Pinup is ideal for illuminating plants and walkways
outdoors. The fixture can be mounted in a series
of different ways; in the ground, above or under a
surface and it can also be mounted on a wall.
The height of the Pinup can be reduced. This
process must be done on site by the installer using
a pipe cutter.
PIN UP
DATA
Product
Article no.
SPECIFICATIONS
Weight
Material
IP protection grade
Overall dimensions
Labelling
Insulation class
Colour
Ø109 mm
ELECTRICAL SPECIFICATIONS
Light Fitting
Dimming
Colour
ADDITIONAL REQUIREMENTS
Mounting Kit
NOTE
Be sure to use a suitable cable, as well as making a waterproof cord connection
with the fixture.
The light source of this light fixture is not replaceable; when the light source
reaches its end of life the whole light fixture must be replaced.
Cable is not replaceable, if damaged the product must be discarded.
500 mm
Pin Up
1A10.3070.30
1,2 kg
Aluminium
IP44
Ø109 mm, H:500 mm
Class I
Black
LED, 230V, 6W
No
3000K
Ground Kit – 1A10.K80
Below Floor Kit – 1A10.K81
Above Floor Kit – 1A10.K82
Wall Kit – 1A10.K83
