MAINTENANCE

Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to
clean this unit.

PRODUCT SERVICE

1) Damage requiring service: The unit should be serviced by qualified service
personnel if:
(a)The DC power supply cord or AC adaptor has been damaged.
(b)Objects or liquids have gotten into the unit.
(c)The unit has been exposed to rain.
(d)The unit does not operate normally or exhibits a marked change in
performance.
(e)The unit has been dropped or the cabinet damaged.
2) Servicing Personnel: Do not attempt to service the unit beyond that described
in this user manual. Refer all other servicing to authorized servicing personnel.
3) Replacement parts: When parts need replacing ensure the servicer uses parts
specified by the manufacturer or parts that have the same characteristics as the
original parts. Unauthorized substitutes may result in fire, electric shock, or other
hazards.
4) Safety check: After repairs or service, ask the servicer to perform safety
checks to confirm that the unit is in proper working condition.

WARRANTY

If your product does not work properly because of a defect in materials or
workmanship, our Company (referred to as "the warrantor" ) will, for the length of
the period indicated as below, (Parts(2)Year, Labor(90) Days) which starts with
the date of original purchase ("Limited Warranty period"), at its option either(a)
repair your product with new or refurbished parts, or (b) replace it with a new of a
refurbished product. The decision to repair or replace will be made by the
warrantor.
During the "Labor" Limited Warranty period there will be no charge for labor.
During the "Parts" warranty period, there will be no charge for parts. You must
mail-in your product during the warranty period. This Limited Warranty is extended
only to the original purchaser and only covers product purchased as new. A
purchase receipt or other proof of original purchase date is required for Limited
Warranty service.

MAIL-IN SERVICE

When shipping the unit carefully pack and send it prepaid, adequately insured and
preferably in the original carton. Include a letter detailing the complaint and
provide a daytime phone and/or email address where you can be reached.
www.seada.co.uk
4
SD-HTS
HDMI to SDI Converter, with 2 SDI outputs
Dear Customer
Thank you for purchasing this product. For optimum performance and safety,
please read this manual carefully before connecting, operating, or adjusting this
product. Please keep this manual for future reference.

FEATURES

⚫
Convert HDMI to SD/HD/3G-SDI
⚫
Distributes 1 HDMI source to 2 SD/HD/3G-SDI output simultaneously
⚫
Support HDMI input resolutions:
1080p (50/60/59.94/30/29.97/25/24/23.98Hz)
1080i (60/59.94/50Hz), 720p (60/59.94/50Hz), 480i (60/59.94HZ)
⚫
Work with SDI to HDMI converter to cascade many layers
⚫
Support transmission distance up to 100m over RG59 cable
⚫
With mounting ears
NOTICE
Our company reserves the right to make changes in the hardware, packaging,
and any accompanying documentation without prior written notice.
