innex DC500 Quick Start Manual

4K Visualizer / Document Camera
Quick Start Guide
Getting started with DC500
3.
(1) Pull the camera head up
from its base plate in the
steps shown.
2.
1.
(2) Plug in the USB cable and attach the cable clip
to the camera arm.
(3) Adjust the camera head until it is horizontal. Fully extend the
arm to capture A3-sized content. After adjusting the camera
to the desired position, press the focus button to trigger focus
if auto-focus mode is o .
Max. A3-sized
Minimum
10cm
Innex DC500
is a 2-in-1 document camera and webcam
that features crystal clear 4K resolution, a noise-cancelling
microphone, smart autofocus, and auto-rotation with its
built-in G-sensor. It works out of the box with most UC
software, such as Zoom, Google Meet, Microsoft Teams,
Skype, and more. Ideao's complimentary software can
help you enhance your lessons and presentations.
Download Ideao VisualCam and the IdeaoCam Chrome
extension for digital zoom, snapshot, recording,
annotation, Google account integration, and more.
For more information please visit:
Ideao VisualCam
https://funtechinnovation.com/software/ideao-visualcam/
IdeaoCam
https://funtechinnovation.com/software/ideaocam/
Package Contents
DC500
USB C to A Quick
USB Cable & Clips Adapter Start Guide Carry Bag
Auto Focus
OFF
Turn o Auto Focus mode when using the DC500 as a document
camera for still objects such as document. When Auto Focus is o ,
auto focus is triggered only when the focus button " " is pressed.
Press the focus button to trigger focus.
ON
Turn on Auto focus mode when using the DC500 as a webcam to
always keep your face in focus. Or as a document camera that
needs to capture dynamic movements.
a
b
g
h
j
i k
a Micro USB Port
DC500 Overview
b Auto Focus On/O
AI Noise Reduction
The AI-powered noise reduction mode is designed to filter out
background noise, providing clear audio for e ective communication
and improving the quality of remote presentations and meetings.
ON
c
d e
If the hinge appears loose after
some use, use a screwdriver to
m
l
e
AI Noise Reduction On/O
f
Auto Rotate 180° On/O
g
LED Indicator
h
Built-in Microphone
i
Camera
j LED Light
Focus / Rotate Button
k Flip Camera Head 0°~180°
c
Press once: trigger focus once
Long press: rotate image 0/180°
l Base Plate
LED Light Button
d m
Bolts
Press to turn on LED light. Three levels brightness.
Auto Rotate 180°
(Use DC500 as a webcam)
OFF
When the Auto-Rotate mode is o , you can long press the button
to trigger 180° rotation.
Long press to rotate
If the image appears mirrored, please
check the video settings in the video
conference software you are using.
ON
When the Auto-Rotate mode is on and you flip the camera head
to the front-facing position, the Auto-Rotate mode will
automatically rotate the view by 180°.
Rotate 180°
f
tighten it.
