FNT series
Wall-Touch / Design-Touch
Operating Instructions
Made in Germany

Advertisement

Table of Contents
loading

Summary of Contents for Fasel Elektronik FNT Series

  • Page 1 FNT series Wall-Touch / Design-Touch Operating Instructions Made in Germany...
  • Page 2: About This Manual

    Additional information about an operating step  Cross-reference to a page  Read instructions  Result of a step Legal notice Operating manual for FNT series control Doc ID B_FNTxxxx Version 2.0 Date 02/2024 Manufacturer Fasel GmbH Elektronik Am Galgenacker 3 D-79232 March-Buchheim...
  • Page 3: Table Of Contents

    Contents About this manual .................. 2 1 Safety ...................... 5 Intended use .................. 5 Commissioning ................6 Qualifications of personnel ............8 Classification of warnings............... 9 Standards and regulations ............. 9 2 Identification..................10 Overview ..................10 Scope of delivery................10 Nameplate..................
  • Page 4 6 Troubleshooting..................35 Error messages ................35 6.1.1 Messages and notes on the display ........ 37 6.1.2 Confirm error messages..........37 7 Maintenance ..................38 Cleaning..................38 Spare parts ................... 38 Customer service................38 8 Disposal ....................39 9 Legal information.................. 40 Disclaimer..................
  • Page 5: Safety

    Safety Safety This operating manual is intended for persons who are authorised and quali- fied to set up and operate the control for a sauna cabin. The following safety instructions should be observed during setup and ope- ration. Failure to observe the safety instructions could result in death or se- rious injury.
  • Page 6: Commissioning

    Safety Commissioning This manual assumes that the installation of the control has been completed in accordance with the appropriate installation instructions and the installa- tion has been inspected and accepted by an authorised technician. Risk to life and limb Improper installation may leave live parts exposed. There is a risk to from electric shock life and limb from electric shock due to contact with electrically live parts.
  • Page 7 Safety Hazard due to Changes and alterations to the control or the installation may lead modifications to the to unforeseen hazards. Contact the manufacturer if you require a device technical modification.  You should only carry out modifications that have been approved in writing.
  • Page 8: Qualifications Of Personnel

    Safety Qualifications of personnel Risk of injury due to Improper handling can cause severe personal injury and damage to insufficient training property.  Assembly, installation, commissioning as well as troubleshoo- ting, maintenance and repairs should only be carried out by sui- tably qualified persons.
  • Page 9: Classification Of Warnings

    Safety Classification of warnings The texts in bold below are used in the following chapters to indicate the risks of hazardous situations. WARNING Warning indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Caution indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
  • Page 10: Identification

    Identification Identification The controls in the FNT series are available as Wall-Touch and Design-Touch models. Overview Wall-Touch In the Wall-Touch model the touch display is integrated into the control unit. The control unit is surface-mounted. Design-Touch In the Design-Touch model the control unit and the touch display can be installed separately.
  • Page 11: Nameplate

    Identification Nameplate The nameplate is located on the left side of the control unit. Wall-Touch A Model F Device number B Device designation G ID codes and certification marks C Item number H Do not dispose of with domestic waste D Customer ID Manufacturer E Electrical connection...
  • Page 12: Functions

    Identification Functions The controls are equipped with various functions depending on the model. Sauna Humidity Infrared FNT2000 FNT2200 FNT3000 FNT3200 FNT3400 Function Symbol FNT2000-DESIGN FNT2200-DESIGN FNT3000-DESIGN FNT3200-DESIGN FNT3400-DESIGN Sauna (Finnish) Sauna with humidity Infrared eco mode Temperature sensor Light dimming Fan dimming Optional humidistat Steam bath...
  • Page 13: Technical Data

    Identification Technical data The control units are available in various models and configurations. Devices made by a number of different manufacturers can also be connected to the control units. Sauna Humidity Infrared  FNT2000 / FNT2000-DESIGN  FNT2200 / FNT2200-DESIGN ...
  • Page 14 Identification Steam bath  FNT2000-STEAM / FNT2000-STEAM-DESIGN  FNT3000-STEAM / FNT3000-STEAM-DESIGN 0°C to +40°C Ambient temperature With protective coating: -20°C to +40°C max. 80% rel. hum. (non-condensing) Rel. humidity min. 00:15 h Heating period max. 06:00 h (max. 20:00 h*) 1N~ 230 V 50 Hz Power supply 230 V~ approved for external steam generator...
  • Page 15: Operation

    Operation Operation The control unit has various connection options and functions that differ depending on the model. The images on the touch display are specific to each model and may vary from those shown in the figures below.  2.4 Functions,  EN-12. For an overview of the functions, see User interface FNT2000 and FNT3000...
  • Page 16 Operation FNT2200 and FNT3200 The FNT2200 / FNT2200-DESIGN and FNT3200 / FNT3200-DESIGN control units can be used for the sauna (Finnish) and sauna with humidity bath modes. A Heating period F Selected bath mode B Desired temperature G Desired humidity in stages C Switch lighting on/off H Current temperature D Switch standby on/off...
  • Page 17 Operation FNT3400 The FNT3400 / FNT3400-DESIGN control unit can be used for the sauna (Finnish), sauna with humidity and infrared bath modes. A Heating period E Switch standby on/off B Desired temperature F Menu settings C Current temperature G Selected bath mode D Switch lighting on/off H Limiter temperature FNT Serie - Operating Instructions...
  • Page 18: Explanation Of Symbols

    Operation FNT2000-STEAM and FNT3000-STEAM The FNT2000-STEAM / FNT2000-STEAM-DESIGN and FNT3000-STEAM / FNT3000-STEAM-DESIGN control units can be used for the steam bath bath mode. A Heating period E Switch lighting on/off B Desired temperature F Switch standby on/off C Current temperature G Menu settings D Selected bath mode Explanation of symbols...
  • Page 19: Switching The Control Unit On/Off

    Operation Switching the control unit on/off The control unit can be switched on/off using the trip switch. The trip switch is located on the bottom of the control unit in the Wall-Touch model and on the left side in the Design-Touch. ...
  • Page 20: Starting The Unit

    Operation Starting the unit WARNING Fire hazard from overheating Objects placed on the oven could catch fire.  Ensure that there is nothing covering the oven.  Ensure that the air is able to circulate freely. WARNING Injuries or damage to health due to excessively high temperature and humidity Items covering the temperature sensor or humidistat may cause an increase in temperature or humidity in the cabin.
  • Page 21: Switching Off

    Operation Switching off NOTICE Device damage due to repeatedly switching off the unit improperly If the control unit is repeatedly switched off contrary to the instruc- tions in this operating manual the control unit may be damaged.  Observe the following instructions on how to switch off the con- trol unit.
  • Page 22: Temperature And Humidity

    Operation Temperature and humidity The desired temperature and humidity in the sauna cabin can be set, depen- ding on the model. With the FNT3400 control unit you can set the desired temperature and a limiter temperature for the infrared bath mode. The oven switches off when the sauna cabin reaches the desired temperature.
  • Page 23 Operation  Setting the humidity Press the desired humidity display.  You can adjust the humidity in stages or % depending on the model. Use the slider to adjust the humidity to the desired level in %* or in stages. Confirm your entry by pressing * Only with optional humidistat.
  • Page 24: 3.10 Heating Period

    Operation 3.10 Heating period Setting the heating period determines how long a bath mode remains on. The heating period can only be changed when the bath mode is off. The following maximum heating periods are permitted in accordance with EN 60335-2-53: Max.
  • Page 25: Menu Settings

    Menu settings Menu settings The exhaust air fan in the sauna cabin can be switched on and off on the touch display. The fan speed in the sauna cabin can be adjusted.  Switching the fan on/off Press the button on the touch display. Press ...
  • Page 26: Coloured Light

    Menu settings  Dimming the cabin light* Press the button on the touch display. Press and hold down for approx. 2 seconds. Use the slider to adjust the brightness to the desired level.  The lowest brightness level is on the left. The highest brightness level is on the right.
  • Page 27: Bench Heating

    Menu settings  Adjusting coloured light Press the button on the touch display. Press and hold down for approx. 2 seconds. Adjust the coloured light to the desired setting. A Coloured light auto mode, slow C Coloured light manual mode B Coloured light auto mode, fast D Adjusting the brightness level Confirm your entry by pressing...
  • Page 28: Essence Function

    Menu settings Essence function The essence function is available as an option for the FNT3200-DESIGN and FNT3400-DESIGN controls. Injection and intermission times can be set for the essence pump. The essence function is automatically displayed if the control has been equipped with this option. ...
  • Page 29: Option Output

    Menu settings Option output The option outputs can be assigned to specific functions by the customer and switched on/off from the control. This function is available as an option for the FNT3000-DESIGN, FNT3200-DESIGN and FNT3400-DESIGN controls.  Switching the option output on/off Press the button on the touch display.
  • Page 30: Basic Settings Menu

    Basic settings menu Basic settings menu eco mode eco mode is only available in the sauna (Finnish) bath mode. In eco mode the heating period is automatically set to 15 minutes once the desired tem- perature is reached. The oven also switches off automatically 3 minutes before the end of the heating period in eco mode.
  • Page 31: Time

    Basic settings menu Time  Setting the time Press the button on the touch display. Press Press Enter the time in hours and minutes using the number bar. Confirm your entry by pressing Temperature differential fan ON This setting is only available for the FNT2000-STEAM / FNT2000-STEAM-DESIGN and FNT3000-STEAM / FNT3000-STEAM-DESIGN controls.
  • Page 32: Display Settings

    Basic settings menu Display settings The backlight on the touch display can be switched on and off. The bright- ness and contrast of the touch display can be adjusted.  Switching the display lighting on/off Press the button on the touch display. Press Press ...
  • Page 33: Keypad Lock

    Basic settings menu Keypad lock Certain control functions can be locked on the touch display.  Locking functions Press the button on the touch display. Press Press Enter the PIN using the number bar.  PIN: 1111 Confirm your entry by pressing Select all functions you want to lock.
  • Page 34: Info Menu

    Basic settings menu Info menu The info menu shows all information about the control currently in use. This information is useful for the service engineer if a fault occurs.  Displaying the info menu Press the button on the touch display. Press Press You can use the...
  • Page 35: Troubleshooting

    Troubleshooting Troubleshooting This chapter describes potential faults on the control and how they can be eliminated. WARNING Personal injury due to improper troubleshooting Improper troubleshooting can lead to hazards due to electric shock or fire hazard from overheating.  If a fault occurs, disconnect the control from the mains power and secure the control against switching back on.
  • Page 36 Troubleshooting Fault Possible causes Troubleshooting To be carried out by Internal timing error Internal timing error. Service engineer Safety temperature limiter The connection to the safety - Check safety temperature Trained electrician/ circuit open, safety tempe- temperature limiter is bro- limiter service engineer rature limiter...
  • Page 37: 6.1.1 Messages And Notes On The Display

    Troubleshooting 6.1.1 Messages and notes on the display Fault Possible causes Troubleshooting To be carried out by Drying function cancelled The drying function has Follow instructions on the dis- Operator been cancelled prematurely. play. Water deficiency No water in evaporator. Top up water in accordance Operator with evaporator operating...
  • Page 38: Maintenance

    Maintenance Maintenance The controls are maintenance-free. Cleaning NOTICE Device damage due to aggressive cleaning agents Aggressive cleaning agents and aids may damage or destroy housings, components and cables.  Use only mild soap-based cleaning agents.  Ensure cloths used are damp, not wet. ...
  • Page 39: Disposal

    Disposal Disposal Dispose of the control in accordance with the regulations applica- ble in your country. Do not dispose of the control with domestic waste. Note on disposal of batteries The control contains batteries. Batteries must not be disposed of as dome- stic waste.
  • Page 40: Legal Information

    Legal information Legal information Disclaimer The utmost care has been taken whilst compiling the information and notes in this manual, which are based on current guidelines and standards, the state of the art and many years of knowledge and experience. The manufacturer is not liable for loss or damage resulting from: ...
  • Page 41: Copyright

    Legal information Copyright Copying in any form whatsoever including extracts, as well as use and/or communication of the contents requires the written permission of the manufacturer. The contents, whether in the form of text, drawings, images or other repre- sentations are protected by copyright and industrial property rights. Improper use of any kind is punishable by law.
  • Page 44 Fasel GmbH Elektronik Am Galgenacker 3 D-79232 March-Buchheim Tel: +49 7665 9241-0 Fax: +49 7665 41139 E-Mail: info@fasel-gmbh.de Internet: www.fasel-gmbh.de in preparation...
