharged. Reference to the size of hanger metal and drill 4 holes in the installation location. Hang the hanger bolts. -
Page 15: Installation Of Refrigerant Pipes
5 Installation of Refrigerant Pipes 5.1 Manifold Mode of Connecting Pipe For only one BM module, there will not be more than three indoor units. Fig. 13 For two BM modules, there will not be more than six indoor units. ... -
Page 16: Allowable Length And Drop Height Of Connecting Pipe
5.2 Allowable Length and Drop Height of Connecting Pipe Fig. 16 (8 indoor units) Table 7 The sorts The pipes Length （ m） Total length between outdoor unit and L1+L2+L3+L4+L5 ≤55 BM modules 86HS050J248 Total length ≤80 Maximum 1A+1B+1C+2A+2B+2C+ between indoor 3A+3B allowable 86HS060J249... -
Page 17: Installation Of Piping Adapter (89Fbmj203 And 89Fbmj213)
Table 8 Name Port A Port B (mm) (mm) Φ15.9→Φ19.05 Φ15.9 Φ19.05 Φ9.52→Φ12.7 Φ9.52 Φ12.7 Φ9.52→Φ15.9 Φ9.52 Φ15.9 Φ6.35→Φ9.52 Φ6.35 Φ9.52 Fig. 17 Install the piping adapter Refer to the piping connection size of the outdoor unit and indoor units, the appropriate piping ①... - Page 18 Fig. 19 Brazing the piping adapter If the connection size of the pipe adapter selected is different from the piping connection size ① BM module, cut the tube of the piping adapter from middle with tube cutter and remove the burrs. ...
-
Page 19: Precaution For Connection
Fig. 21 ④ After brazing, use wet cloths to cool off the pipes to be brazed sufficient. 5.5 Precaution for Connection 5.5.1 Precaution for connection Pipe connections should be follow the following rules: ① Outdoor unit shall be installed close to the indoor unit, hence to minimize the length and bends of connection pipes. - Page 20 ② The bending diameter of the pipeline must be greater than 200mm. The connection pipe cannot often be bent or straightened. Otherwise it will harden and crack. ③ If the thermal insulation of the refrigerant pipe is not removed, please do not bend the pipe. Otherwise, it maybe leads the pipe to crack.
-
Page 21: Electrical Wiring Work
6 Electrical Wiring Work 6.1 Wiring Connection The “L1”, “3” terminals are connected to the live wire, the “L2”,”N(1)” terminals are connected to the neutral wire and the”2” terminal is connected to the transmission line. Fig. 25 6.2 Requirements of Power Circuit and Cable Table 10 Phase and frequency 1Ph,60Hz... -
Page 22: Ground Requirements
ordinary polychloroprene sheathed cords. If the working condition changes, they should be modified according to the related national standard. The specifications of the air switch listed in the table above are applied to the breaker with the working temperature at 40 . If the working con dition changes, they should be modified ℃... -
Page 23: Procedures For Electrical Wiring Work
Pass the screw through the round terminals and fix it onto the terminal block. Fig. 26 6.6 Procedures for Electrical Wiring Work Unscrew the electrical equipment plate. The structure of behind the electrical equipment plate. a) 89FBMJ202 and 89FBMJ212 b) 89FBMJ213 and 89FBMJ213... - Page 24 Terminal black for BM Terminal black for indoor unit Name Ground screw module power supply power supply Name DIP switch Printed circuit board Terminal black for transmission line Fig. 27 Let the power cable and transmission line go through the rubber ring. In order to protect the power cable and transmission line from damaging by the hole, the rubber ring cannot fall from that, otherwise, it may cause electrical shock or fire etc.
-
Page 25: Instructions For Dip Switch
6.7 Instructions for DIP Switch 2 digits DIP is adopted to assign the address when using multi-BM modules and the address cannot be repeated in the same unit. One outdoor unit can connect to no more than 3 BM modules. “ON”... -
Page 26: Design Of Drainage Pipeline
7 Design of Drainage Pipeline 7.1 Installation of Drain Hose Remove the rubber stopper of drain hole. Connect the drain hose to the drain hole of BM module. The drain hose should be kept at 5~10 degrees of gradient to facilitate discharge of the condensing water. -
Page 27: Troubleshooting
9 Troubleshooting ------------------------------------------------------------------------------------------------------------------------- Caution! ◆ In the event of abnormal conditions (like stinky smell), please shut off the power supply immediately and then contact the appointed service center; otherwise, the abnormal running would damage the air conditioner and also would cause electric shock or fire etc. ◆... - Page 28 Thank you for Choosing airconditioners Perfectly engineered for your comfort. www.delta-dct.com...
