Summary of Contents for MasterKraft MCBIAR01
Page 1
MCBIAR01 Air Bike Classic Owner’s Manual Assembly Instructions / Owner’s Manual READ ALL ASSEMBLY INSTRUCTIONS AND SAFETY PRECAUTIONS BEFORE IMPORTANT: USING THIS PRODUCT.REFERENCE ALL SAFETY GUIDELINES AND WARNING LABELS. RETAIN PRODUCT LITERATURE FOR FUTURE REFERENCE. PROPERLY WARM UP AND STRETCH BEFORE EXERCISING.IF YOU FEEL PAIN...
MCBIAR01 Assembly Preparation • To ensure ease of product assembly, please take time to verify the size and quantities of all required assembly hardware. Use the itemized parts listing and hardware chart for reference. • The product assembly process has been documented in easy-to-follow steps. Please read all assembly instructions carefully.
Page 3
MCBIAR01 Assembly Parts Listing ITEM# DESCRIPTION Q'TY FRAME FRONT STABILISER SET REAR FRONT STABILISER SET CONSOLE WIRE CONSOLE CONSOLE POST SEAT TRACK SEAT POST SEAT FIX HANDLEBAR CONNECTING ARM PAIR LEFT LEVER ARM RIGHT LEVER ARM FOOT REST LEFT PEDAL...
MCBIAR01 Exploded View Assembly Parts NOTE: THE EXPLODED PARTS VIEW IS SHOWN FOR REFERENCE ONLY. SOME ITEMS MAY BE PREASSEMBLED. PLEASE REFER TO THE INDIVIDUAL ASSEMBLY STAGE INSTRUCTIONS FOR DETAILED PARTS ORIENTATION.
Page 5
MCBIAR01 Assembly Instruction Assembly Stage #1 Attach Stabilisers To The Main Base Figure 1 Adjustable Levelers Assembly Hardware Required: Button Head Allen Bolt M8*20L Qty. 4 Washer 18*8.5*1.5T Qty. 4 Spring Washer Qty. 4 Assembly Description: A. Assemble the Front STABILISER Assembly (#2) to the Main Base Assembly (#1) using 2-Button Head Allen Bolt (#22), 2-Spring Washers (#23), and 2-Washers (#24).
Page 6
MCBIAR01 Assembly Instruction Assembly Stage #2 Attach Console Mast & Mount Computer On The Main Base Assembly Hardware Required: Button Head Allen Bolt M8*20L Qty. 2 Spring Washer Qty. 2 Washer 18*8.5*1.5T Qty. 2 Assembly Description: A. Carefully route the Sensor Cable (#4) through the Computer Mast (#6) and slide the mast down onto the corresponding mounting area of the Base Frame Assembly.
Page 7
MCBIAR01 Assembly Instruction Assembly Stage #3 Attach Seat Slider And Seat To Main Base Assembly Assembly Description: A) Insert the Adjustable Seat Slider (#7) into the u-channel of the Seat Support Post (#8). Secure the seat slider assembly in place using the 1-Seat Adjustment Knob (#10).
Page 8
MCBIAR01 Assembly Instruction Assembly Stage #4 Attach Pivot Arms To The Main Base Assembly Hardware Required: Allen Bolt M8*35 L Washer 18*8.5*1.5T Qty. 2 Qty. 2 Nylon Nut M8 Qty. 2 Assembly Description: A. Install the Pivot Arms (#16 & #17) by threading the (preinstalled) pivot shaft into the corresponding pivot- boss of the Base Frame Assembly (#1).
Page 9
MCBIAR01 Assembly Instruction Assembly Stage #5 Attach Pedal & Foot Rest To The Main Base Assembly Assembly Hardware Required: Pan Head Screw M5*10L Qty. 2 Assembly Description: Assembly Note: The right and left pedals are appropriately marked (R) and (L). The threading orientation on the left pedal is reversed from the threading orientation on the right pedal.
MCBIAR01 Troubleshooting Basic Troubleshooting Tips Problem Description Suggested Solution No Display 1. Check battery orientation: + / - 2. Check battery voltage: (2) aa batteries 1.5 volts each 3. Check cable connections: make sure connections are secure and in the correct orientation.
MCBIAR01 Preventative Maintenance Equipment Maintenance • Use a dampened soft-cloth to wipe equipment free of perspiration after each use. Avoid getting excessive moisture on computer or electronic components. Do not use abrasive cleaners or petroleum-based solvents to clean equipment. •...
MCBIAR01 Maintenance Information Service Daily Monthly Quarterly Annually Clean/Dry Frame & Console w/ mild soap and cloth Inspect Unit for Noise or loose components Ensure Unit is level-Adjust STABILISER Feet Tighten Crank & Bell Crank Bolts, Tighten Pedals Tighten Seat Bolts...
Page 13
MCBIAR01 Maintenance Information 3. Linkage Arm Check (Monthly): Tighten the linkage bolts and nuts using a 6mm Allen wrench and 13mm wrench. Tighten these parts snug, but do not over tighten or keep tightening. Note: There will be little play in these linkages after tightening, but this is normal.
Page 15
MCBIAR01 Part List PART DESCRIPTION PART# PART DESCRIPTION PART# FRAME CHAIN FRONT STABILISER SET CHAIN REAR STABILISER SET SPEED SENSOR BRACKET ZEPHYR CONSOLE WIRE CHAIN TESIONER 4PAIR CONSOLE IDLER HUB CONSOLE POST WHEEL SEAT TRACK RIGHT CHAINGUARD SEAT POST LEFT CHAINGUARD...
