Summary of Contents for Daavlin ClearLink UV Series
- Page 1 ClearLink™ Home-Control Operation Manual Modes of Operation • Guided Mode • Dosimetric Mode • Timed Mode Company Confidential. Printed copies will not be updated MNL-00002 [4] Page 1 of 22...
-
Page 2: Table Of Contents
Table of Contents 1.0 Control Type ................... 4 2.0 Indications for Use ................. 4 3.0 Delivery and Inspection ..............4 4.0 Site Selection ................... 5 Electrical Requirements ....................5 4.1.1 Circuit Breaker ......................5 5.0 Unpacking and Assembly .............. 5 6.0 Lamp Inspection ................ - Page 3 15.0 Environmental Specifications ............. 18 16.0 Warranty ..................20 16.1 Limited Warranty Policy .................... 20 16.2 Warranty Coverage ..................... 21 16.3 Customer Responsibility..................... 21 16.4 Warranty Service ......................21 16.5 Disposal ........................22 16.6 Other Services......................22 16.7 Contact Information ....................22 Company Confidential.
-
Page 4: Control Type
Dear Valued Customer, Thank you for selecting a Daavlin UV Series phototherapy unit. The use of light for the treatment of photoresponsive skin disorders has been our business since 1981. We are proud of our tradition of innovation in the field of phototherapy and are honored that you have chosen us for your phototherapy needs. -
Page 5: Site Selection
4.0 Site Selection A location for the device should be chosen within reach of an electrical service that meets the requirements of your specific device. See Section Error! Reference source not found. Electrical R equirements below. Extension cords are not recommended. It is important that the unit be properly grounded and installed on a standard, non-Residual Current Device (RCD) or ground fault circuit interrupter (GFCI) breaker. -
Page 6: Lamp Inspection
UV blocking glasses or goggles designed to block 100% of all UVA and UVB light from the eye area when worn. Always use Daavlin approved eyewear. ● Do not remove protective eyewear, or any other protective equipment, during treatment. - Page 7 EMC Precautions. If the device continues to malfunction cease operation and contact the Daavlin Service Department. Do not operate this device with a damaged cord or plug.
-
Page 8: Operating Specifications
Service & Installation Instructions manual. Unauthorized personnel should not open the panels. The Daavlin Service Department should be consulted before any service is performed. 8.0 Operating Specifications Ambient 15°C to 30°C (59°F to 86°F) -
Page 9: Labels And Symbols
WARNING: Equipment not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide. Labels and Symbols A removable label (Figure 1 Unlock Label) located near the keypad provides information on how to unlock the unit. - Page 10 A warning label (Figure 3 Warning Label) is affixed to your Daavlin phototherapy device in a prominent and easily readable position. Please read the label carefully as it contains important safety information. Figure 3 Warning Label Figure 4 Identification Label The serial number and date of manufacture of the device are printed on an identification label (Figure 4 Identification Label) that is located at the back of the unit near the power cord.
-
Page 11: General Instructions (All Modes Of Operation)
(For example, forgot lip balm, put sunscreen on tender area, etc.) Note: A free printable treatment log is available for download at www.Daavlin.com. You will need to purchase lip balm and sunscreen with an SPF (Sun Protective Factor) of at least 30. -
Page 12: Unlocking The Device
To prevent unauthorized use, the device will self-lock when left idle for twenty (20) minutes. 1. Tap the blank screen. The Daavlin logo will appear. 2. Tap the logo. The Lock Screen will appear (unless disabled) Figure 9 Logo Screen 3. -
Page 13: Running A Treatment
For example, each time you use the device, the ClearLink Controller will check the date of your last treatment. If you are on schedule, it will automatically proceed. However, if you have missed a treatment or treatments, the system will adjust accordingly to keep your dose at a safe level. A screen will appear advising you of the adjustment (See Figure 12 below). -
Page 14: Dosimetric Mode
Put on your goggles 6. Press the Enter key to begin the treatment. A several second countdown will begin. Positioning: Open the doors, enter the treatment chamber, and close the doors behind you. Face either the back or front of the device. In order to receive even and effective treatments, center yourself within the unit. -
Page 15: Timed Mode
Google Daavlin treatment time calculator and bookmark it on your phone. In that app, simply enter the time of your last treatment and the desired percentage increase and the calculator will give you the new treatment time instantaneously. -
Page 16: Care Of The Unit
It works just like a key. To remove the feature or to change it to a number that is easier to remember, contact Daavlin’s service department at 1-800-322-8546 for step-by-step instructions. Hours of operation are Monday through Thursday 7:30am - 8:00pm EST and Friday 8:30am - 5:00pm EST. -
Page 17: Cleaning/Disinfection
3 min 70% Isopropyl Alcohol Table 3 Daavlin Tested Cleaners 1. Thoroughly wipe down the surfaces and allow contact time listed in Table 3 Daavlin Tested Cleaners. 2. Allow to air dry and inspect for visible contaminants. 3. If contaminants remain repeat until no visible containments remain repeat steps 0 and 2. -
Page 18: Uv Series Lamp Replacement And Removal
Because of differences between brands, always replace lamps with the same brand as originally installed. Consult the Lamp Inspection Guide on page 6 for replacement lamp guidance and contact the Daavlin service department for a lamp replacement quote. They can be reached by dialing 1-800-322-8546 or via email at service@daavlin.com. - Page 19 Emissions Test Conformity EMC Environment Guide Limitation of Voltage Changes, Voltage The UV Series device is suitable for healthcare environment Compliant Fluctuations, and Flicker operation in hospitals and clinic Following IEC 61000-3-3 Table 5 Electromagnetic Immunity Emissions Test IEC 60601 Test Level Actual Level +/- 8kV (conductive +/- 8kV (conductive...
-
Page 20: Warranty
3V/m 16.0 Warranty 16.1 Limited Warranty Policy This Limited Warranty is provided to the original purchaser (the “Purchaser”) of the Daavlin device (the “Equipment”). Daavlin warrants Equipment to conform with the Equipment Company Confidential. Printed copies will not be updated... -
Page 21: Warranty Coverage
Limited Warranty. In such situations, Daavlin will cover freight expenses in the Company Confidential. Printed copies will not be updated... -
Page 22: Disposal
Daavlin. Even with Daavlin’s authorization, Daavlin shall not be responsible or liable for any such work (in or out of warranty). Daavlin reserves the right to bill for labor, expenses, and services for requested "warranty" service trips which result in work not covered by this Limited Warranty.
