Instruction Manual
60/90CM Gas Cooktop
Model No.: HGC60, HGC90
This manual explains the proper installation and use of your appliance, please
read it carefully before using, even if you are familiar with the product. The man-
ual should be kept in a safe place for future reference. In case of failure, only an
Authorized Technical Service may repair this hob. If it is not, the warranty will be
null and void.
Advertisement
Table of Contents
Troubleshooting
Related Manuals for HELLER HGC60
Summary of Contents for HELLER HGC60
- Page 1 Instruction Manual 60/90CM Gas Cooktop Model No.: HGC60, HGC90 This manual explains the proper installation and use of your appliance, please read it carefully before using, even if you are familiar with the product. The man- ual should be kept in a safe place for future reference. In case of failure, only an Authorized Technical Service may repair this hob.
-
Page 2: General Safety
Even if you have previously used this cooktop before, or any other gas hob, it is important that you read these instructions thoroughly before using the appliance, paying particular attention to the installation and safety instructions. Should any issue be found during the installation, operation, or its designated usage, review this manual to ensure all instruc- tions have been adhered to. - Page 3 Cooking appliances can become very hot in use - please keep children and pets away from the unit while it is in use. Do not allow children to operate or play with any part of the appliance. Do not use unstable pans and ensure that the handle is positioned away from the edge of the worktop.
-
Page 4: Children's Safety
DO NOT MODIFY THIS APPLIANCE. DO NOT USE THIS APPLIANCE AS A SPACE HEATER. The appliance must not be used as a work surface or as a storage surface. Do not heat an empty pan on the appliance. Children’s Safety The cooking zones will become hot during operation, always keep children away from the appliance. -
Page 5: Safety Instructions
Where this appliance is installed (in marinecraft or caravans, it shall not be used as a space heater. Special conditions, which shall be avoided, e.g. marine environment, and any conditions necessary to ensure optimum performance. The appliance can be used in freezing conditions. Safety Instructions Safety during the installation of the appliance DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS APPLIANCE. -
Page 6: Product Specifications
For safety reasons, cleaning of the appiance utilising a steam jet or other high pressure cleaning equipment is not permitted. Product Specifications Model Burner* Knob Total Gas Overview Supports Position Consumption HGC60 1W+2SR+1A With 2 types Front LPG:30.5M- for option NG:29.5MJ/h HGC90 1W+1R+2SR+1A With 2 types Front LPG:39.6M-... -
Page 7: Technical Specifications
User Manual Sealing Tape 1 roll Installation Clip 4 sets Screws 4 pieces ST4.2x24 LPG Injectors Model HGC60: 4 pieces Model HGC90: 5 pieces Elbow & Washers 1 Elbow, 3 Washers Natural Gas Regulator Technical Specifications Model Product Dimensions Cut-out Size... -
Page 8: Installation
Installation Unpacking the appliance Remove all packaging and make sure the appliance is in perfect condition. If you have any doubts, do not use the appliance and call your supplier. Some parts on the appliance are protected by a plastic film. This protective fil must be removed before the appliance is used. -
Page 9: Technical Information
Technical Information: The installation, adjustments, conversions and maintenance listed in this section must be carried out by qualified personnel only. The safety and automatic adjustment devices of the appliance may only be modified by an authorised service agent. The installation of this gas hob must comply with Australia and New Zealand standards. This appliance must be fitted in compliance with the installation rules given above. - Page 10 The gas connection is situated at the rear of the appliance, 540mm from the right side and 85mm from the rear of the hotplate . (Model:HGC60) The gas connection is situated at the rear of the appliance, 808mm from the right side and 85mm from the rear of the hotplate .
- Page 11 Apply the adhesive sealing tape to the underside lip of the burner box. Shown at G oppo- site. bench. Cast Iron Trivet – When installed in the benchtop, the dimension from the top of the Pan Support to the Benchtop surface is 47mm (Model:HGC60&HGC90) Model: HGC60 Model: HGC90...
-
Page 12: Electrical Connection
The power supply cord (supplied) must not touch against any hot surfaces and must be placed so that its temperature does not exceed 75℃ at any point along its length. After having installed the burner, the GPO must always be in an accessible position. Wiring Diagram (Model: HGC60) Wiring Diagram (Model: HGC90) - Page 13 4. Securing the hob in position using fixing brackets (supplied) Screw one end of the bracket into the pre-drilled holes in the underside of the hob. The other end of the bracket should be located underneath the worktop to secure the hob in position GAS CONNECTION (QUALIFIED PERSONNEL ONLY) The appliance has an G 1/2”...
- Page 14 Ensure the supply connection point, test point and natural gas regulator adjustment screw (for Natural gas installation) are accessible for testing and/or adjustment with the burner in the installed position. Where a flexible hose assembly is used, ensure it is approved to AS/NZS 1869, Class B.
- Page 15 Natural Gas (the appliance test point is located at the regulator) The supplied regulator must be fitted to the appliance inlet connection. Gas pressure must be adjusted to 1.0kPa when approximately 50% of the burners are on high flame. Universal LPG (the appliance test point is located at the injector) Gas pressure must be checked to confirm the Appliance operating pressure is 2.75 kPa, the appliance test point is the rapid burner injector as shown in the next page.
- Page 16 Natural gas to Universal LPG or vice versa. GAS CONVERSION INSTRUCTIONS: The manufacturers servicing instructions detail how authorised personnel may convert the burner from Natural gas to Universal LPG or from Universal LPG to Natural gas. Con- tact the manufacturer or agent as required. HGC60...
- Page 17 HGC90 Semi-rapid Semi-rapid Auxiliary Semi-rapid Rapid Auxiliary Semi-rapid...
-
Page 18: Abnormal Operation
Burners extinguished by cupboard doors. • Gas valves, which are difficult to turn. In case the appliance fails to operate correctly, contact the authorised service provider in your area. Start using your appliance HGC60 Control knob panel HGC90 Control knob panel... - Page 19 The burners are fitted with mains powered electronic spark ignitors, so must be connect- ed to the main power supply (i.e. nominal 220~240 V ac ,50Hz) to operate. If power is not available, the burner will still work but the burners will have to be lit manually using e.g., matches, utility lighter.
-
Page 20: Maintenance And Troubleshooting
Burner and utensil choice The maximum utensil (pan) diameters in millimeters (mm) for each burner are: 1. For Natural Gas burners - Auxiliary (small) and Semi-Rapid (medium) = 195 mm - Rapid (large) = 230 mm - Triple ring (wok) = 270 mm 2. - Page 21 BURNERS Remove trivets from hob. Ensure burners are cool. Remove the burners enameled cap (C) and aluminum burner crown (F). Wash down with warm soapy water and rinse with clean water. Dry with a clean, soft cloth. Use a cotton bud, toothbrush, or some other item to clean out any incrustations or dirt from the four holes marked(H).
-
Page 22: Troubleshooting
Troubleshooting Servicing of the hotplates must only be done by an authorised service representative (see back of this booklet) and the hotplate must not be modified. Power must be disconnected before any servicing or maintenance is conducted. DO NOT MODIFY THIS APPLIANCE. It is recommended the hotplate serviced by an authorized person at least every 2 years.
